- Page 1 73-0084-250 3/08 Lionel Shakespeare Express “Kinlet Hall” Passenger Set Owner’s Manual...
- Page 2 Congratulations! ongratulations on your purchase of The Shakespears Express "Kinlet Hall" Passenger Set! Built in 1929, #4936 Kinlet Hall is one of nearly three hundred Hall-type locomotives built for Great Western Railway between the world wars. During World War II, #4936 was severely damaged when it ran directly into the crater of a bomb after a heavy Luftwaffe raid in 1941 on Plymouth Harbor.
-
Page 3: Table Of Contents
Table of contents Running your train Running your train set Adding smoke fluid to your locomotive’s smoke generator Coupling Reverse unit procedure Sounding your locomotive's whistle Maintaining and servicing your set Lubricating your locomotive Replacing your locomotive’s traction tire Replacing your locomotive’s headlamp Replacing the passenger car lamps Notes Limited Warranty/Lionel Service... -
Page 4: Running Your Train
Running your train Running your train set With track power off, place your train set on the track. Refer to page 5 for information on coupling the cars. Connect the drawbar between the locomotive and tender. See Figure 1. If the smoke unit switch is in the ON position, add smoke fluid to your locomotive’s Caution! stack to prevent damage to the smoke unit. -
Page 5: Adding Smoke Fluid To Your Locomotive's Smoke Generator
Running your train Adding smoke fluid to your locomotive’s smoke generator our locomotive is equipped with a smoke generator that produces safe, clean white smoke during operation if the smoke unit switch is in the ON position. Refer to Figure 3 on page 6 for the location of the switch. -
Page 6: Reverse Unit Procedure
Running your train Reverse unit procedure he electronic reverse unit inside your Lionel locomotive acts like the transmission in a car. When you apply power to the track, the locomotive moves in the direction specified by the reverse unit—or it sits in neutral, awaiting another power interruption. Power interruptions are the signal that tells the reverse unit to sequence to the next operational state. -
Page 7: Sounding Your Locomotive's Whistle
Running your train Sounding your locomotive’s whistle ress the HORN/WHISTLE button on your controller to sound the locomotive's whistle. If your controller does not have a HORN/WHISTLE button, install a Lionel Sound Activation Button (available separately, part no. 610-5906-001). Connect the button as shown in Figure 4. All track power must feed through the Sound Activation Button. -
Page 8: Maintaining And Servicing Your Set Lubricating Your Locomotive
Maintaining and servicing your set Lubricating your locomotive elp your steam locomotive lead a long and productive life on your railroad by maintaining it properly. We recommend that you purchase a Lionel Lubrication and Maintenance Kit (6-62927), available from your Lionel dealer. Two basic rules to keep in mind: never over-lubricate (a small amount will do) and avoid getting grease or oil on the locomotive’s wheels, contact rollers, or your track. -
Page 9: Replacing Your Locomotive's Traction Tire
Maintaining and servicing your set Replacing your locomotive’s traction tire ne of the locomotive’s drive wheels is fitted with a rubber traction tire to enhance tractive effort, allowing your locomotive to pull many cars at once. To replace the traction tire, simply unscrew the drive rod nut from the wheel using a 5.5mm nut driver. -
Page 10: Replacing The Passenger Car Lamps
Maintaining and servicing your set Replacing the passenger car lamps ach passenger car is illuminated by two lamps, Lionel part no. 630-8352-311. During the course of normal operations, you may find that the lamps require replacement. Replacement lamps are available at your authorized Lionel Service Center or from Lionel Service in Chesterfield, MI. 1. -
Page 11: Notes
Notes... -
Page 12: Limited Warranty/Lionel Service
Limited Warranty/Lionel Service his Lionel product, including all mechanical and electrical components, moving parts, motors and structural components, except for light bulbs, is warranted to the original consumer-purchaser, for one year against original defects in materials or workmanship when purchased through an authorized Lionel merchant.
