- Page 1 K&F NOMOS XLS Version 1.2 User's Manual Released: 30.06.2014 Important Information, Please Read Before Use! KLING & FREITAG GmbH Junkersstraße 14 D-30179 Hannover TEL +49 (0) 511 96 99 70 FAX +49 (0) 511 67 37 94 www.kling-freitag.de...
-
Page 3: Table Of Contents
Removing the Transport Covers Stacked Setup Configuration and Connecting Diagram System Requirements for Use Terminal assignment NOMOS XLS combined with other K&F tops. Cardioid Arrays with NOMOS XLS 5.4.1 Setup instructions for a cardioid array 5.4.2 LSBlocks for cardioid use... -
Page 4: Introduction
Thank you for your decision to buy a KLING & FREITAG product. To guarantee a trouble- free operating of the equipment and to allow your KLING & FREITAG NOMOS XLS system to achieve its full potential please read the operating instructions carefully before use. With the purchase of a NOMOS XLS, you have acquired a large sound system with the highest possible quality and performance capabilities. -
Page 5: Product Description
User's manual K&F NOMOS XLS Product Description Scope of Delivery • Subwoofer NOMOS XLS • User's Manual Overview of components Stacking grooves (8x) , adjacent: plastic glider speaker enclosure handle (2x) Threaded stand flange Speakon connector, front (behind company logo) -
Page 6: Accessories
User's manual K&F NOMOS XLS Accessories Transport Cover NOMOS XLS Protective Cover NOMOS XLS Loudspeaker patch cable NLT-425, 5 m KLING & FREITAG GMBH © 2014 Version 1.2 Page 6 of 21... -
Page 7: Safety Instructions
User's manual K&F NOMOS XLS Safety Instructions The speaker is solely for professional use in the manner described here. To prevent damage to persons and property, you must set up the speaker in compliance with the specifications of applicable national standards. -
Page 8: Protecting The Speakers / Operating Safety
Make sure that the stacking feet of subwoofers stacked on top of one another are securely positioned in the grooves of the lower speaker. If you place a top speaker on a NOMOS XLS you must always strap the speakers to one another and secure them from falling over. -
Page 9: Setup
User's manual K&F NOMOS XLS Setup Removing the Transport Covers To remove the transport lid, turn the appropriate catches 180° to completely release the latch. Lift the lid from the speaker. Stacked Setup Securely place the bottom subwoofer onto a level surface. -
Page 10: Configuration And Connecting Diagram
User's manual K&F NOMOS XLS Configuration and Connecting Diagram System Requirements for Use K&F CD 44 Digital System Controller LAB.GRUPPEN FP 10000Q: LAB.GRUPPEN FP 14000: for high power configurations with NOMOS subwoofer Connector Panel CP 4: These components will be referred to as 'K&F SystemRack' in this manual. -
Page 11: Nomos Xls Combined With Other K&F Tops
K&F NOMOS XLS NOMOS XLS combined with other K&F tops. The NOMOS XLS can only be combined in 2 channel mode with all K&F top speakers when using the Controller CD 44. To do so, select the desired LS blocks for the top speaker in the Controller CD 44, and combine these with the LS block for the NOMOS XLS subwoofer. -
Page 12: Cardioid Arrays With Nomos Xls
K&F NOMOS XLS Cardioid Arrays with NOMOS XLS The subwoofer NOMOS XLS is designed so that it can be used as a cardioid system in an array of three subwoofers, or in multiples of three. A cardioid array results in an increase of sound pressure towards the front because of the rear-facing subwoofer. -
Page 13: Lsblocks For Cardioid Use
User's manual K&F NOMOS XLS When cardioid arrays are stacked on the floor, ensure that there is always a distance of at least 40 cm between each unit of 3. Unifilar drawing: 40 cm [1,3 ft] 40 cm [1,3 ft] 40 cm [1,3 ft] 5.4.2... -
Page 14: Cardioid Configurations With Different Speakers
Fuse in the NOMOS XLS To increase the operating safety of the NOMOS XLS, the subwoofers are equipped with fuses at the signal input. These fuses reduce the risk of consequential damage resulting from a short circuit (i.e. charred cables / connectors / fire damage). -
Page 15: Transport And Storage
Transport and Storage The NOMOS XLS is protected against short-term moisture. The accessories has to be stored, transported and used in a dry enviroment. The NOMOS XLS System is not designed for long- term use in a corrosive environment. Make sure that the system is adequately ventilated during longer storage periods so that possible residual moisture can escape from the equipment. - Page 16 User's manual K&F NOMOS XLS In this context, it is very important to keep an inspection log book. In this inspection log book, the data for every used accessory is entered at the periodic inspections, making the data available at all times for possible inspections. This book should document maintenance measures and inspection intervals and contain parts lists.
-
Page 17: Technical Specifications
1) 50% duty cycle Measurings taken with the K&F SystemRack. The K&F SystemRack is required for operation of the K&F NOMOS XLS. KLING & FREITAG GMBH © 2014 Version 1.2 Page 17 of 21... -
Page 18: 10. Measuring Diagrams
User's manual K&F NOMOS XLS 10. Measuring Diagrams Polar Patterns Cardioid Hypercardioid Note: Attenuation factor depends on setting and configuration (s. p. 10). Frequency response KLING & FREITAG GMBH © 2014 Version 1.2 Page 18 of 21... -
Page 19: 11. Dimensions Nomos Xls
User's manual K&F NOMOS XLS 11. Dimensions NOMOS XLS Weight: 41.3 kg KLING & FREITAG GMBH © 2014 Version 1.2 Page 19 of 21... -
Page 20: 12. Disposal
User's manual K&F NOMOS XLS 12. Disposal Please recycle the packaging material of the device. 12.1 Germany It is not allowed to dispose of used electrical equipment as domestic waste. But please do not dispose of them at official collecting points for recycling either! All KLING &... - Page 21 User's manual K&F NOMOS XLS KLING & FREITAG GMBH © 2014 Version 1.2 Page 21 of 21...
