- Page 1 K&F PASSIO SUB 15 Version 1.1 User's Manual Released: 03.09.2015 Important Information, Please Read Before Use! KLING & FREITAG GmbH Junkersstraße 14 D-30179 Hannover TEL +49 (0) 511 96 99 70 FAX +49 (0) 511 67 37 94 www.kling-freitag.de...
-
Page 3: Table Of Contents
Instructions for Speaker Stacking Preventing hearing damage Protecting the Speakers / Operating Safety Configuration and Connecting Diagram PASSIO SUB 15 combined with other K&F tops. 4.1.1 Combination with Top Speakers in 2-Channel Mode 4.1.2 Combination with Top Speakers in 1-Channel Mode... -
Page 4: Introduction
With the purchase of a PASSIO SUB 15, you have acquired a large sound system with the highest possible quality and performance capabilities. As the owner of a PASSIO SUB 15 loudspeaker, you now have a versatile and highly professional tool which, when operated properly, is a true pleasure to use. -
Page 5: Product Description
User's manual K&F PASSIO SUB 15 Product Description Scope of Delivery • Subwoofer PASSIO SUB 15 • User's Manual (1x) System Requirements K&F TOPAS-system amp Lab.gruppen IPD 2400 Lab.gruppen PLM+ K&F CD 44 Digital System Controller: LAB.GRUPPEN FP 10000Q: These components are referred to as 'K&F SystemRack'. -
Page 6: Overview Of Components
User's manual K&F PASSIO SUB 15 Overview of Components (4x) Stacking grooves on top of the enclosure, for stackings of identical enclosures (2x) handle Threaded stand flange with M20 threads for use with distance rod. Front grille locking profiles for optional transport cover (2x) Speakon connector 4-pin NLT4MP (parallel) (8x) rubber foot 4 x on the side, 4 x on the bottom. -
Page 7: Accessories
User's manual K&F PASSIO SUB 15 Accessories Protective Cover PASSIO SUB 15 Distance rod 337 Transport Cover PASSIO SUB 15 KLING & FREITAG GMBH © 2015 Version 1.1 Page 7 of 19... -
Page 8: Safety Instructions
Make sure that the stacking feet of subwoofers stacked on top of one another are securely positioned in the grooves of the lower speaker. If you place a top speaker on a PASSIO SUB 15 you must always strap the speakers to one another and secure them from falling over. - Page 9 User's manual K&F PASSIO SUB 15 • overloading the speakers or • using the speakers without K&F SystemRack we do not assume warranty and excludes liability for possible consequential damage. The following signals may damage the speakers: • permanent high-level signals with high frequency and continuous noise from feedback, •...
-
Page 10: Configuration And Connecting Diagram
4.1.1 Combination with Top Speakers in 2-Channel Mode The PASSIO SUB 15 can only be combined in 2 channel mode with all K&F top speakers when using the Controller CD 44. To do so, select the desired LS blocks for the top speaker in the Controller CD 44, and combine these with the LS block for the PASSIO SUB 15 subwoofer. - Page 11 (Controller CD 44) K&F PASSIO 2xPassio+PSub15 K&F 2x Passio + Passio Sub 15 K&F GRAVIS 8 2xGra8W+PSub15 K&F 2x Gravis 8 W + Passio Sub 15 K&F GRAVIS 12N 2xGra12+N+PSub15 K&F 2x Gravis 12+N + Passio Sub 15 K&F GRAVIS 12W 2xGra12+W+PSub15 K&F 2x Gravis 12+W + Passio Sub 15...
- Page 12 User's manual K&F PASSIO SUB 15 IPD2400 EU: LS-Block PASSIO PASSIO SUB 12 To the next IPD2400 EU IPD2400 EU Depending on the top used, you must make allowances in 1-channel operations for more or less significant volume losses as compared to 2-channel operations.
-
Page 13: Fuse In The Passio Sub
K&F PASSIO SUB 15 Fuse in the PASSIO SUB 15 To increase the operating safety of the PASSIO SUB 15, the subwoofers are equipped with fuses at the signal input. These fuses reduce the risk of consequential damage resulting from a short circuit (i.e. -
Page 14: Transport And Storage
Transport and Storage The PASSIO SUB 15 is protected against short-term moisture. The accessories has to be stored, transported and used in a dry enviroment. The PASSIO SUB 15 System is not designed for long-term use in a corrosive environment. -
Page 15: Technical Specifications
User's manual K&F PASSIO SUB 15 Technical Specifications Design Bass reflex system Operated with K&F SystemRack, K&F TOPAS, K&F PLM+, K&F D-Series or Lab.gruppen IPD 2400 Cut-off frequencies 100 Hz (2-channel mode) Lower cut-off frequency 40 Hz / 33 Hz... -
Page 16: Measuring Diagrams
User's manual K&F PASSIO SUB 15 Measuring Diagrams Frequency response Frequency response with system controller Frequency (Hz) KLING & FREITAG GMBH © 2015 Version 1.1 Page 16 of 19... -
Page 17: Dimensions Passio Sub
User's manual K&F PASSIO SUB 15 10. Dimensions PASSIO SUB 15 KLING & FREITAG GMBH © 2015 Version 1.1 Page 17 of 19... -
Page 18: 11. Disposal
User's manual K&F PASSIO SUB 15 11. Disposal Please recycle the packaging material of the device. 11.1 Germany It is not allowed to dispose of used electrical equipment as domestic waste. But please do not dispose of them at official collecting points for recycling either! All KLING &... -
Page 19: 12. Ec Declaration Of Conformity
User's manual K&F PASSIO SUB 15 12. EC Declaration of Conformity for the products mentioned hereafter including model variants from KLING & FREITAG GmbH provided the products have not been altered subsequently. Loudspeaker systems: ACCESS B5 E 90 MK II...
