5MGR54XXD Series Fan
UL Model No. : AC-552
ALTO
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Monte Carlo Fan Company 5MGR54XXD Series
Summary of Contents for Monte Carlo Fan Company 5MGR54XXD Series
- Page 1 5MGR54XXD Series Fan UL Model No. : AC-552 MonteCarloFans.com To register your fixture, please visit our website: MonteCarloFans.com NEED HELP? STOP ALTO ¿NECESITA AYUDA? AVEZ-VOUS BESOIN D’AIDE? Please do not return this product to the store. Por favor no devulva este producto a la tienda.
-
Page 2: Helpful Tools
Helpful Tools Safety instructions WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70-1999), including fire-rated construction. - Page 3 P l a c e c a n o p y r i n g o v e r Insert downrod into the yoke on top Thread the leadwires and of fan body. Align the hole in the downrod then place yoke s a f e ty c a b l e t h r o u g h t h e downrod with the hole in the yoke.
- Page 4 Flushmount Installation Go to step 30 to finish installation Lift Conopy allowing the 2 studs to Remove side covers from canopy protrude through the canopy. and then remove set screws and Next lift the cover ring and install pins from yoke as inset shown. knurled nuts as shown.
- Page 5 Shipping stabilizer Check motor for shipping stabilizers P l a c e b l a d e b ra c ke t o n t o Install blade bracket with and remove if present. Install the blade by aligning the 3 holes b l a d e b y 3 b l a d e s c r e w s blade assembly to motor using the on blade as shown.
- Page 6 Thread lead wires of light kit C o n n e c t w h i t e w i r e f r o m P l a c e l o c k w a s h e r a n d h e x through center hole in switch fan to white wire from light nut over lead wires from light...
- Page 7 Remote Control Transmitter Features: MEDIUM SPEED LED LIGHT LOW SPEED HIGH SPEED LIGHT ON/OFF SETTING A N D D I M M E R ( P r e s s a n d h o l d t o d i m l i g h t infinitively) F A N O F F S E T T I N G (Turns fan off only)
-
Page 8: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 9 Jul.2010...
