  • Page 1 Pro Line 9460A Vandal Resistant Mini Dome User’s Manual October 13, 2008...
  • Page 2 All Rights Reserved All text and figures included in this publication are the exclusive property of DVTel Inc., and may not be copied, reproduced or used in any way without the express written permission of DVTel Inc. Information in this document is subject to change without notice.

  • Page 3: Table Of Contents

    To set the parameters of a mini dome camera ....2-3 Site Installation of the Pro Line 9460A Mini Dome Camera ..2-5 To install the mini dome camera .
  • Page 4 Pro Line 9460A User’s Manual To set Serial Port parameters ......3-6 Setting Video Profile Parameters ......3-7 To set the Video Profile parameters .

  • Page 5: Overview

    IP networks. It is built on open standards to provide long-term investment protection. The Pro Line 9460A mini dome camera can be used with the iSOC NVMS applications. Furthermore, it enables configuration and video viewing from web browsers and configuration via Telnet.

  • Page 6: Hardware Products Warranty And Returns Statement

    DVTel packing slip or other transportation receipt. DVTel does not warrant that PRODUCTS are error free. DVTEL does not warrant or guarantee the use or compatibility of the camera with any specific video management software product.

  • Page 7: Limitations Of Liability

    Overview Limitations of Liability With the exception of the terms and conditions stated in this document, DVTEL SHALL NOT BE HELD TO ANY LIABILITY WITH RESPECT TO ANY CLAIM BY CUSTOMER OR A THIRD PARTY ON ACCOUNT OF, OR ARISING FROM, THE USE OF ANY PRODUCT. IN NO EVENT SHALL DVTEL BE LIABLE UNDER...
  • Page 8 Pro Line 9460A User’s Manual...

  • Page 9: Configuration And Installation

    Configuration and Installation The following procedures are performed to configure and set up the mini dome camera: Bench Installation of the Pro Line 9460A Mini Dome Cameras • Configuring the Mini Dome Camera • Site Installation of the Pro Line 9460A Mini Dome Camera •...

  • Page 10: Configuring The Mini Dome Camera

    Figure 2-2: RJ45 Connection Options Configuring the Mini Dome Camera Upon receiving Pro Line 9460A mini dome camera, its basic parameters, such as the IP address, need to be configured. To configure the device, you need the Device Configurator. This application is provided along with the...

  • Page 11: Prerequisites

    Configuring the Mini Dome Camera Parameters When installing Pro Line 9460A mini dome cameras, you have to change their IP address to ensure the compatibility with an existing network. The primary default IP address of the mini dome camera is created using the APIPA addressing scheme and is in the range 176.(a+16).bc.de, based upon the...
  • Page 12 Pro Line 9460A User’s Manual For any other power supply, refer to the manufacturer documentation for the proper wiring scheme. The mini dome camera is powered up as soon as power is provided. Device Configurator Configurator.exe 5. Start the by double-clicking the file or by accessing the iSOC NVSM 5.3 AdminCenter and selecting Pro Line A in the Unified Configurator.

  • Page 13: Site Installation Of The Pro Line 9460A Mini Dome Camera

    Configuration and Installation Site Installation of the Pro Line 9460A Mini Dome Camera After the mini dome camera is configured successfully, it can be installed in its final location. Use the provided mounting template to mark out and create the necessary holes in the mounting surface.
  • Page 14 Pro Line 9460A User’s Manual Recess Mount The Pro Line 9460A units are provided with fold out wings for quick and easy installation into a ceiling without the need for a special mounting kit. To use the fold out wings, turn silver-colored screws clockwise to first extend the locking arms and then tighten them against the mounting surface.

  • Page 15: Surface Mount

    Configuration and Installation Surface Mount You have two options when using the surface ring, it either needs to be mounted before the base is installed (only required if using the 3 addition mounting locations on the surface ring) or you insert the dome housing into the surface ring before mounting with the screw locations shown below.
  • Page 16 Pro Line 9460A User’s Manual Alarm and Audio Connections The Pro Line 9460A provides an accessory cable to easily connect audio input and output, alarm inputs and relay output. Note: The top of the camera is omitted from the picture to clearly show the alarm cable.

  • Page 17: Camera Installation

    Configuration and Installation Table 2-2: Input and Output Wire Setup Wire Color Description Direction / Comment Brown Alarm Input 1 Orange Audio Input Green/White Alarm Ground Orange /White Audio Ground Brown/White Alarm Input 2 Green Audio Output Blue Alarm Output(*) Output 60V AC/DC at 500 mA max Blue/White Alarm Output(*)
  • Page 18 Pro Line 9460A User’s Manual For WDR cameras, the default video standard is NTSC. If PAL video standard is required, connect • the Menu Programming Interface and set to PAL Video Standard under the Video I/O sub-menu. 2. Once you have the gimble secured to the housing, position the camera at the desired angle by rotating the gimble.

  • Page 19: Configuring The I/Os

    Configuration and Installation Bottom view of lid Keyed to fit into base Configuring the I/Os The input/output features on the multipole connector on the back of the device are used for alarms (or events) and audio control. The mini dome camera has two alarm inputs and one relay output terminals.

  • Page 20: Audio

    • between two devices. To activate the audio transmission channel for PTT on the Pro Line 9460A transmitter, you must trigger an activation switch (for example, a button) that is based on the shorting of the ground and input 2 terminals.

  • Page 21: Alarms

    The mini dome camera has two alarm inputs and one relay output terminals. A typical configuration requires you plug an event sensor to the input 1 and ground I/O terminals on the Pro Line 9460A camera, and your alarm system to the Out section of a receiver.
  • Page 22 Pro Line 9460A User’s Manual 2-14...

  • Page 23: Using The Web Interface

    Using the Web Interface You can access the Pro Line 9460A mini dome cameras with a web browser for live viewing, Network, Serial Port and Video configuration. Accessing the Web Interface Device Configurator It is possible to access the web interface via the or directly via a web browser.

  • Page 24: To Access The Web Interface Via A Web Browser

    Pro Line 9460A User’s Manual To access the Web interface via a web browser 1. Start the Internet Explorer. http://IP_address 2. In your Internet Explorer window, enter the IP address of the device using the format. The web browser appears, displaying the home page of the mini dome camera.

  • Page 25: Using The Web Interface

    Using the Web Interface Using the Web Interface Using the web interface, you can view live video and set general, network configuration and video configuration parameters of the displayed mini dome camera. Web Interface Workspace The web interface consists of a navigation pane, video pane and configuration pane. Figure 3-3: Web Interface Workspace The following actions can be performed in the different panes: Navigation Pane —...

  • Page 26: Setting General Parameters

    Pro Line 9460A User’s Manual Setting General Parameters The Home page of the web interface displays the video feed and configurable general parameters of the mini dome camera. To set general parameters 1. On the Home page of the web interface, set the following parameters:...

  • Page 27: Setting Network Configuration Parameters

    Using the Web Interface 5. To disable the digital zoom, select the Disable digital zoom check box. Digital Zoom 6. To close the dialog box, click the Zoom toggle button. Setting Network Configuration Parameters The network configuration parameters of the mini dome camera need to be set to ensure the compatibility with an existing network.

  • Page 28: Setting Serial Port Parameters

    Pro Line 9460A User’s Manual The mini dome camera will reset and the new network configuration parameters will appear. Setting Serial Port Parameters To set Serial Port parameters 1. In the Navigation pane, expand the Serial Ports branch, and then click the relevant serial port node.

  • Page 29: Setting Video Profile Parameters

    Using the Web Interface Setting Video Profile Parameters Set the video profile parameters. To set the Video Profile parameters Navigation 1. On the Home page of the web interface, go to the pane. Video Navigation 2. Expand the branch of the tree, and then select Video Profile.

  • Page 30: Setting Picture Profile Parameters

    Pro Line 9460A User’s Manual Table 3-3: Video Profile Parameters Parameter Description Intra Interval The frequency at which a complete video frame (called I-frame) is sent by the encoder. Possible values are in the 0–100 range. A value of 0 indicates that no I-frame will be sent automatically by the device;...
  • Page 31 Using the Web Interface Picture Profile page appears. Figure 3-8: Picture Profile page 3. Set the following parameters: Table 3-4: Picture Profile Parameters Parameter Description Analog Input Brightness The total amount of light in a color — Possible values range from 0-100 Contrast The range of colors in the image —...
  • Page 32 Pro Line 9460A User’s Manual 3-10...

  • Page 33: Using The Cli

    Using the CLI You can access the command line interface (CLI) of the supported edge device to perform more extensive configurations of the edge device. The CLI is hierarchically organized, with menus, sub- menus, and individual options representing configuration parameters. You access the CLI through Telnet.

  • Page 34: To Access The Cli Via The Telnet Terminal

    Pro Line 9460A User’s Manual To access the CLI via the Telnet terminal Using Microsoft Telnet, click Start—Run. In the command line, enter telnet <host name> • (where host name is the IP address of the device), and press ENTER.

  • Page 35: To Work With The Cli Menu Structure

    ENTER. Depending on the changed settings, the device may perform a soft boot. Setting Serial Port Parameters The Pro Line 9460A supports the RS-232 and the RS-422/485 asynchronous protocols. Using the CLI, you can select the desired protocol for the serial port and set its parameters.

  • Page 36: Setting The Access Management Parameters

    Pro Line 9460A User’s Manual Setting the Access Management Parameters Access management Via the menu, you can define user accounts and device security. User Accounts — By defining user accounts, you can protect the configuration of the device by •...

  • Page 37: Setting The System Status Parameters

    Using the CLI Table 4-2: User Account Parameters Menu Parameter Description Web client 2 user name Enter the new parameter value and press ENTER. Web client 2 password Enter the new parameter value and press ENTER. Web client 2 enable •...

  • Page 38: Setting Network Parameters

    Pro Line 9460A User’s Manual 3. Set the following parameters by selecting the respective menu number and pressing ENTER: Table 4-3: Board Temperature Parameters Menu Parameter Description Critical high temperature limit Enter the new parameter value and press ENTER. High temperature limit Enter the new parameter value and press ENTER.

  • Page 39: Setting The Ethernet Communication Parameters

    Using the CLI Table 4-4: Network Parameters Menu Parameter Description Ping Request Target The IP address of the Ping target Ping Request Send Buffer The size of the ping packet Size Domain Name The name of the domain in which the edge device resides. This parameter is fixed.

  • Page 40: Setting Advanced Parameters

    Pro Line 9460A User’s Manual Setting Advanced Parameters Advanced Using the menu, you can view or set the following parameters: Video, Video Status, Serial Port Status, VSIP, VSIP Statistics, Audio, Test and Debug, Outputs Control, System Time, System Time Stats.
  • Page 41 Using the CLI To select NTSC, type 2 and press ENTER. — 3. When the desired option is selected, type p and press ENTER repeatedly until you reach the Video menu. Video Input Type To display the parameters, type 3 and press ENTER. To select Composite, type 1 and press ENTER.
  • Page 42 Pro Line 9460A User’s Manual Table 4-7: Encoder Parameters Menu Parameter Description Rate Control Mode The mode controlling the bit rate variation. The available modes are: • CBR —The Constant Bit Rate mode is the most effective to maintain the target bit rate. May drop frames rates to maintain the bit rate.

  • Page 43: To Set The Video Status Menu Parameters

    Using the CLI Table 4-8: Video Input Parameters Menu Parameter Description Contrast The range of colors in the image — Possible values range from - 128-127 Enter the new parameter value and press ENTER. Saturation The intensity of the colors in the image — Possible values range from -128-127 Enter the new parameter value and press ENTER.

  • Page 44: To Set The Serial Port Status Parameters

    Pro Line 9460A User’s Manual 5. When the desired option is selected, type p and press ENTER repeatedly until you reach the main menu. 6. Type s and press ENTER to save the changed settings. To set the Serial Port Status parameters...

  • Page 45: To View And Reset The Vsip Statistics Menu Parameters

    Using the CLI Table 4-9: VSIP Parameters Menu Parameter Description VSIP Unit Name The name of the device Enter the new VSIP unit name and press ENTER. • VSIP TCP Heartbeat Enabled — type 1 and press ENTER • Disabled — type 2 and press ENTER Unique Set Identifier Enter the unique ID and press ENTER VSIP Event Monitor IP Address...
  • Page 46 Pro Line 9460A User’s Manual Select the following parameters by typing the respective menu number and pressing ENTER: — Table 4-10: Audio Output Parameters Menu Parameter Description UDP Data Port Destination port where audio is sent Remote IP Address Enter the new remote IP address of the input source and press ENTER Initial Streaming •...

  • Page 47: To View The Test And Debug Menu Parameters

    Using the CLI Sample Rate 5. To set the parameter, type 4 and press ENTER. Type 1 and press ENTER to set the parameter to 8 kHz. — Type 2 and press ENTER to set the parameter to 32 kHz. —...

  • Page 48: To View And Reset The System Time Stats Menu Parameters

    Pro Line 9460A User’s Manual Table 4-12: System Time Parameters Menu Parameter Description NTP Server Poll Period Enter the new NTP Polling Period (in seconds, ranging from 10 to 1000) and press ENTER UTC Time Displays the current universal time and date...
  • Page 49 Using the CLI Video Data Priority — This parameter can either be Routine, Low, Medium, High or — Critical (when TOS is selected) or range from 0-63 (when DSCP is selected). Audio Data Priority — This parameter can either be Routine, Low, Medium, High or —...
  • Page 50 Pro Line 9460A User’s Manual 4-18...

  • Page 51: Factory Default Configuration

    Factory Default Configuration The Pro Line 9460A is programmed at the factory with the following configuration: Table A-1: Factory Default Configuration Type Configuration • Serial port Bit rate: 1000 bauds • Data bits: 8 • Parity: none • Stop bit: 1 •...
  • Page 52 Pro Line 9460A User’s Manual...

  • Page 53: Dhcp Support And Apipa

    IP address. At startup, a mini dome camera searches for a valid IP network configuration. The device requires this configuration prior to starting its functions. The network configuration for the Pro Line 9460A devices consists of: An IP address •...
  • Page 54 Pro Line 9460A User’s Manual...

  • Page 55: Technical Specifications

    Technical Specifications Here are the Pro Line 9460A technical specifications: Table C-1: Technical Specifications Parameter Definition Video Compression MPEG-4 ISO 14496-2 compliant Frame rate Up to 30 frames or 60 fields per second in NTSC (25 frames or 50 fields in PAL),...
  • Page 56 Pro Line 9460A User’s Manual Table C-1: Technical Specifications Parameter Definition Power Supply voltage 12VDC or 802.3af class 3 PoE (48VDC) Consumption 12VDC, 8W, 0.7A | PoE, 9W (class3) Physical Enclosure Metal case with 1/4 inch UNC screw mount Size 7.65”...

  • Page 57: Mpeg License Statement

    MPEG License Statement THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD ("MPEG-4 VIDEO") AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO.
  • Page 58 Pro Line 9460A User’s Manual...
