DVTEL ioimage CP-2202-361P/N User And Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DVTEL INC.
65 Challenger Road
Ridgefield Park, NJ 07660
CP-2202-361P/N
User and Installation Guide
The contents of this guide may
not be reproduced or reprinted
in whole or in part without the
express written permission of
DVTEL, INC.
April 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ioimage CP-2202-361P/N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DVTEL ioimage CP-2202-361P/N

Summary of Contents for DVTEL ioimage CP-2202-361P/N

  • Page 1 DVTEL INC. 65 Challenger Road Ridgefield Park, NJ 07660 CP-2202-361P/N User and Installation Guide The contents of this guide may not be reproduced or reprinted in whole or in part without the express written permission of DVTEL, INC. April 2013...

  • Page 3: Table Of Contents

    Configuring Camera Settings ......................29 5.5.1 Main Page 1 ............................ 29 5.5.2 Main Page 2 ............................ 38 5.5.3 Main Page 3 ............................ 41 Appendix ..............................45 A.1. Technical Specifications ........................46 A.2. Mounting Accessories ........................48 A.3. Troubleshooting ..........................51 Contacting DVTEL ............................ 53...
  • Page 4 CP-2202-361P/N User and Installation Guide List of Figures Figure 1 - XPVA-10D/100D Package Contents .................. 2 Figure 2 - Camera Dimensions ......................4 Figure 3 - Camera Switch Settings ..................... 4 Figure 4 - Camera Dip Switch Settings ....................5 Figure 5 - Camera ID Setting ......................

  • Page 5: Document Information

    This manual and its contents herein are owned by DVTEL, Inc. All rights reserved. DVTEL, the DVTEL logo, ioimage, the ioimage logo, ioimage analytics, ioibox, ioicam, ioiware, ioiware command center, ioiware setup, CP-2202-361P/N, IOI-XTRK-10D, IOI-XTRK-100D, trk1, trk10d, trk100, trk100d, trk-101, trk200, trk4000d, trk8000, mmp100dn, sc1dn-A, XPVA-10D, and XPVA-100D are trademarks of DVTEL, Inc.
  • Page 6 DVTEL, Inc. and its agents make no guarantees or warranties to the suitability for the users’ intended use. DVTEL, Inc. accepts no responsibility for improper use or incomplete security and safety measures.
  • Page 7 Document Information Warning: 1. Do not disassemble the camera or remove screws. There are no user serviceable parts inside the unit. 2. The unit cover is an essential part of the product. Do not open or remove this cover. Never operate the unit without the cover in place. Operating the unit without the cover in place poses a risk of fire and shock hazards 3.
  • Page 8 CP-2202-361P/N User and Installation Guide Caution: To avoid damage from overheating or unit failure, assure that there is sufficient temperature regulation to support the unit’s requirements (cooling/heating). Operating temperature should be maintained within -40° to 122°F (-40° to 50°C), with no more than 80% non-condensing humidity. Minimizing EMI and RFI When wires run for a significant distance in an electromagnetic field, electromagnetic interference (EMI) can occur...

  • Page 9: Introduction

    CP-2202-361P PTZ Camera and IOI-XTRK-100D XPVA-100D-N CP-2202-361N PTZ Camera and IOI-XTRK-100D The camera is configured via the encoder’s web interface. It can be managed by DVTEL’s Latitude Video Management System, as well as by the encoder. 2.1 Features Following are key features of the CP-2202-361P/N PTZ camera when operated with the IOI-XTRK- 10D and IOI-XTRK-100D encoders: ...

  • Page 10: Package Contents

    CP-2202-361P/N User and Installation Guide 2.2 Package Contents Verify that the camera package contains the items listed below. If any item is missing or has defects, do NOT install or operate the product. Contact your reseller or installer for assistance. Dome Camera with System Cable Outdoor Mount Kit...
  • Page 11 Note: The following items are NOT provided with the camera, but are required for installation:  24VAC, 100VA power supply (DVTEL CX-PRWR-241 or equivalent)  75-ohm video coax cable with two female BNC connectors Camera mounting accessories (see ‎ A .2 Mounting Accessories) ...

  • Page 12: Camera Dimensions, Settings And Wiring

    CP-2202-361P/N User and Installation Guide 3 Camera Dimensions, Settings and Wiring This chapter provides the camera dimensions, switch settings, and wiring for reference before installation. 3.1 Camera Dimensions The camera’s dimensions (with the sunshield installed) are shown below. Top View Side View Figure 2 - Camera Dimensions 3.2 Camera Switch Settings...

  • Page 13: Communication Dip Switch Settings

    5 to OFF and reconnect the power. 3.2.2 Camera Control Protocol Switch Verify that the camera control protocol switch is preset to 12 in order to operate with the DVTEL XPVA assembly. This setting should not be changed. 3.2.3 Camera ID Setting Verify that the Camera ID default setting is 001.

  • Page 14: Camera Wiring

    CP-2202-361P/N User and Installation Guide Note: Verify that the encoder is also set to half-duplex communication. 3.3 Camera Wiring The camera is shipped with a system cable that includes a 22-pin connector for attaching the camera to a power supply, the video input on the encoder, and the RS-485 port on the encoder. Attach the connector to the camera, as illustrated below: Figure 6 - 22-Pin Connector on Camera The system cable wiring is as follows:...

  • Page 15: Power Connector

    Camera Dimensions, Settings and Wiring 3.3.1 Power Connector The power output cable from the camera is supplied with a 3-pin power connector. Be sure that the wires are properly inserted in the connector according to the following pin-out: Definition AC 24- Ground AC 24+ To power-up the camera...

  • Page 16: Installation And Mounting

    CP-2202-361P/N User and Installation Guide 4 Installation and Mounting Follow the instructions below for outdoor installation and mounting the CP-2202-361P/N outdoor dome camera. 4.1 Preparation Read the instructions in this chapter thoroughly before installing the camera. Following are additional considerations for outdoor installation: ...

  • Page 17: Ceiling Mounting

    Figure 8 - Straight Tube + Outdoor Mount Kit Items Needed:  Outdoor Mounting Kit (standard with outdoor cameras)  Straight Tube Mounting package (DVTEL Camera Mounting Option available separately)  Screws and screw anchors for fixing the Straight Tube onto the ceiling (not provided) ...

  • Page 18: Figure 9 - Outdoor Mount Kit

    Items Needed:  Outdoor Mounting Kit (standard with outdoor cameras)  Swan Tube Mount package (DVTEL Camera Mounting Option available separately)  Screws and screw anchors for fixing the Swan Tube onto the floor (not provided)  M5 Standard/Security Screw (supplied)

  • Page 19: Figure 11 - Outdoor Mount Kit

    Installation and Mounting Swan Tube Mounting Package Contents:  M8x12 screw x 1  Spring washer-8 x 1  Pendant tube washer x 1  Rubber Washer-8 x 1  Waterproof rubber gasket x 1  Sponge x 2 Tools Required: ...

  • Page 20: Wall Mounting

    Figure 12 - Compact Pendant Mount + Outdoor Mount Kit Items Needed:  Outdoor Mount Kit (standard with outdoor cameras)  Compact Pendant Mounting package (DVTEL Camera Mounting Option available separately)  Screws and screw anchors for fixing the Standard or Compact Pendant Mount (not provided) ...
  • Page 21 Installation and Mounting To install the Standard or Compact Pendant Mount Cut a cable access hole in the wall. If desired, cables can also be threaded through the Cable Entry Board on the Mounting Plate. Attach the Standard or Compact Pendant Mount to the wall using the appropriate screws and screw anchors (not provided).

  • Page 22: Figure 13 - Wall Box Mount + Compact Pendant Mount + Outdoor Mount Kit

     Compact Pendant Mount package (DVTEL Camera Mounting Option available separately)  Wall Box Mount package (DVTEL Camera Mounting Option available separately)  Screws and screw anchors for fixing the Wall Box Mount (not provided)  M5 Standard/Security Screw (supplied) Wall Box Mounting Package Contents: ...

  • Page 23: Corner Mounting

    Installation and Mounting Thread the cables through the Standard/Compact Pendant Mount with the cables coming out of the Pendant Mount’s outlet. Attach the waterproof gasket to the Pendant Mount. After threading the cables, block the entry hole with the supplied sponge to prevent insects from entering.
  • Page 24 CP-2202-361P/N User and Installation Guide Items Needed:  Outdoor Mount Kit (standard with outdoor cameras)  Compact Pendant Mount package (DVTEL Camera Mounting Option available separately)  Corner Standard Mounting Plate/Corner Plate Mini package (DVTEL Camera Mounting Option available separately) ...

  • Page 25: Figure 15 - Corner Thin/Wide Box + Compact Pendant Mount + Outdoor Mount Kit

    Outdoor Mount Kit (standard with outdoor cameras)  Compact Pendant Mount package (DVTEL Camera Mounting Option available separately)  Corner Thin/Wide Box Mount package (DVTEL Camera Mounting Option available separately)  Waterproof rubber screws and screw anchors for fixing the Corner Thin/Wide Box (not provided) ...

  • Page 26: Pole Mounting

    CP-2202-361P/N User and Installation Guide Attach the Standard/Compact Pendant Mount to the Corner Thin/Wide Box using the supplied screws and washers. Thread the cables through the Standard/Compact Pendant Mount with the cables coming out of the Pendant Mount’s outlet. Attach the waterproof gasket to the Pendant Mount. After threading the cables, block the entry hole with the supplied sponge to prevent insects from entering.
  • Page 27 Outdoor Mount Kit (standard with outdoor cameras)  Compact Pendant Mount package (DVTEL Camera Mounting Option available separately)  Pole Thin/Wide Direct Mount package (DVTEL Camera Mounting Option available separately)  Waterproof rubber screws and screw anchors for fixing the Corner Thin/Wide Box (not provided) ...

  • Page 28: Figure 17 - Pole Thin/Wide Box + Compact Pendant Mount + Outdoor Mount Kit

    Outdoor Mount Kit (standard with outdoor cameras)  Compact Pendant Mount package (DVTEL Camera Mounting Option available separately)  Pole Thin/Wide Box Mount package (DVTEL Camera Mounting Option available separately)  Waterproof rubber screws and screw anchors for fixing the Corner Thin/Wide Box (not provided) ...
  • Page 29 Installation and Mounting To install the Compact Pendant Mount with Pole Thin/Wide Box Mount Fasten the Pole Thin/Wide Box Mount to a pole with the supplied stainless straps. Thread the cables through the Pole Thin/Wide Box Mount. Attach the Compact Pendant Mount to the Pole Thin/Wide Box Mount using the supplied screws and washers.

  • Page 30: Configuration And Operation

    CP-2202-361P/N User and Installation Guide 5 Configuration and Operation This chapter describes in detail information about configuring camera settings and operating the camera. This section includes the following information:  Configuring Network Settings  Introduction to Setting up the Camera ...

  • Page 31: Figure 18 - Camera Setup Window

    Configuration and Operation To configure the camera, select Setup > Camera from the Navigation Bar. The Camera Setup window opens. Figure 18 - Camera Setup Window Select Menu. The Main Page On-Screen Display (OSD) menu opens and is overlaid on the image in the Viewer Window.

  • Page 32: On-Screen Display Menu Tree

    CP-2202-361P/N User and Installation Guide 5.3 On-Screen Display Menu Tree Note: Certain functions that are displayed in the camera’s On-Screen Display have been disabled because they are not supported by the IOI-XTRK-10D and IOI-XTRK-100D encoders. These functions are indicated below as NOT SUPPORTED BY ENCODER. The camera’s On-Screen Display includes the following menu tree: PARAMETER LEVEL 1...
  • Page 33 Configuration and Operation PARAMETER LEVEL 1 LEVEL 2 LEVEL 3 DEFAULT AUTO (Auto White Balance) AUTO INDOOR OUTDOOR WBC MODE ATW (Auto-tracing WBC) R GAIN <000> ~ <127> MANUAL B GAIN <000> ~ <127> EXIT + SAVE: YES ZOOM SETUP MENU 1 <8>...
  • Page 34 CP-2202-361P/N User and Installation Guide PARAMETER LEVEL 1 LEVEL 2 LEVEL 3 DEFAULT PRESET SET <001>~<256> ENTER PRESET PRESET RUN <001>~<256> ENTER EXIT ENTER SEQUENCE NOT SUPPORTED BY ENCODER AUTOPAN NOT SUPPORTED BY ENCODER CRUISE NOT SUPPORTED BY ENCODER HOME SETTING NOT SUPPORTED BY ENCODER IR FUNCTION THRESHOLD <MID>, <HI>, <LOW>...
  • Page 35 Configuration and Operation PARAMETER LEVEL 1 LEVEL 2 LEVEL 3 SWITCH <ON>, <OFF> POINT <01> ~ <32> HOUR <00> ~ <23> MINUTE <00> ~ <59> NONE NO FUNCTION NONE PRESET PRESET POINT <001> ~ <256> SEQUENCE NOT SUPPORTED BY ENCODER SCHEDULE MODE AUTOPAN...

  • Page 36: On-Screen Display Control Buttons

    CP-2202-361P/N User and Installation Guide 5.4 On-Screen Display Control Buttons Use the following buttons on the On-Screen Display keypad to select functions in the menu: Note: PC keyboard arrows are not enabled for configuring the On-Screen Display. Menu Click Menu to open the configuration menu. Enter The Enter button provides one of the following functions: ...

  • Page 37: Configuring Camera Settings

    Configuration and Operation 5.5 Configuring Camera Settings The Main Page enables configuration of camera settings. It consists of three screens::  Main Page 1 (page 29)  Main Page 2 (page 38)  Main Page 3 (page 41) 5.5.1 Main Page 1 MAIN PAGE 1 is the default menu page.
  • Page 38 CP-2202-361P/N User and Installation Guide  Manual - In this mode, users can adjust focus near/far via the control keyboard’s Focus Near/Far key.  Auto - Open the submenu to set one of the three options: Normal - In this mode, the camera stays in focus automatically and continuously in any condition.
  • Page 39 Configuration and Operation Manual - In this mode, the brightness is set automatically while three adjustments are possible:  Set shutter speed between 1/10000 ~ 1/50 (PAL) or 1/10000 ~ 1/60 (NTSC)  Set the iris aperture between f/1.6 to f/28 ...
  • Page 40 CP-2202-361P/N User and Installation Guide 5.5.1.7 SETUP MENU 1 Click Enter to open the submenu to configure the following settings: 5.5.1.7.1 ZOOM SPEED Select the zoom speed: SLOW or FAST. The default setting is FAST. 5.5.1.7.2 MAX. DIGI. ZOOM (Maximum Digital Zoom) Set the maximum digital zoom to OFF or select between the range of 2x-12x.
  • Page 41 Configuration and Operation 5.5.1.7.3 SLOW SHUTTER A slow shutter speed exposes the image sensor to more light in a dark environment, but blurs motion. A faster shutter speed is recommended where there is plenty of light or for tracking fast moving objects.
  • Page 42 CP-2202-361P/N User and Installation Guide 5.5.1.7.5 IMAGE INVERSE Select ON to enable this feature or OFF to disable it. The default setting is OFF. Selecting ON vertically and horizontally inverts the displayed image, displaying it so that the image is not upside down (see the figures shown below).
  • Page 43 Configuration and Operation 5.5.1.7.9 EXIT When YES is flashing, click Enter to exit this submenu and to return to MAIN PAGE 1. To continue to SETUP MENU 2, click the Down arrow. 5.5.1.8 SETUP MENU 2 Click Enter to open the submenu to configure the following settings: 5.5.1.8.1 FLIP An object can be tracked continuously when it passes under the camera and this setting is set to Image or M.E.
  • Page 44 CP-2202-361P/N User and Installation Guide 5.5.1.8.2 ANGLE ADJUSTER Click Enter to open the submenu to adjust the range of the tilt angle. Select the tilt motion range according to the flip mode:  MIN ANGLE: -10° to +10°. The default is 00. ...
  • Page 45 Configuration and Operation To enter the password  Select a digit by moving the Left or Right arrow to move the cursor.  Click Enter on the On-Screen Display. After each entry, an ‘X’ is displayed instead of a dash. Note: To delete a digit, move the Down arrow until DELETE is flashing in the PASSWORD window.

  • Page 46: Main

    CP-2202-361P/N User and Installation Guide 5.5.1.8.6 OSD AUTO CLOSE Specify whether to utilize the auto-close feature for the On-Screen Display, or select the duration (30, 60, 90, 120, 150, or 180 seconds) to display the OSD menu on screen.  Select ON to enable this feature.
  • Page 47 Configuration and Operation 5.5.2.3 TITLE DISPLAY Use this function to create a name for a zone and to display the title on screen.  Select ON to display a zone title on screen while the camera monitors the zone.  Select OFF to disable displaying a title on screen.
  • Page 48 CP-2202-361P/N User and Installation Guide 5.5.2.5 PRESET Up to 256 preset points can be set and run, of which up to 32 can function with video analytics activated. The actual number of preset points depends on user settings. Click Enter to open the PRESET submenu. To set a Preset ...

  • Page 49: Main

    Configuration and Operation 5.5.2.8 CRUISE THIS FUNCTION IS NOT SUPPORTED BY THE ENCODER. 5.5.2.9 HOME SETTING THIS FUNCTION IS NOT SUPPORTED BY THE ENCODER. 5.5.3 Main Page 3 This menu enables configuration of the following settings: 5.5.3.1 IR FUNCTION The camera uses the IR cut filter to capture a clear image at nighttime or in low light conditions. Its internal light algorithm automatically removes the IR cut filter according to the image brightness level.
  • Page 50 CP-2202-361P/N User and Installation Guide When YES is flashing, click Enter in order to return to MAIN PAGE 5.5.3.2 ALARM SETTING THIS FUNCTION IS NOT SUPPORTED BY THE ENCODER. 5.5.3.3 ALARM DETECT THIS FUNCTION IS NOT SUPPORTED BY THE ENCODER. 5.5.3.4 WDR FUNCTION The Wide Dynamic Range (WDR) function resolves high contrast or changing light issues in order to...
  • Page 51 Configuration and Operation 5.5.3.7 SCHEDULE The schedule function is for programming a preset point or function to be executed automatically at a specific time. The following settings are available:  SWITCH - Select ON to enable or OFF to disable the schedule function. ...
  • Page 52 CP-2202-361P/N User and Installation Guide  IR FUNC. (IR Function) - Select the IR FUNCTION mode if you want to schedule use of the infrared function at nighttime or when there are low-light conditions. Note: If you select IR FUNC, IR FUNCTION is displayed in the following line. Options are AUTO, ON, and OFF.

  • Page 53: Appendix

    Appendix Appendix The Appendix contains the following sections:  Technical Specifications (page 46)  Mounting Accessories (page 48)  Troubleshooting (page 51)

  • Page 54: Technical Specifications

    CP-2202-361P/N User and Installation Guide A.1. Technical Specifications Following are the CP-2202-361P/N technical specifications: Camera Camera Type Pan/Tilt/Zoom Image Sensor ¼" Sony CCD Horizontal Resolution 650 TVL (PAL and NTSC) Effective Pixels 570k (PAL)/480k (NTSC) Optical/Digital Zoom 36x optical zoom/1x-4x variable digital zoom Lens Type f/1.6 to f/3.8 Focal Length...
  • Page 55 Appendix PTZ Operation (continued) Manual Speed 0.5° ~ 90°/second 256 without analytics/up to 32 with analytics (number Presets depends on settings) Preset Speed 5° ~ 400°/second Preset Accuracy 0.225° Proportional Pan & Tilt On/Off (pan and tilt speed proportional to zoom ratio) Analog Video Output TV Standard PAL or NTSC...

  • Page 56: Mounting Accessories

    CP-2202-361P/N User and Installation Guide A.2. Mounting Accessories The following mounting accessories are available from DVTEL for installation of your PTZ camera. For more information on available options, contact your DVTEL sales representative or visit www.DVTEL.com to request details on where to get the accessories you need.
  • Page 57 Appendix PART NUMBER ITEM CX-PIPE-0 Straight Tube (25 cm) Iron; Height: 250/500 mm (9.8/19.7 inches); Diameter: 50 mm (2 inches) 1 kg (2.2 lbs.)/1.8 kg (4 lbs.). Supplied with M8 x 12 screw x 1, spring washer-8 x 1, pendent tube washer x 1, rubber washer-8 x 1 and waterproof rubber x 1.
  • Page 58 CP-2202-361P/N User and Installation Guide PART NUMBER ITEM CX-CRNR-0 Corner Standard Mounting Plate 222 × 204 × 117 mm (8.7 × 8 × 4.6 inches); 2 kg (4.4 lbs.). Supplied with washer-8 x 4, spring washer-8 x 4, M8 x 16 screw x 4, and M8 nut x 4. CX-POLE-0 Pole Thin Direct Mounting 232 ×...

  • Page 59: Troubleshooting

    The unit IP address is in Change the unit IP address after connecting to it directly (not use by another through the system network) by using the DVTEL Configurator computer (collision) application. For instructions, refer to the XPVA-10D/100D Installation Guide.
  • Page 60 CP-2202-361P/N User and Installation Guide Problem Possible Solution  Bad output video quality Connect an analog monitor to the camera. If video quality is acceptable, connect the camera to the encoder.  Check that the cables are connected securely. This includes junction boxes and amplifier that may be used.

  • Page 61: Contacting Dvtel

    Mobile: +86-13501266857 Fax: +86-10-85868815 To request the latest versions of firmware and software or to download other product-related documents, visit http://www.dvtel.com/support. If you have obtained a login, go to our support gateway. For assistance, email us at support@dvtel.com or phone 1-888-DVTEL77.
