Summary of Contents for Russell Hobbs RHSLDW1
- Page 1 Slimline Dishwasher Instruction Manual Model Number: RHSLDW1 Please read these instructions carefully and keep them for future reference For Customer Services, Spare Parts & Manufacturer’s Warranty Information, please call 01204 664 084 Opening times: Monday – Friday 9am – 5pm...
-
Page 2: Table Of Contents
Contents Components ......................4 Control Panel ......................5 Technical Specification ................... 6 EC declaration of conformity ................... 6 Safety Information ....................6 Recycling ........................ 6 Safety information ....................7 When installing your machine ................. 7 Daily Use ........................ 7 Items not suitable for dishwashing ................8 Installing the machine .................... - Page 3 Upper Basket ..........................17 Incorrect Loads ..........................17 Standard Loading ....................18 Capacity ........................ 18 Programme Options ....................19 Using the machine ....................20 Switching on the machine ..................20 Selecting a programme ..................20 Monitoring your wash cycle .................. 20 Changing a programme ..................
-
Page 4: Components
Components 1. Worktop 7. Rating Plate 2. Upper Basket 8. Control Panel 3. Upper Spray Arm 9. Detergent and rinse aid dispenser 4. Lower Basket 10. Cutlery Basket 5. Lower Spray Arm 11. Salt Dispenser 6. Filters 12. Upper Basket Track Latch For Customer Services, Spare Parts &... -
Page 5: Control Panel
Control Panel 1. Power on/off When the power on/off button is pressed, the light on the Start/Pause button will illuminate. 2. Door Handle The door handle is used to open/close the door. 3. Start/Pause Button Once you press the Start/Pause button, the programme you selected with the selector button will start running and the indicator lamp ‘wash/dry’... -
Page 6: Technical Specification
Technical Specification Capacity 10 Place Settings Height 845mm Width 450mm Depth 598mm Net Weight 40 Kg Electricity Input 220 - 240 V, 50 Hz Total Power 1900 W Heating Powee 1800 W Pump Power 100 W Drain Pump Power 30 W Water Supply 0,03MPa (0,3 bar) - 1MPa (10) Pressure... -
Page 7: Safety Information
Safety information When you receive your machine, check for damage to the packaging and unit. Never start a machine that is damaged. Contact 01204 664 084 for advice if your machine is received in a damaged state. When installing your machine Ensure you choose a suitable, safe and level place to install your machine. -
Page 8: Items Not Suitable For Dishwashing
Children should not use this machine as this may result in injury. Items not suitable for dishwashing Do not allow cigarette ashes, candle remains, polish, chemical substances to enter the dishwasher. Cutlery with bone, ivory or nacre coated handles, glued items or items soiled with abrasive chemicals. -
Page 9: Water Connection
Ensure that the water inlet hose does not become compressed while positioning the machine. Also, make sure that the machine does not stand on the electrical cable. Ensure the machine is level when placed on the surface. Adjust the feet by twisting clockwise to raise the height of the machine, and anti-clockwise to reduce the height of the machine. -
Page 10: Electrical Connection
Electrical Connection The earthed plug of your machine should be connected to an earthed outlet supplied by a suitable voltage and current. Ensure a qualified engineer is appointed to install the machine to ensure that the machine is correctly earthed. If the machine is installed and not properly earthed, the warranty will be void. -
Page 11: Before Using The Machine
Before using the machine Water To maximise cleaning quality, the machine requires soft water – ie low calcareous water. Lime scale may form on dishes and the interior of the machine in hard water areas. This will reduce the performance of the machine. Filling with salt Use softener salt specifically produced for dishwashers –... -
Page 12: Testing Strip
Testing Strip The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in the mains water supply. To find out the hardness of water in your area, contact your local water board who can determine the hardness of water in your area using a testing strip. -
Page 13: Adjusting Salt Consumption
Adjusting salt consumption Water Hardness British Hardness Hardness Level Indicator Level Wash/Dry Lamp is on 0 - 6 End lamp is off Start/Pause Lamp is off Wash/Dry Lamp is on 7 - 14 End lamp is off Start/Pause Lamp is off Wash/Dry Lamp is on 15 - 21 End lamp is off... -
Page 14: Detergent Use
After switching the programme dial to 0, press the Start/Pause button and hold it down. While the start button is held down, press the On/Off button to switch the machine on (2). Keep Start/Pause keys held down until the monitor lights illuminate (2). After lights ‘Wash/Dry/End’... -
Page 15: Combined Detergents
heavily soiled items, pour a small amount (5cm³) into the prewash section of the tablet dispenser (a). Combined Detergents Detergent manufacturers also manufacture combined detergents that are called ‘2 in 1’, ‘3 in 1’ and ‘5 in 1’. This dishwasher is suitable for for use of 3 in 1 or less only and must be used on a setting of 65°C or more. -
Page 16: Loading Your Dishwasher
Loading your dishwasher Ensure dishes are placed in the machine with sufficient space for water to flow around the dishes. This will allow optimum energy efficiency. There are two baskets provided with this machine, the upper basket is designed for cups, glasses, shallow dishes and tea plates. -
Page 17: Examples Of Loading
Examples of loading Lower Basket Upper Basket Incorrect Loads For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084 -17-... -
Page 18: Standard Loading
Standard Loading Capacity Upper and lower baskets: 10 place settings. The upper basket should be adjusted to the lower position. For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084 -18-... -
Page 19: Programme Options
Programme Options... -
Page 20: Using The Machine
Using the machine Switching on the machine To switch on the machine, press the ‘On/Off’ button Selecting a programme To select a programme, twist the programme knob to the desired position Monitoring your wash cycle You can monitor the progress of the wash cycle by using the programme follow up bulbs. -
Page 21: Switching The Machine Off
Switching the machine off To switch the machine off after a cycle, wait until the finish light is illuminated (lower LED). Then press the ‘On/Off’ button. Important information Once a wash cycle has finished, the drying process can be sped up by opening the machine door slightly. -
Page 22: Maintenance And Cleaning
Maintenance and cleaning Cleaning the machine regularly will prolong the machines service life. Oil and lime accumulation If oil and lime accumulate in the machine, run the machine empty while ensuring the use of a dishwasher tablet/detergent. Machine door seal Use a damp cloth to wipe residues on the door seals regularly. -
Page 23: Spray Arms
filter and line up the corresponding markings. Lock the micro filter into the metal/plastic filter and turn in the direction of the arrow (4) . - Never use the dishwasher without the filter present. Incorrectly fitting the filter will reduce the washing effectiveness of the machine. Spray arms Always check the spray arm water outlet to ensure they are not clogged. -
Page 24: Programme Monitor Light Is On And Start/Pause Light Is Flashing
Error Codes Programme monitor light is on and Start/Pause light is flashing Your machine door is open. Shut the door. The programme won’t start Check the machine is plugged in. Check the indoor fuses. Ensure the water inlet hose is turned on. Ensure the machine door is closed. -
Page 25: Control Lamps Illuminated After Cycle Has Finished
Control lamps illuminated after cycle has finished The ‘On/Off’ button has not been released. Detergent residues are left in the detergent compartment Detergent has been added when the detergent compartment is wet. Wipe dry the detergent compartment before using the machine again. Water will not drain The water drain hose is clogged or twisted. -
Page 26: Dishes Won't Dry
Not enough detergent is being used. Rinse aid setting is too low. Salt is needed due to hard water Water softener setting at low level. Salt compartment cap not closed properly. Dishes won’t dry A programme without a dry operation has been selected. Rinse aid dosage set too low. - Page 27 For manufacturer’s warranty information please call 01204 664 084 Opening times: Monday - Friday 9am until 5pm Saturday: 9am – 1pm Alternatively, write to the following address: PO Box 2235 Bolton BL6 9AJ Revision 3 This symbol is known as the 'Crossed-out wheelie bin Symbol'. W hen this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
