- Page 1 45cm Wide Built In Dishwasher Instruction Manual Model number(s): RH45BISLDW2-M For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety instruction ………………………………………. Water & electrical connection ………………………………………. Disposal of old electrical appliances ………………………………………. Saving energy & water ………………………………………. Unpacking the dishwasher ………………………………………. Product overview ………………………………………. Control panel ………………………………………. 10-11 Pre-Installation ………………………………………. Water Hardness & setting the salt ………………………………………. 12-13 Loading the salt into the container ………………………………………. -
Page 3: Safety Instruction
Safety Instructions The appliance was designed and manufactured in compliance with current international safety standards. The following information has been provided for safety reasons and should therefore be read carefully. Keep this instruction manual in a safe place for future reference. If the appliance is sold, given away or moved, please ensure the manual is kept with the machine, so that the new owner may benefit from the advice contained within it. - Page 4 Safety Instructions • If your family includes children: • Keep detergents and rinse aids away from children. • Keep children away from the open door of a dishwasher, there could still be some detergent left inside. • Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door very carefully if the dishwasher is operating, there is a risk of water squirting out.
-
Page 5: Water & Electrical Connection
Water and Electrical Connection Important note: Connection to the water and electricity supplies should only be performed by a qualified technician. Electrical Connection Before inserting the plug into the electrical socket, make sure that: • The socket is earthed and complies with current regulations; •... -
Page 6: Disposal Of Old Electrical Appliances
Water and Electrical Connection • Tap connections*: A range of adaptors are available to suit your tap. • DO NOT connect the dishwasher to a single outlet instantaneous water heater or an electric heater. • It MUST NOT be connected to a surface water drain. •... -
Page 7: Saving Energy & Water
Saving water and energy • Only start a wash cycle when the dishwasher is full. • While waiting for the dishwasher to be filled, prevent unpleasant odours with the Rapid Wash. • Select a wash cycle that is suited to the type of dishes/crockery and to the soil level of the dishes/crockery using (see the washing program section): - for dishes with a normal soil level, use the Eco wash cycle, which guarantees low energy and water consumption levels. -
Page 8: Unpacking The Dishwasher
Unpacking the appliance 1. Remove the appliance from all packaging and check that the product has not been damaged during transportation. If it has been damaged, contact the manufacturer or the retailer and do not proceed any further with the installation process. Below are key areas to check: •... -
Page 9: Product Overview
Product Overview Front view Rear view Upper basket 10. Drain pipe Inner pipe 11. Power cord Lower basket 12. Inlet pipe connector Salt aid container 13. Adjuster Detergent dispenser 14. Cutlery basket Control panel 15. Salt funnel Mug shelf 16. Installation accessories (please see Spray arms installation section) Filter... -
Page 10: Control Panel
Control Panel 1. On/off button 5. Salt aid warning & rinse aid warning indicator lights (when these are 2. Time delay button shown they need refilling) 3. On/off indicator light 6. Program indicator lights 4. Time delay indicator lights (3 7. - Page 11 Control Panel Half load button Press to select half load function (press after selecting the required program but prior to closing the door of the appliance). This function should only be used when 6 or less place settings have been loaded in to the appliance and require washing.
-
Page 12: Pre-Installation
Pre-Installation Important Note: Prior to installation and first use the following 4 steps must be followed, failure to do so will void your guarantee: 1. Set the water softener level 2. Add 1.5kg dishwasher salt and fill the salt container with water 3. -
Page 13: Loading The Salt Into The Container
Water Hardness & Setting the Salt Note: The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will form on the dishes and utensils. The appliance is equipped with a special softener that uses a salt container specifically designed to eliminate lime and minerals from the water. -
Page 14: Rinse Aid Dispenser
5. Usually, the salt warning indicator light will stop being illuminated within 2-6 days after the salt container has been filled 6. Immediately after filling the salt into the salt container, a washing program should be started (We suggest to use the Quick or rapid programs) Otherwise the filter system, pump or other important parts of the machine may be damaged by salty water. - Page 15 When to Refill the Rinse Aid Dispenser There is a rinse aid warning indicator light in the control panel which will light when there is no or little rinse aid in the rinse aid dispenser. 1. To open the dispenser, lift the cover with cover handle. 2.
-
Page 16: Detergent
Rinse Aid Dispenser The rinse aid dispenser has 5 settings. Please follow the steps below for adjustment in rinse aid level: 1. Open the door and switch on the appliance. 2. Within 60 seconds after the appliance was switched on press and hold the ‘Program’ button for more than 5 seconds and then press the ‘Delay’... - Page 17 Detergent Normally new pulverised detergent is without phosphate. Thus the water softener function of phosphate is not given. In this case we recommend to fill salt in the salt container even when the hardness of water is only 7*clarke. If detergents without phosphate are used in the case of hard water often white spots appear on dishes and glasses.
- Page 18 Detergent Detergent Dispenser The detergent dispenser is located on the inside of the dishwasher door and is approximately halfway up the door. The dispenser can be filled with either detergent powder or a detergent tablet in compartment A, Filling the Detergent Dispenser Note: observe the dosing and storage recommendations that are stated on the detergent packaging.
- Page 19 Detergent 2. Fill the detergent dispenser with the correct amount of detergent powder in compartment A or 1 detergent tablet in compartment B. If the dishes are heavily soiled, place an additional detergent dose in compartment B, this detergent will take effect during the pre-wash phase (this is not required if using a detergent tablet).
-
Page 20: Loading The Dishwasher
Loading the Dishwasher Notes: • Only purchase and wash utensils which are identified as dishwasher safe. • Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. • For particular items, select a program with as low a temperature as possible. •... - Page 21 Loading the Dishwasher d. All utensils are placed in the way that the spray arms can rotate freely during washing. e. Load hollow items such as cups, glasses, pans etc. with the opening facing downwards so that water cannot collect in the container or a deep base. f.
- Page 22 Loading the Dishwasher Loading the Upper Basket The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty).
- Page 23 Loading the Dishwasher Adjustable Upper Basket Height The height of the upper basket can be adjusted in order to create more space for large dishes/crockery/utensils for both the upper/lower basket. The factory setting for the upper basket is set at the highest setting so there is more space for larger dishes/crockery/utensils for both lower basket height.
- Page 24 Loading the Dishwasher Cutlery Basket Cutlery should be placed in the cutlery basket with the handles at the bottom, except for knives and other utensils with sharp points must be loaded in the basket with their points down or placed in a horizontal position. If the rack has side baskets, the spoons should be loaded separately into the appropriate slots.
-
Page 25: Washing Programs
Washing Programs... -
Page 26: Washing Cycles
Washing Cycles Turning on the appliance Starting the wash cycle 1. Pull out the lower and upper basket, load the dishes and push them back. It is recommended to load the lower basket first, then the upper one (see the loading the dishwasher section). 2. - Page 27 Washing Cycles Half load In case you do not have enough dishes for a full load, the half load option can be selected with certain programs (please see the Wash Program section). Please follow the steps below: 1. Open the dishwasher door, load your soiled dishes/crockery and add detergent. 2.
-
Page 28: Installation
Installation • This appliance can be installed as a built in unit only. • We recommend that 2 people handle the dishwasher during installation. • Avoid damaging the product during installation, positioning of the appliance requires two people in order to avoid injuries or damage to the appliance. •... - Page 29 Installation The aperture size has to be a minimum of (H)820 x (W)450 x (D)580mm. The cabinet in which the appliance is housed in must have a electrical, drain and water supply line entrances of (W)80 x (D)100mm. The dishwasher dimensions are (H)815mm x (W)448mm x (D)550mm The minimum space required for the door to be opened is 50mm:...
- Page 30 Installation The dishwasher must be level to ensure correct closure and sealing of the door. When the unit is correctly levelled, the door should not catch the inner liner on either side of the cabinet. The adjustable feet may be loosened or tightened in order to obtain the optimum levelling of the unit.
- Page 31 Installation Position the dishwasher next to a water tap and a drain. Ensure the water inlet and drain hoses are not kinked or squashed. The unit must not stand on the mains cable. Note: The appliance must be moved into position by hand Tape the supplied door template (accessory 11) to the rear of the wooden cabinet door or panel.
- Page 32 Installation Install the wooden cabinet door or panel onto the dishwasher door by following the steps. Ensure the wooden cabinet door or panel weight is a minimum of 3kg and a maximum of 6kg. Note: You may need to fix the handle of the wooden cabinet door prior to fixing the wooden cabinet door to the dishwasher door Install the top hob hooks (accessory 8) and lower hooks (accessory 4) on to the wooden cabinet door or panel with ST3.5 x 25 screws (accessory 3) and ST3 x 14 screws (accessory 1).
- Page 33 Installation After the wooden cabinet door or panel is installed, the tension of the dishwasher door spring can be adjusted by rotating the adjusting bolt. If the tension is right, the door will remain horizontal in the fully open position and will move to a nearly closed position when the door is raised slightly from the horizontal position.
- Page 34 Installation To secure the dishwasher to under the counter top and to the side cabinets, fix the screws ST4 x 14 with the 2 securing brackets (accessories 1 and 7) to the underside of the counter top and fix screws ST3.5 x 16 (accessory 5 ) to the adjacent wooden cabinets and cover with the screw covers/caps (accessory 9) Optional: To secure the dishwasher to plinth fix the plinth fixing bracket (accessory 10) with the screws ST4 x 14 with (accessory 1).
-
Page 35: Drain Hose Connection
Connection of the Water Supply & Drain Hose Important notes: • Connection to the water and electricity supplies should only be performed by a qualified technician. • The dishwasher should not stand on top of the water hoses or the electricity supply cable. -
Page 36: Water Connection
Connection of the Water Supply & Drain Hose Connection of the Water Supply Important note: Before attaching the water inlet hose, run the water until it is perfectly clear so that any impurities that may be present in the water do not clog the appliance. This precaution is needed to avoid the risk of the water inlet getting blocked and damaging the appliance. -
Page 37: Maintenance & Cleaning
Maintenance & Cleaning Filtering System The filter prevents larger remnants of food or other objects from getting inside the pump. The residue may block the filter, in this case they must be removed. The filter system consists of a coarse filter, a flat (Main filter) and a micro filter (Fine filter). 2) Coarse Filter Larger items, such as pieces of bones or glass, that could block the drain are trapped... - Page 38 Maintenance & Cleaning To remove the filter device, twist the coarse filer (part 2) and pull it in a upwards direction. All parts of the filter will lift away from the bottom of the appliance 1. Turn the coarse filter (part 2) in anti-clockwise direction, then pull it in a upwards direction 2.
- Page 39 Maintenance & Cleaning Cleaning the door Important note: Never use a spray cleaner to clean the door panel as it may damage the door lock and electrical components. Abrasive agents or some paper towels should not be used because of the risk of scratching or leaving spots on the stainless steel surface.
- Page 40 Maintenance & Cleaning 1. Cut off the electrical power to the dishwasher. 2. Turn off the water supply and disconnect the water inlet pipe from the water valve. 3. Drain the water from the inlet pipe and water valve. (Use a bowl to catch the water) 4.
- Page 41 Maintenance & Cleaning No Solvents or Abrasive Cleaning To clean the exterior and rubber parts of the dishwasher, do not use solvents or abrasive cleaning products. Only use a cloth with warm soapy water. To remove spots or stains from the surface of the interior, use a cloth dampened with water and a little vinegar, or a cleaning product made specifically for dishwashers.
-
Page 42: Trouble Shooting
Trouble Shooting Problem Causes Solution Make sure the power cord is properly plugged into the wall socket. Power supply is not turned Make sure the dishwasher is turned on and the door is closed securely. Replace fuse or reset circuit breaker. Remove Fuse blown, or the circuit any other appliances sharing the same circuit breaker acted... - Page 43 Trouble Shooting Problem Causes Solution Use only the dishwasher detergent to avoid suds. If this occurs, open the dishwasher and let suds evaporate. Pour 1 gallon of cold water to the tub, then close the dishwasher and select any cycle. Improper detergent The first part of the cycle will see the Suds in the tub...
- Page 44 Trouble Shooting Problem Causes Solution Arrange the dishes correctly or wash in 2 Dishwasher has been separately loads, please see the Loading the overloaded Dishwasher section. The dishes were not loaded Arrange the dishes correct, please see the correctly Loading the Dishwasher section. The program was not Select a more intensive program, please see the powerful enough...
- Page 45 Trouble Shooting Problem Causes Solution Load the dishwasher as suggested in the Improper loading directions. Increase the amount of rinse-aid and/or refill Too little Rinse-aid the rinse-aid dispenser. Do not empty your dishwasher immediately after washing cycle has ended. Open the door slightly so that the steam can escape.
-
Page 46: Connection To The Mains Supply
Connection to the Mains Supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC220V - 240V; 50HZ. Check that the voltage marked on the product corresponds with your supply voltage. For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which... -
Page 47: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Product Care. -
Page 48: Technical Specification
Technical Specification Model number RH45BISLDW2-M Rated Voltage 220V – 240V ~ 50Hz Capacity 9 place settings External Dimensions(HxWxD) 815mm x 448mm x 550mm... -
Page 49: Notes
Notes... - Page 50 Notes...
- Page 51 Notes...
- Page 52 For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste. Only discard electrical/electronic/battery items in separate collection schemes, which cater for the recovery and recycling of materials contained within.
