Installation Daily use Electrical connection Cooking tables Environmental concerns Cleaning and maintenance IKEA GUARANTEE Safety Information Your safety and that of others are very The power cable must be long enough important for connecting the appliance, once This manual and the appliance itself provide fi...
Page 4
ENGLISH During and after use, do not touch the Scrapping of household appliances heating elements or interior surfaces This appliance is manufactured with of the appliance - risk of burns. Do not recyclable or reusable materials. allow the appliance to come into contact Dispose of it in accordance with local with cloths or other fl...
ENGLISH Product description Control panel Rear oven lamp Cooling fan (not visible) Oven fan Upper heating element Circular heating element (not visible) Grill heating element Oven door Accessories Baking tray Grill Pan Set Wire Shelf...
ENGLISH Control panel Function selector knob Thermostat knob Cooking time selector Thermostat indicator light (red) Daily use How to operate the oven • Turn the selector knob to the required function. The oven light switches on. • Turn the thermostat knob clockwise to the required temperature.
Page 7
ENGLISH Oven functions table Function Description of function OVEN OFF LIGHT To switch on the oven light. GRILL To grill steak, kebabs and sausages, to cook vegetables au gratin and to toast bread. Preheat the oven for 3 - 5 min. Place food on the 4th shelf.
ENGLISH Cleaning and maintenance CLEANING Accessories • Soak the accessories in water with WARNING! washing up detergent immediately after Never use steam cleaning equipment. use, handling them with oven gloves if Only clean the oven when it is cool to still hot.
Page 10
(see note for lamp type) and screw the lamp cover back on. 3. Reconnect the oven to the power supply. NOTE: Only use 25-40W/230V type E-14, T300°C incandescent lamps. Lamps are available from IKEA After Sales Fig. 3 Service. Fig. 4...
“What to do if ...” table. If any repairs are required, please contact 2. Switch the appliance off and back on IKEA After Sales Service (to guarantee that again it to see if the fault persists. original spare parts will be used and repairs If after the above checks the fault still occurs, carried out correctly).
ENGLISH Technical data Dimensions Width Height Depth Usable volume l Area of largest baking sheet (net surface) cm 1200 Circular heating element W 2000 Grill W 2450 Cooling fan W Oven lamp W Total rating W 2300 Number of functions Energy consumption kWh 0.79 The technical informations are situated in the rating plate inside the appliance.
ENGLISH Installation After unpacking the oven, make sure that During use it has not been damaged during transport Do not place heavy objects on the door and that the oven door closes properly. In as they could damage it. the event of problems, contact the dealer or Do not cling to the door or hang your nearest After-sales Service.
Page 14
ENGLISH Door lock device To open the door with the door safety device see Fig 1. Fig. 1 The door safety device can be removed by following the sequence of images (see Fig. 2). Fig. 2...
1,5 mm ) must be carried out by a qualifi ed the mains voltage. The rating plate is on electrician. Contact IKEA After Sales Service. the front edge of the oven (visible when the door is open). Environmental concerns...
IKEA fi ve (5) years guarantee? • Consumable parts including batteries and The range of appliances named LAGAN and lamps. all appliances purchased in IKEA before 1st of • Non-functional and decorative parts which August 2007. do not affect normal use of the appliance,...
Page 17
IKEA appliance in the dedicated IKEA However, if an IKEA appointed Service kitchen furniture; Provider or its authorized service partner • ask for clarifi cation on functions of IKEA repairs or replaces the appliance under appliances. the terms of this guarantee, the appointed...
Page 18
PORTUGAL Åbningstid: Mandag - fredag 9.00 - 21.00 Telefone: 21316401 1 Lørdag 9.00 - 18.00 Tarifa: Tarifa local (Åbent udvalgte søndage, se IKEA.dk) Horário: Segunda - Sexta 9.00 - 21.00 DEUTSCHLAND REPUBLIC OF IRELAND Telefon-Nummer: 06929993602 Phone number: 016590276 Tarif:...
