Summary of Contents for IKEA DYNAMISK
- Page 1 DYNAMISK...
- Page 3 ENGLISH...
-
Page 4: Table Of Contents
Technical data First use Installation Daily use Environmental concerns Helpful hints and tips IKEA GUARANTEE Care and cleaning Subject to change without notice. Safety instructions In the interest of your safety and to ensure • If this appliance featuring magnetic door... - Page 5 ENGLISH If the refrigerant circuit should become • Do not store flammable gas and liquid in damaged: the appliance, because they may ex- – avoid open flames and sources of igni- plode. tion • Do not place food products directly –...
- Page 6 ENGLISH • It is advisable to wait at least four hours Environment Protection before connecting the appliance to allow This appliance does not contain gasses the oil to flow back in the compressor. which could damage the ozone layer, in ei- •...
-
Page 7: Product Description
ENGLISH Product description Carefully read the operating instructions before using the appliance. Vegetable drawer Low-temperature-compartment Glass shelves No-Frost-cooling Bottle rack Control panel Butter shelf Door shelves Bottle shelf Freezer baskets Rating plate... - Page 8 ENGLISH Display Freezer Compartment button Bottle Chill button and Appliance ON/ Mode button OFF button It is possible to change predefined sound of buttons to a louder one by pressing togeth- Temperature colder button er the Mode button and Temperature cold- Temperature warmer button er button for some seconds.
- Page 9 ENGLISH Switching off Extra Humidity Mode To switch off the appliance do these steps: If you need to increase the humidity in the 1. Press the bottle symbol for 3 seconds. refrigerator, we suggest activating the Extra 2. The display switches off. Humidity function.
- Page 10 ENGLISH To switch on the function: To switch on the function: 1. Select the fridge compartment. 1. Press the Bottle Chill button. 2. Press the Mode button until the corre- The Bottle Chill indicator appears. sponding icon appears. The Timer shows the set value (30 mi- The fridge temperature indicator shows nutes).
-
Page 11: First Use
ENGLISH • flashing the alarm and freezer tempera- Door open alarm ture indicators An acoustic alarm will sound after approxi- • sounding of buzzer. mately 5 minutes if the door is left open . To reset the alarm: The door open alarm conditions are indica- 1. - Page 12 ENGLISH The freezer drawers ensure that it is quick Freezer blocks and easy to find the food package you want. If large quantities of food are to be stored, remove all drawers except for the bottom drawer which needs to be in place to provide good air circulation.
- Page 13 ENGLISH To make these adjustments proceed as fol- No-Frost Cooling lows: gradually pull upwards the shelf until it comes free (1), remove it by pushing to- wards inside (2), then reposition as re- quired. Bottle rack Place the bottles (with the opening facing front) in the pre-positioned shelf.
- Page 14 ENGLISH To switch on the Fresh Zone Mode: To switch on the function: 1. Switch on the Shopping function. (see 1. Remove or place upward the low-tem- on page 9. ) perature-compartment drawer and put 2. The Shopping indicator comes on. the bottle rack in front of the QuickChill 3.
-
Page 15: Helpful Hints And Tips
ENGLISH Ice-cube production 2. Put the tray in the freezer compartment This appliance is equipped with one tray for Important! Do not use metallic instruments the production of ice-cubes. to remove the tray from the freezer. 1. Fill the tray with water. Helpful hints and tips Normal Operating Sounds Meat (all types) : wrap in polythene bags... -
Page 16: Care And Cleaning
ENGLISH • do not allow fresh, unfrozen food to touch To obtain the best performance from this food which is already frozen, thus avoid- appliance, you should: ing a rise in temperature of the latter; • make sure that the commercially frozen •... -
Page 17: Troubleshooting
ENGLISH Defrosting of the refrigerator The absence of frost is due to the continuous circulation of cold air inside the compart- Frost is automatically ment, driven by an automatically controlled eliminated from the fan. evaporator of the re- frigerator compart- Periods of non-operation ment every time the When the appliance is not in use for long... - Page 18 ENGLISH Problem Possible cause Solution The compressor oper- The Temperature regulator Set a warmer temperature. ates continually. may be set incorrectly. The door is not closed cor- Refer to "Closing the door". rectly. The door has been opened Do not keep the door open too frequently.
- Page 19 ENGLISH Problem Possible cause Solution The appliance does not The appliance is switched off. Switch on the appliance. operate. The mains plug is not connec- Connect the mains plug to the ted to the mains socket cor- mains socket correctly. rectly.
-
Page 20: Technical Data
ENGLISH Technical data The technical infor- Dimensions mation are situated Height 2014 mm in the rating plate on the internal left side Width 595 mm of the refrigerator Depth 673 mm compartment and in the energy label. Net Volume Fridge 280 Litre Freezer 78 Litre... - Page 21 ENGLISH Electrical Connection 2. Connect the wire coloured blue to the terminal either marked with the letter Caution! Any electrical work required “N“ or coloured black. to install this appliance should be 3. Connect the wire coloured brown to the carried out by a qualified electrician or terminal either marked with the “L“...
-
Page 22: Environmental Concerns
1st of August 2007 placed parts become the property of IKEA. Who will execute the service? What will IKEA do to correct the problem? IKEA service provider will provide the serv- IKEA appointed service provider will exam- ice through its own service operations or ine the product and decide, at its sole dis- authorized service partner network. - Page 23 • The use of the appliance in a non-domes- IKEA appliances: tic environment i.e. professional use. Please do not hesitate to contact IKEA After • Transportation damages. If a customer Sales Service to: transports the product to their home or 1.
- Page 24 Before calling us, assure that You have to 3. ask for clarification on user manual con- hand the IKEA article number (8 digit code) tents and specifications of the IKEA ap- for the appliance of which you need our pliance.
- Page 25 Hétköznap 8 és 10 óra között 0900 235 45 32 ma-vr 9.00-21.00 Nederland and/or 0, 1 0 EUR/min (niet lokaal)Incl. BTW zat 9.00-20.00 0900 BEL IKEA zon 9.00-18.00 Norge 815 22052 Takst innland 8 til 20 ukedager Österreich 0810 300486...
- Page 28 © Inter IKEA Systems B.V. 2008 AA-905134-01...
