Model No. IMTL22990
Serial No.
Write the serial number in the space
above for future reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through di-
rect assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.
¨
Patent Pending
USER'S MANUAL
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Image IMTL22990
Summary of Contents for Image IMTL22990
- Page 1 Model No. IMTL22990 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
-
Page 2: Table Of Contents
2. Use the treadmill only as described in this 4. Keep the treadmill indoors, away from mois- manual. ture and dust. Do not put the treadmill in a garage or covered patio, or near water. 3. Place the treadmill on a level surface, with eight feet of clearance behind it. - Page 3 5. Do not operate the treadmill where aerosol 14. Never start the treadmill while you are stand- products are used or where oxygen is being ing on the walking belt. Always hold the administered. handrails while using the treadmill. 6. Keep children under the age of 12 and pets 15.
-
Page 4: Before You Begin
The model effective form of cardiovascular exercise in the conve- number of the treadmill is IMTL22990. The serial num- nience and privacy of your home. ber can be found on a decal attached to the treadmill (see the front cover of this manual for the location). -
Page 5: Assembly
This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. -
Page 6: How To Use The Heart Rate Monitor
Make sure that the logo on ¥ As you walk or run on the treadmill, position your- the sensor unit is facing forward and is right-side-up. self near the center of the walking belt. For the... -
Page 7: Operation And Adjustment
WALKING BELT electric shock. This product is equipped with a cord having an equipment-grounding conductor and a Your treadmill features a walking belt coated with grounding plug. Plug the power cord into a surge PERFORMANT LUBE , a high-performance lubricant. -
Page 8: Console Diagram
When the manual mode is selected, the speed and ¥ Do not stand on the walking belt when turn- incline of the treadmill can be changed with a touch of ing on the power. a button. As you exercise, the LED track and the four displays will provide continuous exercise feedback. -
Page 9: How To Use The Manual Mode
To see Adjust the incline of the treadmill as desired which unit of measure- To change the incline of the treadmill, press the ment is selected, hold down the STOP button while inserting the key into INCLINE buttons. Each time one of the buttons is pressed, the incline will change by 0.5%. - Page 10 When you are finished exercising, press the Note: The graphs on the left side of the console STOP button and remove the key. show how the speed or incline of the treadmill will change during the programs. During program 4, Step onto the foot...
- Page 11 (If an incline pro- an incline program is selected, press the INCLINE gram is selected, the treadmill will also adjust to buttons to adjust the maximum incline setting (see the first incline setting for the program, unless it is already at the first setting.) Hold the handrails and...
-
Page 12: Trouble-Shooting
PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in. - Page 13 1/4 of a turn each. Be careful not to overtighten the walking belt. Plug in the power cord, insert the key and run the treadmill for a few minutes. Repeat until the walking belt is centered. b. If the walking belt has shifted to the right, first re- move the key and UNPLUG THE POWER CORD.
- Page 14 PROBLEM: The heart rate monitor does not function properly SOLUTION: a. If the heart rate monitor does not function properly, see HEART RATE MONITOR TROUBLE- SHOOTING on page 6. b. If the heart rate monitor still does not function properly, the battery should be changed.
-
Page 15: Conditioning Guidelines
CONDITIONING GUIDELINES Burning Fat WARNING: Before beginning To burn fat, you must exercise at a low intensity level any exercise program, consult your physi- for a sustained period of time. During the first few cian. This is especially important for individu- minutes of exercise, your body uses easily accessible als over the age of 35 or individuals with pre- carbohydrate calories for energy. - Page 16 PART LISTÑModel No. IMTL22990 Note: To identify the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Key No. Qty. Console Base Screw Belly Pan Screw Handrail Cap Nylon Washer...
- Page 17 EXPLODED DRAWINGÑModel No. IMTL22990 R01099A...
-
Page 18: Ordering Replacement Parts
EXPLODED DRAWING in the center of this manual) If possible, place the treadmill near your telephone for easy reference when calling. IMAGE is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
