Furuno FCV-30 Installation Manual

Furuno FCV-30 Installation Manual

Color sounder
Hide thumbs Also See for FCV-30:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
SAFETY INSTRUCTIONS ......................................................................................................................i
SYSTEM CONFIGURATION................................................................................................................. iii
EQUIPMENT LISTS .............................................................................................................................. iv
1. MOUNTING ........................................................................................................................................1
1.1 Control Unit.................................................................................................................................1
1.2 Processor Unit ............................................................................................................................3
1.3 Transceiver Unit..........................................................................................................................4
1.4 Transducer..................................................................................................................................5
1.5 Junction Box .............................................................................................................................6
2. WIRING ..............................................................................................................................................7
2.1 Interconnection ...........................................................................................................................7
2.2 Cable Fabrication .......................................................................................................................9
2.3 Synchronizing Transmission with Echo Sounder or Other Sonar............................................11
2.4 Input/Output Sentences........................................................................................................... 12
3. SYSTEM SETTINGS AFTER INSTALLATION ............................................................................... 13
OUTLINE DRAWINGS .......................................................................................................................D-1
INTERCONNECTION DIAGRAM ......................................................................................................S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
COLOR SOUNDER FCV-30
www.furuno.co.jp
Back

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCV-30 and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno FCV-30

Summary of Contents for Furuno FCV-30

  • Page 1: Table Of Contents

    Back Installation Manual COLOR SOUNDER FCV-30 SAFETY INSTRUCTIONS ........................i SYSTEM CONFIGURATION......................... iii EQUIPMENT LISTS ..........................iv 1. MOUNTING ............................1 1.1 Control Unit..........................1 1.2 Processor Unit ..........................3 1.3 Transceiver Unit..........................4 1.4 Transducer..........................5 1.5 Junction Box ..........................6 2. WIRING ..............................7 2.1 Interconnection ...........................7 2.2 Cable Fabrication ........................9...
  • Page 2 *00015183714* *00015183714* *00015183714* *00015183714*...

  • Page 3: Safety Instructions

    The installer of the equipment is solely responsible for the proper installation of the equipment. FURUNO will assume no responsibility for any damage associated with improper installation. Be sure that the power supply is compatible with the voltage rating of the equipment.
  • Page 4 SAFETY INSTRUCTIONS CAUTION CAUTION The transducer cable must he handled Ground the equipment to carefully, following the guidelines prevent mutual interference. below. • Keep fuels and oils away from the Observe the following compass safe cable. distances to prevent interference to a •...

  • Page 5: System Configuration

    SYSTEM CONFIGURATION Display Unit (option) MU-151C/MU-201C Control Unit Processor Unit or commercially available monitor CV-301 CV-300 POWER Navigator Satellite Compass 100-240 VAC Net Sonde φ , 50/60 Hz Hard Disk USB Memory Transceiver Unit CV-302 100-120/200-240 VAC φ , 50/60 Hz Network Sounder ETR-30N Junction Box...

  • Page 6: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks Processor CV-300 With spare parts SP02-04801, SP02-05101 − Unit and installation materials CP06-01401 CV-301 With FP03-09860 & CP03-25604 − Control Unit Transceiver CV-302 With SP02-04901 & CP02-07801 − Unit CV-302-MS Transducer CV-303 −...
  • Page 7 EQUIPMENT LISTS Spare parts SP02-04901: 001-416-070 Name Type Code no. Remarks Fuse FGMB 125V 10A PBF 000-157-470-10 Fuse FGMB 250V 5A PBF 000-157-570-10 Accessories SP03-09860: 008-535-690 Name Type Code no. Remarks Cushion TM-180-302 000-166-468-10 Grommet G-49 000-166-406-10 Blind seal 22-020-1005-1 100-173-591-10 KB fixing metal 03-163-7821-1...

  • Page 8: Mounting

    MOUNTING NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. Control Unit Mounting considerations When selecting a mounting location, keep in mind the following points: •...
  • Page 9 1. MOUNTING Fixing without KB fixing metal 1. Drill four mounting holes of 5 mm diameter referring to the drawing below. 2. Fix the control unit with four screws (M4) from under side of the desktop. Use M4x12 (supplied) for mounting panel thickness “t” between 2 and 5 mm. For greater thickness, screw length shall be M4x(t+7.8±2).

  • Page 10: Processor Unit

    1. MOUNTING Processor Unit The processor unit can be mounted on the deck, a desktop or on a bulkhead. Select a mounting location considering the points below. • Locate the unit out of direct sunlight. • Select a location where temperature and humidity are moderate and stable. •...

  • Page 11: Transceiver Unit

    1. MOUNTING Transceiver Unit The transceiver unit is designed to be mounted on the deck. Select a mounting location considering the points below. • The transceiver unit generates heat so the mounting location should be well ventilated and dry. • The unit is only designed for deck mounting. •...

  • Page 12: Transducer

    TFB-1600 and optional transducer tank T-625. About transducer casing The FURUNO transducer tank is finished with lacquer primer to prevent corrosion in storage. After welding the casing to ship's hull, remove the lacquer primer, using lacquer thinner. Coat casing with same paint as used on ship's hull.

  • Page 13: Junction Box

    1. MOUNTING Junction Box If the length of cable between the transducer and transceiver unit is more than 15 m, the optional junction box (with 10 m or 20 m cable) can be used for cable extension. For bulkhead mounting, orient the cable entry downside and fix the junction box with M5 bolts (shipyard supply).

  • Page 14: Wiring

    WIRING Interconnection Refer to the interconnection diagram at the back of this manual for detailed information. Transceiver Unit CV-302 Monitor KP OUT TRX2→CN-B102 TRX4→CN-B104 TRX1→CN-B101 TRX3→CN-B103 LAN* Control Unit CV-301 TB-B101 100-120 VAC/ 200-240 VAC Navigator Satellite Compass Net Sonde Junction Box (option) CV-304 Processor Unit...
  • Page 15 2. WIRING Cable running in the junction box Fold back the harnesses of TD2 & TD4 and pass them to clamp 1. TRX4 Clamp 1 TRX2 TRX3 TRX1 Clamp 2 Fix the braided shield by cable clamp.

  • Page 16: Cable Fabrication

    2. WIRING Cable Fabrication LAN cable The LAN cable (FR-FTPC-CY 10, 20, or 30 m) connects between the processor unit and the transceiver unit. Cut armor and outer vinyl sheath as shown below and then connect the modular connector MPS588-C (supplied) to both ends. Inner vinyl sheath Inner vinyl sheath Outer vinyl sheath...
  • Page 17 2. WIRING Power cable for the processor unit Use power cable DPYC-2.5 (Japan industry standard cable) or equivalent. Connect connector SRCN6A13-3S (supplied) as follows. 2 cm Sheath Armor Solder Side Armor Screw Armor Vinyl Tighten Clamp set screw sheath Connect to "1"...

  • Page 18: Synchronizing Transmission With Echo Sounder Or Other Sonar

    Synchronizing Transmission with Echo Sounder or Other Sonar To synchronize transmission of the FCV-30 with an echo sounder or other type of sonar, connect it as shown below. Also, set the Ping Setting to External, referring to page 3-4 and 3-5 of the FCV-30 Operation manual.

  • Page 19: 2.4 Input/Output Sentences

    2. WIRING 2.4 Input/Output Sentences Input sentences (talker not specified) Sentence Data Remarks Time, position NMEA GRI, TD (Loran C) NMEA Latitude and longitude NMEA TD (Loran C) NMEA Water temperature NMEA Loran C data (Latitude and longitude, TD, ground speed and course NMEA Recommended minimum navigation information NMEA...

  • Page 20: System Settings After Installation

    INSTALLATION After installing all equipments, set up the equipment as shown in this chapter. The FCV-30 is shipped from the factory ready for connection to an XGA monitor. To connect an SXGA monitor, contact a FURUNO agent or dealer. System Setting Do the system settings as follows.
  • Page 21 3. SYSTEM SETTINGS AFTER INSTALLATION Compensation 1. Click Compensation in the System menu to show the Compensation dialog box is displayed. Ten key button 2. Set the following items. To enter numeric values, press the ten-key button at lower left-hand side to open the ten-key panel. Click appropriate numeric keys. Stabilization: Choose ON to activate the stabilization function.
  • Page 22 3. SYSTEM SETTINGS AFTER INSTALLATION Temperature 1. Click Temp in the system menu to show the “Temp” dialog box. 2. Set the following items. Temp input: Choose CIF or NMEA as the temperature data source as appropriate. Temp adjust: Enter compensation value for CIF input. (Setting range: -20.0 to +20.0 degrees) 1.
  • Page 23 3. SYSTEM SETTINGS AFTER INSTALLATION Communication parameters 1. Click Communication in the system menu to show “Communication” dialog box. 2. Set the following items. IP address: Set the IP address of the network. Port: Set the port number. Normally no change is required. Port in the NMEA/SC/CIF field: COM1: Choose this when an external equipment is connected to COM1 port of the processor unit.
  • Page 24 3. SYSTEM SETTINGS AFTER INSTALLATION Setting the Date 1. Click the Date in the system menu. The Date dialog box is displayed. Cancel 2. Using ◄ or ► or ten-key panel, enter current date and time. 3. Click the OK or Apply button. From this moment, the time counts up. Note that the date and time are not displayed on the screen, however data files which are downloaded are named by date and time.
  • Page 25 5. Using the mouse wheel, double-click the space just below the right edge of the menu bar. The Service menu disappears. Also, the Service menu disappears by turning off and on the FCV-30. Note: Do not change the setting in the Beam Information, Bottom or Environment in the Service menu at installation.
  • Page 26 3. SYSTEM SETTINGS AFTER INSTALLATION 4. If the transducer to be used is programmed in the FCV-30, choose Model number in the Setting method box, and choose the model in LF or HF box. Note: Change the tap inside the ETR-30N according to the character which appears next to “TAP”: A to D displayed beneath the frequency.
  • Page 27 Y. Hatai...
  • Page 30 Y. Hatai...
  • Page 31 Y. Hatai...
  • Page 32 Y. Hatai...
  • Page 33 Y. Hatai...

  • Page 34: Interconnection Diagram

    名称 カラー魚群探知機 T.TAKENO Apr. 2 '07 *1: SHIPYARD SUPPLY APPROVED *2: OPTION 相互結線図 *3: CONNECTOR PLUG FITTED AT FACTORY. SCALE MASS NAME COLOR VIDEO SOUNDER *4: GROUND THROUGH CABLE CLAMP. DWG No. INTERCONNECTION DIAGRAM C2373-C01- F FURUNO ELECTRIC CO., LTD.
