BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT
•
and ordinances.
Note to Installer
Be sure to leave these
•
instructions for the consumer's and local
.
inspector's use
Note to Consumer
•
your Owner's Manual for future reference.
Skill Level
• Installation of this dishwasher
requires basic mechanical and electrical skills. Proper
installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the GE Appliance Warranty. See
warranty information.
Completion Time
•
New installations require more time than replacement
installations.
CONTENTS
Installation Preparation
Parts Supplied...................................................................................... 3
Materials You Will Need ..................................................................3
Tools You Will Need .......................................................................... 3
Prepare Dishwasher Enclosure ...................................................4
Drain Requirements .......................................................................... 4
Prepare Electrical Wiring ................................................................5
Prepare Hot Water Line ..................................................................6
Dishwasher Installation
Step 1, Preparation ........................................................................... 7
Step 2, Check Door Balance .........................................................7
Step 3, Remove Wood Base, Install Leveling Legs .............7
Step 4, Remove Toekick ..................................................................7
Step 5, Position Sound Barrier .....................................................7
Step 6, Remove Floor Protect ......................................................8
Step 7, Install 90° Elbow .................................................................8
Step 8, Install Drain Hose to Drain Loop .................................8
Step 9, Position Water Line and House Wiring ....................8
Safety Information
Observe all governing codes
Keep these instructions with
IMPORTANT
•
installed to allow for future removal from the enclosure
if service is required.
Care should be exercised when the appliance is installed
or removed, to reduce the likelihood of damage to the
power supply cord.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories - See the Owner's Manual for
available custom panel kits.
READ CAREFULLY.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS
shown throughout these instructions. While
performing installations described in this booklet,
gloves, safety glasses or goggles should be worn.
For Monogram local service in your area, 1.800.444.1845.
For Monogram parts and accessories, call 1.800.626.2002.
For Monogram parts and accessories in Canada, call
1.800.561.3344.
Step 10, Install Drain Hose Through Cabinet .......................8
Step 11, Slide Dishwasher Three-Fourths of the
Way Into Cabinet. .............................................................................. 9
Step 12, Install Trim Pieces............................................................9
Step 13, Install Mounting Brackets ...........................................9
Step 14, Push Dishwasher Into Final Position ................... 10
Step 15, Level Dishwasher ......................................................... 10
Step 16, Position Dishwasher, Secure to Countertop or
Cabinet ................................................................................................. 11
Step 17, Connect Water Supply ............................................... 11
Step 18, Connect Drain Line ................................................11,12
Step 19, Connect Power Supply ............................................... 12
Step 20, Pretest Checklist ........................................................... 13
Step 21, Dishwasher Wet Test .................................................. 13
Step 22, Replace Floor protect ................................................. 13
Step 23, Position Insulation, Pre-Toekick and
Sound Barrier ................................................................................... 14
Step 24, Replace Toekick ............................................................. 14
Step 25, Literature .......................................................................... 14
2
The dishwasher MUST be
.
