Assembly Instructions:

Install rower seat onto seat rail,
with widest part of seat rearward.
Step 1
CAUTION
Installing the seat incorrectly will result
in lack of data pickup during rowing.
Turn seat rail over, and install the rear
rubber bumpstop using 2x M6x10mm
screws with beveled edge facing forward.
Step 2
Seat Rail
Rear Leg
Using the M10x25mm bolt, 11x21x2T Washer and
Rear leg, install as shown. Once rear leg is tight-
ened, install the rear Rubber End Cap.
Step 3
M10x25mm bolt and
11x21x2 washer

Rear Rubber

end cap
