MODELS: ZRM-E36CS, ZRM-E42CS

PARTS SUPPLIED

(2) Top Duct Covers
(2) Bottom Duct Covers
(1) Hood Body w/
blower housing
(1) Hardware package
HARDWARE PACKAGE CONTENTS
(3) Wire Nuts
(4) M4 x 1-1/2"
Wood Srews
(2) 3/16 x 1/4"
(12) M3 x 6
Machine Screws
Machine Screws
PARTS NOT SUPPLIED
- Ducting, conduit and all installation tools
- Hack saw to cut down trim pieces
- Cable connector (if required by local codes)
- Duct cover extension accessory - Z1C-01RM
- Recirculating kit accessory - ZRC-02RM (36"), ZRC-01RM (42")
(2) Thick Trim Pieces
(2) Thin Trim Pieces
(1) 6" round damper (pre-installed)
(4) 3/16 *1/2" mounting screws (pre-installed)
(1 in each corner of the blower housing)
(4) Halogen Light Bulbs (pre-installed)
(2) Aluminum Mesh Filters (3 - ZRM-E42CS)
(1) Light Bulb Removal
(4) ø12 OD / ø5 ID
Suction Cup
Washers
(8) M4 x 8
Machine Screws
4
www.zephyronline.com
(1) Top Support Frame
(1) Bottom Support Frame
