Troy-Bilt TB4HB EC Operator's Manual

4-Cycle Electric Start Capable Handheld Blower
Removing Unit From Carton Assemble The Unit
1 1 2
Remove all contents from Insert the upper blower
the carton. tube into the blower outlet
and turn it clockwise until it
locks into place.
Assemble The Unit Starting The Unit
10 X
5
6
Place unit on a level surface. Press primer bulb 10 times,
Fill fuel tank.
or until fuel is visible
Starting The Unit
1 9 10
DO NOT squeeze throttle Pull rope 5 times.
control.
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES WHILE OPERATING THE UNIT.
NEED HELP?
769-07792 P00
TB4HB EC
Operator's Manual
3
Install the lower blower tube
onto the upper blower tube
and turn it clockwise until it
locks into place.
Primer
Bulb
7
Move choke lever to
Position 1.
5 X
11
Move choke lever to
Position 2 .
Call 1-800-828-5500 in U.S. or 1–800–668–1238 in Canada
4
Place the unit on a level
surface, remove the oil plug
from the crankcase, and pour
the entire bottle of oil into the
fill hole.
Lower Blower Tube
8
Crouch in starting position.
3-5 X
12 13
Pull rope 3-5 times to start Continue to squeeze
engine. Squeeze throttle throttle. Move choke lever
to Position 3.
control and allow unit to
warm up for 30-60 seconds.
Tools Required:
On/Off Switch
• Flathead Screwdriver
Blower Outlet
Upper Blower Tube
Oil Plug
DIDN'T START?
Repeat the starting instructions.
IF engine fails to start after 2 attempts,
move choke lever to position 3 and pull
the starter rope until engine starts
IF unit still fails to start, refer to operator's
manual for additional starting and
troubleshooting information
14
Continue to squeeze
throttle. Warm unit for an
additional 60 seconds to
complete warm-up. Unit
may be used during this
time.
Throttle Control
Primer Bulb
Starter Rope
05/12
