- Page 1 ALLARMED SPEED DOME LCTSD318 User Manual LCTSD326 LCTSD336 LCT0804/ver.1.0 www.hrcctv.com...
- Page 2 User Manual LCTSD318-326-336 Disposal of waste products for European Union NORME GENERALI DI SICUREZZA - This products was designed to minimize their impact on the General safety recommendations environment reducing eliminating hazardous materials and designing for recyclables. Sicurezza delle persone - Safety warnings...
-
Page 3: Table Of Contents
User Manual LCTSD318-326-336 SUMMARY 1. Introduction..........................4 1.1 Technical specific .................... 4 LCTSD318............................4 LCTSD326............................4 LCTSD336............................4 1.2 Side identification..................... 5 2. Installation..........................6 2.1 Preparations ..................... 6 2.2 Brackes assembling .................... 6 2.3 Connection....................... 6 2.4 Switch adjustment .................... 8 3. Menu Configuration ........................ 10 3.1 Menu Operation.................... -
Page 4: Introduction
User Manual LCTSD318-326-336 1. Introduction 1.1 Technical specific Specifics Details Preset Tour 4 – max 27 Preset Cruise Pattern Horizontal Movimento 360° ; speed 300°/sec. OSD password Proportional Pan/Tilt Day/night Auto, Color, Night (select) S/N Ratio >50dB Electronics shutter 1/1 - 1/10,000 sec., 22 steps... -
Page 5: Side Identification
User Manual LCTSD318-326-336 1.2 Side identification 1. Bracket of wall to fix 2. Threaded inside attack 3. Drip 4. Inside custody 5. Security hook 6. Fan 7. Heating up plate 8. Hook-up lever and quick shell out 9. Hook tack on of security 10. -
Page 6: Installation
User Manual LCTSD318-326-336 2. Installation 2.1 Preparations Precautions • Qualified and experienced person can carry out the installation. In many countries and areas licensed people is required. • Before the installation and connection put off the camera . • Do not putin the camera near to the air vent of the air conditioner. - Page 7 User Manual LCTSD318-326-336 Fig.3 Fig.4 connect cables. Connect these cables into the relative connector relative: A. Video signal - BNC female connector. B. RS485+A and RS485-B terminal box. Open the screw of clamps put in the cables and close .Attention to the polarity electric wires( RS485+A (RX+) and RS485-B (RX-)) in the connection with the control device (control keyboard , DVR).
-
Page 8: Switch Adjustment
User Manual LCTSD318-326-336 D. IN/OUT alarm clamps 8 in put with 1 common of reference ( the in put must to pilot at clean contacts). 1 output alarm to relay (Common, NC e NO); max. 30V, 1A. 2.4 Switches adjustment For access to the 2 DIP-SWITCHES reverse the block of Speed dome ( pag 5) . - Page 9 User Manual LCTSD318-326-336 The protocol of communication that need to use is assigned by DIP Swicthes 1-2-3-4-5- 6 Protocol DIP 1-6 Protocol Switch Position Protocol Switch Position Pelco PD Lilin (Default) Pelco C Kalatel Pelco PDC Vicon The factory start up is : Pelco PD Second the next table that consent to obtain 254 different address (1 at 254 ) all switches of the second DIP Switch assign the address of the camera.
-
Page 10: Menu Configuration
User Manual LCTSD318-326-336 3. Menu Configuration To understand the potentiality LCTSD camera high speed dome,system see the followed illustration. Video wiring note,come true with usual coaxial cable or twisted cable and the BUS RS485 for the Speed Dome management. At the RS485 BUS ,fin place too recorder(DVR) and on the BUS, is possible to put on :LCTspeed dome, HR DVR,HR keyboard (HRKB001 and HRKB001NET).By these devices is possible to manage and setup the Speed Dome. -
Page 11: Boot-Up Screen
Protocol: Pelco PD • address: display the Speed Dome address assigned ,set up by DIP-Switch 2 Com: 4800 N 8 1 • Model: display the model in use of the three available (LCTSD318-LCTSD326- address: 001 • LCTSD336) Model: LCTSD318 Version: firmware version •... -
Page 12: Menu Explanation
User Manual LCTSD318-326-336 System setup (pag.13) • Site Info: Dome ID, Name, broadcast address. Site Info 3.3 Menu explanation • Display Setup: Screen display. Display setup • Boot-up Screen: Display boot-up information Boot-up screen The main menu is subdivide in 7 sub menu . -
Page 13: System Setup
Comm: 4800 N 8 1 <address>: Display assigning address of Speed Dome fil to DIP-Switch 2 Address: 001 Model: LCTSD318 <Model>: Display the model in use of three available (LCTSD318-LCTSD326-LCTSD336) <Version>: firmware version Version: 1.01 Call the Preset 1 to back. -
Page 14: Lens - Optics Setup
User Manual LCTSD318-326-336 Password In this menu is possible to bump up the security level if the password is enable. <Input PW>:For input the password the next sub menu display . Old PW: ****** Input PW : ****** Back Confirm PW: ******... -
Page 15: Camera - Camera Setup
User Manual LCTSD318-326-336 Autofocus Time In this menu is possible disarm/arm <Off> If on is up , select seconds <0-255>, In here the dome can be manually controlled, this function consent to restore auto focus automated , After user time . -
Page 16: Pan/Tilt - Ptz Setup
User Manual LCTSD318-326-336 BLC Mode Select this option to access in sub menu and arm <On> or disarm <Off> the function. BLC Mode : On Back 3.7 PAN/TILT setup System Auto Stop Time Lens Speed Amplify Camera Proportional P/T Pan/Tilt... - Page 17 User Manual LCTSD318-326-336 Preset Preset Preset No: Tour Name: Cruise Current Setup Pattern Test Zone Next Test Park Time: Remove current Park Time: Back Back Select <Preset> to enter sub menu and control Preset: <Preset Number>: Select preset number to be make on or adjustment.
-
Page 18: Privacy Mask - Privacy Aree Setup
User Manual LCTSD318-326-336 Pattern Pattern Numbe: Preset Record: Tour Test: Cruise Pattern Back Zone Park Time: Park Time: Back Select<Pattern> to enter sub menu and control Pattern : <Pattern Number>: Select Pattern record number. <Record>: Here move the camera to desired positions, to recording really passage. -
Page 19: Alarm - Alarm Setup
User Manual LCTSD318-326-336 Privacy Mask Select <Privacy Mask> to enter sub menu and control 8 masking zones. < Mask Number>: Select mask zone number. <Mask setup>: Set the position and size of the masking zone. Before to mask, make sure with camera just be position to the cover zone. - Page 20 User Manual LCTSD318-326-336 Alarm Select <Alarm> to enter sub menu and control input and output alarm. < Alarm In 1-8>: For each input alarm , is possible associate preset or select 1 to the 4 tour, cruise or pattern setup.
-
Page 21: Appendix
User Manual LCTSD318-326-336 4. APPENDIX DIP-SWITCH AND ADDRESS SETTING CHART www.hrcctv.com pag. - Page 22 User Manual LCTSD318-326-336 pag. www.hrcctv.com...
-
Page 23: Www.hrcctv.com Pag
User Manual LCTSD318-326-336 MEMO Technical specifications can be modified without any preliminary notice This manual may not be reproduced in whole or in part (except brief quotations in articles or magazines), without the 'written permission of HR EUROPE. www.hrcctv.com pag. - Page 24 User Manual LCTSD318-326-336 HR EUROPE s.r.l. ROMA: sede legale e amministrativa; Via Giulianello, 1-7 – 00178 Roma, ITALIA – Tel +39 06 7612912 Fax +39 06 7612601 TORINO: sede operativa; Via G.B.Feroggio, 10 – 10151 Torino, ITALIA – Tel +39 011 453 53 23 Fax +39 011 453 70 49 SHANGHAI: ufficio di rappresentanza;...
