Dell PowerConnect RPS720
Figure 1-1. Front Panel Indicators-PowerConnect RPS720
Supports up to four PowerConnect switches through 12 V DC output
Dedicated 180 W power supply for up to four connected switches
Front panel LEDs display status of individual power supplies
1U, 19-inch rack mountable system
The PowerConnect RPS720 redundant power bank provides four external
redundant power supplies for your PowerConnect switches, eliminating the power
supply as a single point of failure.
Dell PowerConnect MPS600
Figure 1-2. Front Panel Indicators-PowerConnect MPS600
Supports one PowerConnect 55xxP (PoE) switch through 48 V DC output
Dedicated 600 W power supply for one connected switch
Front panel LEDs display status of the power supply
Getting Started With Your System
