PowerConnect MPS600
The PowerConnect MPS600 contains a 600 W power supply.
Physical
Height
Width
Depth
600 W AC-DC power supply
NOTE:
The power supply has an universal input (90 VAC to 264 VAC) and a 12 VDC
regulated output. This regulated output supplies power to other power supply backup
source. The power supply incorporates over current protection and OVP.
Input Voltage
Input Frequency Range
Max. Input AC Current
Output Voltage and Current
No of Output
Nominal Output Voltage Set Point
Set Point Tolerance
Total Error Band
Minimum Current
Maximum Current
PowerConnect MPS1000
The PowerConnect MPS1000 contains a 1000 W power supply.
Physical
Height
Width
Depth
41.6 mm (1.64 in)(maximum)
133.8 mm (5.27 in)(maximum)
401.4 mm (15.8 in)(maximum)
Universal input– 90 to 264 VAC
47 to 63 Hz, single phase AC
8.0 A (maximum)
1
48 V DC
+/- 1%
+/- 2%
1.0 A
12.5 A
41.6 mm (1.64 in)(maximum)
133.8 mm (5.27 in)(maximum)
401.4 mm (15.8 in)(maximum)
Getting Started With Your System
13
