369300/369310/369305/369315
7" Video Touch Screen
User guide
07/12-01 CN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7" Video Touch Screen and is the answer not in the manual?

Questions and answers

Summary of Contents for LEGRAND 7" Video Touch Screen

  • Page 1 369300/369310/369305/369315 7" Video Touch Screen User guide 07/12-01 CN...
  • Page 3: Table Of Contents

    7" VIDEO KIT TOUCH SCREEN Table of contents Calling Function Entrance Panel Activation Intercom calling Work Mode Guest records Guest Photos Digital Photos Frame Settings Ring Setting Video Setting Date Time Setting Touch Screen Calibration Setting Welcome message...
  • Page 4 – legislation regarding the protection of personal data; – data security obligations; – picture and portrait rights, as well as the regulations on copyright and intellectual and industrial property. • Legrand is not responsible for the illegitimate use of its equipment by its customers.
  • Page 5 Your 7" VIDEO KIT TOUCH SCREEN 1.Speaker 2.Intercom 3.Entrance panel switching ON key / Answering key 4.Call LED 5.Power LED 6.Optional button (G+/G- connector) 7.Door lock button (L+/L- connector) 8.Microphone 9.USB 10.SD Date Detection of SD card Main screen: 25-12- 2011 Entrance panel activation Intercom Call Guest Voice Record...
  • Page 6: Calling Function

    1. Calling Function 2. Entrance Panel activation When a call arrives, internal unit switch on showing When press in main screen, you will activate video from Entrance camera. the entrance panel camera. Press to activate a Press to answer. call with entrance panel. : When pressed, ending talking and return to main screen.
  • Page 7: Work Mode

    4. Work Mode 5. Guest Records When you press in main screen, you enter in : Select this icon in main screen to set all calls to the guest record menu: mute (without ring). : Select this icon in main screen to go to standby and power off screen.
  • Page 8: Guest Photos

    7. Digital Photo Frame : Go to see the vistor photo that link to the In order to see photos you must have inserted a SD card, record. you can see icon on top right corner in main : Lock voice record to avoid to delete. screen.
  • Page 9: Settings

    8. Settings 8.1 Ring Setting When press in main screen, you will enter in the settings menu: :Select entrance panel ring. : Quit and return to main page. :Move with arrows to select song for this ring. : Enter Ring setting. :Select intercom ring : Enter Video setting.
  • Page 10: Video Setting

    8.4 Touch Screen Calibration Setting 8.2 Video Setting : Coordinates calibration, 3 points to calibrate the : Increasing color, brightness or contrast setting. screen. : Decreasing color, brightness or contrast setting. 8.5 Welcome message 8.3 Date Time Setting : Record welcome message. : Increasing year/month/day/hour/minute.
