Summary of Contents for Cradlepoint MBR1400LE-VZ

  • Page 2: Manual Revisions

    All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. Copyright © 2013 by CradlePoint, Inc. All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written consent by CradlePoint, Inc.

  • Page 3: Table Of Contents

    MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT Table of Contents 1 INTRODUCTION ..............3 5.3 GPS ................. 47 5.4 GRE T ..............48 UNNELS 1.1 P ............. 3 ACKAGE ONTENTS 5.5 H ............... 49 OTSPOT LIENTS 1.2 S ............
  • Page 4 8.9 S ............221 YSTEM OFTWARE 9 GLOSSARY..............223 10 APPENDIX ..............237 10.1 P ....... 237 RODUCT NFORMATION AND AFETY UIDE 10.2 S .............. 240 PECIFICATIONS © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 2...

  • Page 5: Introduction

    MBR1400E-SP – 3G EVDO for Sprint 1.2 System Requirements  At least one Internet source: a CradlePoint 3G/4G business-grade modem, an Ethernet-based modem, a broadband data modem with active subscription (USB, ExpressCard), or WiFi as WAN.  Windows 2000/XP/7, Mac OS X, or Linux computer (with WiFi adapter—802.11n recommended—for WiFi functionality).

  • Page 6: Mbr1400 Overview

    Internet. In addition to connection options for traditional wired networking solutions like cable, DSL, satellite, or T1, the most powerful feature of the MBR1400 is its ability to use CradlePoint business-grade modems or USB or ExpressCard data modems to create instant networks anywhere you receive a broadband signal.
  • Page 7 Rapidly deploy and dynamically manage networks at geographically distributed stores and branch locations with Enterprise Cloud Manager, CradlePoint’s next generation management and application platform. Enterprise Cloud Manager integrates cloud management with your CradlePoint devices to improve productivity, increase reliability, reduce costs, and enhance the intelligence of your network and business operations. Learn more at http://cradlepoint.com/ecm.
  • Page 8 Captive Portal 1.3.2 The Captive Portal solution provided by CradlePoint routers enables businesses to provide their customers with a public WiFi hotspot with access controls. The controls can be as simple as requiring acceptance of a terms of service agreement, while advanced features allow administrators to control and monitor usage, require login, direct users to specific web pages, provide revenue through services fees or paid advertising, and more.

  • Page 9: Radle Oint Arc Mbr1400 Series

    CRADLEPOINT 1.4 CradlePoint ARC MBR1400 Series The CradlePoint ARC MBR1400 Series includes a CradlePoint 3G/4G business-grade modem with the MBR1400 and creates an effortless instant network from high-speed wireless broadband. CradlePoint integrated business-grade modems are specifically designed to provide the highest level of performance, reliability, and security for 24x7 business-critical applications.
  • Page 10 Module Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi (Cellular/PCS) gain; finger tighten only; maximum torque spec is 7 kgf-cm GPS: standalone GPS support Industry Standards & Certs: FCC, Verizon Modem Part Number: MC200LE © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 8...
  • Page 11 Module Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi gain; finger tighten only; support for GPS on aux connection GPS: standalone GPS support Industry Standards & Certs: PTCRB, FCC, AT&T Modem Part Number: MC200LP © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 9...
  • Page 12 Module Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi gain; finger tighten only; support for GPS on aux connection GPS: standalone GPS support Industry Standards & Certs: CE, GCF-CC Modem Part Number: MC200LP2 © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 10...
  • Page 13 Module Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi gain; finger tighten only; support for GPS on aux connections GPS: standalone GPS support Industry Standards & Certs: PTCRB, FCC, IC Modem Part Number: MC200LP © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 11...
  • Page 14 For optimum performance, antennas on the MBR1400W-SP should be pointed in opposite directions as shown to the right. This will help prevent overlap with the 2.4 GHz WiFi band. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 15 IOT; FCC Part 15, 22 & 24, CDG Stages 1,2; IS-2000IA-98D/E, IS-134, IS-637B, IS-683A, IS-707A, IS-856, IS-866; JESD22- A114-B, JESD22-C101 Modem Certification Model Number: MC100E Modem Certification Part Number: MC100E-VZ (MBR1400E-VZ has been discontinued.) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 13...
  • Page 16 FCC Part 15, 22 & 24, CDG Stages 1,2; IS-2000IA-98D/E, IS- 134, IS-637B, IS-683A, IS-707A, IS-856, IS-866; JESD22-A114- B, JESD22-C101 Modem Certification Model Number: MC100E Modem Certification Part Number: MC100E-SP (MBR1400E-SP has been discontinued.) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 14...

  • Page 17: Hardware Overview

    MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT 2 HARDWARE OVERVIEW © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 15...

  • Page 18: Ports, Buttons, And Switches

    MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT 2.1 Ports, Buttons, and Switches © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 16...
  • Page 19  I = On  O = Off 3G/4G Modem Signal Strength Button: When pressed the bar LEDs indicate signal strength from the CradlePoint business-grade modem or USB or ExpressCard modem. The signal strength is shown for 10 seconds if the modem does not support concurrent data connection and signal strength measurement.

  • Page 20: Leds

    2.2 LEDs LAN and WAN LEDs: The default settings are shown. LAN ports can be reconfigured to function as WAN ports and vice versa; the LEDs will function accordingly. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 21: Quick Start

     Your router requires an Internet source. Attach a  USB/ExpressCard modem(s) CradlePoint business-grade modem, insert one or  Integrated CradlePoint business-grade modem more supported USB or ExpressCard modem(s), connect a cable or DSL modem to the blue Ethernet WAN port, or connect to an available WiFi source.

  • Page 22: Connect To A Computer Or Other Device

    SSID (service set identifier; the unique name of the local network). The SSID can be found on the product label in the form MBR1400- xxx, where “xxx” is the last 3 digits of the router’s MAC address. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 23 Follow the instructions given with the Wizard or Getting Started – First Time Setup for more information about using the First Time Setup Wizard. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 21...
  • Page 24 Your network should now be up and running, and users who have the security password can access the network on WiFi-enabled devices. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 25: Common Problems

    Check your signal strength in the Internet section of the Dashboard a weak signal in your location, contact your service provider. If you are still not online after activating the modem, go to knowledgebase.cradlepoint.com for more information. © 2013 CRADLEPOINT, INC.
  • Page 26 MBR1400. Insert your USB data modem into your PC and access the Internet using the software provided by your cellular carrier. Follow the directions provided to complete the update. Once you have updated your USB data modem, reconnect the cellular device to your CradlePoint router and connect to the Internet.
  • Page 27 Go to System Settings → System Software and click on “Manual Firmware Upload”. If you are still not online after activating the modem, go to knowledgebase.cradlepoint.com for more information. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 28 If the data modem LEDs are not illuminated, your modem is not connected and online. You may need to update firmware. “Your USB or ExpressCard modem does not work with the Refer to the previous section, router.” If you are still not online after activating the modem, go to knowledgebase.cradlepoint.com for more information. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 29: Web Interface - Essentials

    Web Interface – Essentials contains the following sections to help you more quickly and easily navigate these administration pages: Administrator Login Getting Started – First Time Setup Wizard Quick Links Configuration Pages Enterprise Cloud Manager Registration IP Passthrough Setup © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 27...

  • Page 30: Administrator Login

    Log in using your administrator password. Initially, this password can be found on the bottom of the MBR1400 unit as the Default Password. This password is also the last eight digits of the unit’s MAC address. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 31 Modem Details (if you have a business-grade/USB/ExpressCard data modem attached)  Manufacturer: The name of the modem manufacturer (CradlePoint, Novatel, etc.)  Model: The name of the modem model  Signal: The strength of the signal (dBm) ...

  • Page 32: Getting Started - First Time Setup Wizard

    FIRST TIME SETUP WIZARD. (Otherwise, go to Getting Started → First Time Setup). 4) CradlePoint recommends that you change the router’s ADMINISTRATOR PASSWORD, which is used to log in to the administration pages. The administrator password is separate from the WiFi security password, although initially the Default Password is used for both.
  • Page 33 The router cannot use 802.11n modes if WEP is enabled; WiFi performance and range will be limited.  NONE (OPEN): Select this option if you do not want to activate any security features. CradlePoint recommends BEST (WPA2) WiFi security. Try this option first and switch only if you have a device that is incompatible with WPA2.
  • Page 34 7) Configuring Your Access Point Name (APN): If you are using a SIM-based modem (LTE/GSM/HSPA) with your CradlePoint router, you may need to configure the APN before it will properly connect to your carrier. Wireless carriers offer several APNs, so check with your carrier to confirm the appropriate one to use.
  • Page 35  Authentication Protocol – Set this only if your service provider requires a specific protocol and the Auto option chooses the wrong one. Select from: o Auto o Pap o Chap  Username  Password © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 33...
  • Page 36 ISPs/Carriers block certain addresses, so choose an address that all of your WAN connections can use. For best results, select an established public IP address. For example, you might ping Google Public DNS at 8.8.8.8 or Level 3 Communications at 4.2.2.2. Click NEXT. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 34...
  • Page 37 Click APPLY to save the settings and update them to your router. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 35...

  • Page 38: Quick Links

    MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT 4.3 Quick Links The CradlePoint logo in the upper left-hand corner of all the administration pages is a link to the Dashboard (Status → Dashboard), which displays fundamental information about the router.

  • Page 39: Configuration

    Network Settings – Provides configuration options for the networks, or LAN, created by your router. For example, enable a guest WiFi network (WiFi / Local Networks), set up rules to filter websites (Content Filtering), or create a traffic- shaping rule to set bandwidth priorities (WiPipe QoS). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 40  If you want to change the content filtering settings for the network created by the MBR1400, go to the Network Settings tab.  If you have multiple Internet sources (such as a CradlePoint business-grade modem and an Ethernet connection) for which you would like to set priority levels, go to the Internet tab.

  • Page 41: Enterprise Cloud Manager Registration

    CRADLEPOINT 4.5 Enterprise Cloud Manager Registration To register your device with CradlePoint Enterprise Cloud, navigate to Getting Started → Enterprise Cloud Manager Registration. Input your ECM Username and ECM Password and click Register. You have now registered the device with Enterprise Cloud Manager.

  • Page 42: Ip Passthrough Setup

    You can quickly enable IP passthrough with the IP Passthrough Setup Wizard available under Getting Started → IP Passthrough Setup. IP passthrough takes a 3G/4G WAN data source (USB, ExpressCard, or CradlePoint business- grade modem) and passes the IP address through to Ethernet LAN.

  • Page 43: Status

     Dashboard  GPS  GRE Tunnels  Hotspot Clients  Internet Connections  Routing  Statistics  System Logs  VPN Tunnels  WiPipe QoS © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 41...

  • Page 44: Client List

    This rate changes automatically to match environmental conditions. Distance from the router, interference, etc can impact this value. Higher values indicate better performance. Devices can still function in the network with as little as 1 Mbps. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 45 Time Online: Simply the amount of time the device has been connected to the router. Kick: Click on this button to disconnect a client. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 46: Dashboard

    After the initial setup of the router, every time you log in you will automatically be directed to this Dashboard. Also, you can click on the CradlePoint logo in the upper left-hand corner to return to the Dashboard from any page.
  • Page 47 For configuration options, see Internet → Connection Manager. The IP address and gateway describe your active WAN source. For DNS server configuration options, see Network Settings → DNS. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 48 This will inform you about the availability of new firmware, for example. Router Alerts includes links to the System Software page (for new firmware) and the Connection Manager. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 49: Gps

    GPS. If GPS is supported, make sure the modem is in an area where it can receive a signal from the GPS satellites. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 50: Gre Tunnels

    View the status of configured GRE Tunnels. To set up or edit a GRE tunnel, go to Internet → GRE Tunnels. Included information:  Name  Status  Transmit (packets/bytes)  Receive (packets/bytes) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 48...

  • Page 51: Hotspot Clients

     MAC address  Data Usage (both IN and OUT)  Time Online You may revoke a client's access to the Internet by clicking the 'Revoke' button. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 49...

  • Page 52: Internet Connections

    Depending on the device, possible information will be in the following sections: Diagnostics, General Information, IP Information, and Statistics. For modems, the Diagnostics section provides specific information about how the modem is communicating with its carrier. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 53  Type ethernet  Port IP Information  DNS Servers  IP Address  Gateway Statistics  Incoming Bytes  Outgoing Bytes  Connection Uptime (secs) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 51...
  • Page 54  Service Display LTE  Primary Home Agent  Carrier Status  Profile  MN-AAA SPI  PIN Status  MN-AAA SS  Connection State (connected, idle, etc.) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 52...
  • Page 55  Manufacturer Pantech, Incorporated IP Information  Netmask  IP Address  Gateway Statistics  Outgoing Bits/Second  Incoming Bits/Second  Incoming Bytes  Outgoing Bytes © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 53...
  • Page 56  Signal Error Rate  PIN Status General Information  Model Nokia Internet Stick CS-18  Unique Identifier  Port  Profiles 1-9  Type modem © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 54...
  • Page 57 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT IP Information  DNS Servers  IP Address  Gateway Statistics  Incoming Bytes  Outgoing Bytes  Connection Uptime (secs) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 55...
  • Page 58  Modem Firmware Version  CINR  Connection State (connected, idle, etc.) General Information  Product U300 – 4G  Protocol Ethernet Static  Unique Identifier  MAC © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 56...
  • Page 59 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT  Type WiMAX  Port  Manufacturer Franklin Wireless Corporation Statistics  Outgoing Bits/Second  Incoming Bits/Second  Incoming Bytes  Outgoing Bytes © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 57...
  • Page 60  Model Nokia Internet Stick CS-18  Type modem  Port  Manufacturer Nokia IP Information  Netmask  IP Address  Gateway Statistics  Outgoing Bits/Second © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 58...
  • Page 61 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT  Incoming Bits/Second  Incoming Bytes  Outgoing Bytes © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 59...
  • Page 62  Manufacturer Novatel Wireless Inc. IP Information  Netmask  IP Address  Gateway Statistics  Outgoing Bits/Second  Incoming Bits/Second  Incoming Bytes  Outgoing Bytes © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 60...
  • Page 63  Connection State (connected, idle, etc.) General Information  Product Wireless As WAN  Unique Identifier  Type wwan IP Information  Netmask  IP Address  Gateway © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 61...

  • Page 64: Routing

    System Routes displays routes associated with networks connected to the router as well as routes learned from routing protocols (such as RIP or BGP). Static Routes displays user-specified routes configured in Network Settings → Routing. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 65 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT GRE Routes displays user-specified routes configured in Internet → GRE Tunnels. VPN Routes displays user-specified routes configured in Internet → VPN Tunnels. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 66 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT NEMO Routes displays user-specified routes configured in Internet → Network Mobility (NEMO). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 64...

  • Page 67: Statistics

    Wireless Statistics: View the signal strength and other wireless modem information. The wireless device’s signal strength will only be displayed as long as it supports “Live Diagnostics.” Sample rate and size can be adjusted from the dropdown boxes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 68 CRADLEPOINT Data Usage: A measure of amount of information that is currently being sent or received through the network. Sample rate and size can be adjusted from the dropdown boxes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 69 Failover/Failback/Load Balance: An easy way to view current connective states of the devices plugged into the router as compared to the past. Sample rate and size can be adjusted from the dropdown boxes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 70: System Logs

    Level: Select/Deselect from the following levels to filter messages by priority.  Critical  Error  Warning  Info NOTE: The logs are erased whenever the router is rebooted or loses power. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 68...

  • Page 71: Vpn Tunnels

    View the status of configured VPN tunnels. To set up or edit a VPN tunnel, go to Internet → VPN Tunnels. Included information:  Name  Connections  Status  Protocols  Transferred  Direction  Time Online  Control © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 69...

  • Page 72: Wipipe Qos

    MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT 5.11 WiPipe QoS View the breakdown of packets and bytes sent and received associated with each WiPipe QoS rule. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 73: Network Settings

     Content Filtering  DHCP Server  DNS  Firewall  MAC Filter / Logging  Routing  Routing Protocols  WiFi / Local Networks  WiPipe QoS © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 71...

  • Page 74: Content Filtering

    When creating rules keep in mind that some sites use multiple domains, so each domain may need a rule added to produce the desired behavior. NOTE: Websites that use HTTPS will not be blocked by these rules. You will need to use OpenDNS to block HTTPS websites. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 75  Rule Priority: Higher number rules overrule lower number rules.  Enabled: A rule can be enabled or disabled by selecting or deselecting the checkbox. Click Submit to save your rule changes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 73...
  • Page 76 This can have the side effect of being very strict; sites that are hosted across many domains may need every domain added to the list for full functionality. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 77 Network WebFilter Rules, except that you must assign a MAC address instead of a network to each rule. See the Network WebFilter Rules section for more configuration details. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 75...
  • Page 78 WebFilter Rules. When a network is set to Block Access, it will block access to sites not specifically allowed in the WebFilter Rules. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 79 Internet Service Provider (ISP) uses the port that OpenDNS is configured to access, port 53, which will prevent OpenDNS filtering. If OpenDNS does not appear to be working correctly, enabling this will attempt to bypass those ports when using an OpenDNS content filtering level. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 80: Dhcp Server

    While you have the option to manually input the information to reserve an IP address (Hostname, Hardware Addr, IP Addr), it is much simpler to select a device under the Active Leases section and click “Reserve.” The selected device’s information will automatically be added under Reservations. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 81: Dns

    CRADLEPOINT 6.3 DNS DNS, or Domain Name System, is a naming system that translates between domain names (www.cradlepoint.com, for example) and Internet IP addresses (206.207.82.197). A DNS server acts as an Internet phone book, translating between names that make sense to people and the more complex numerical identifiers. The DNS page for the MBR1400 has these distinct functions: ...
  • Page 82 Host name: Enter your host name, fully qualified. For example: myhost.mydomain.net. User name: Enter the user name or key provided by the dynamic DNS service provider. If the dynamic DNS provider © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 83 To ensure that the device keeps the same IP address, go to Network Settings → DHCP Server and reserve the IP address for the device by selecting the device in the Active Leases list and clicking “Reserve”. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 84: Firewall

    These numbers will be mapped to the local port numbers.  Local Computer: Select the IP address of an attached device from the dropdown menu, or manually input the IP address of a device. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 85  Protocol: Select from the following options in the dropdown menu: o TCP o UDP o TCP & UDP  Click Submit to save your completed port forwarding rule. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 83...
  • Page 86 IPv6 providers, but it cannot be used effectively in all situations. The primary purpose for CradlePoint’s NPT implementation is for failover/failback and load balancing setups. LAN clients can potentially retain the original IPv6 lease information and may experience a more seamless transition when WAN connectivity changes than if not utilizing NPT.
  • Page 87 IP address for this rule to match against.  Netmask: Use this to define a subnet size this rule will match against.  Port Negation: Match on any port © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 85...
  • Page 88 Protocol: Any IP Source  Network IP: 172.22.24.160 (Johnny’s IP address)  Netmask: 255.255.255.255 (This netmask restricts the rule to one single address).  Port(s): 80 © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 86...
  • Page 89 Point-to-Point Tunneling Protocol. This is enabled by default.  SIP: For VoIP (voice over IP) using Session Initiation Protocol.  TFTP: Enables file transfer using Trivial File Transfer Protocol. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 90 The services affected by this include remote HTTP, HTTPS, SNMP, and SSH configuration tools. This does not restrict access to LAN-based administration, i.e. devices within your network still have administration access. The individual remote administration services can be enabled under System Settings → Administration → Remote Management. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 91 IP address sets will be allowed access. If this field is left empty a netmask of 255.255.255.255 will be used, which means that only the single specified IP address would have remote administration access. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 92: Mac Filter / Logging

    MAC Filter List (Whitelist or Blacklist): Add devices to either your whitelist or blacklist simply by inputting each device’s MAC address. NOTE: Use caution when using the MAC Filter to avoid accidentally blocking yourself from accessing the router. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 93 The time/date that is logged is the time of the first connection. The page may need to be refreshed to show the most recent log entries. Double-clicking on entries from this list will add them to the Ignored MAC Addresses list. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 94: Routing

    Rule. If the IP/Network Address falls outside the LAN IP range, you probably need to select this option. Distribute: Allow this static route to be distributed via a routing protocol (Network Settings → Routing Protocols). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 95: Routing Protocols

     Router-ID: This sets the router-ID of the BGP process. The router- ID may be an IP address of the router, but need not be - it can be any arbitrary 32bit number. However it MUST be unique within the © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 96  Metric: Numerical priority of the route.  Route Map: Route maps provide a means to filter and/or apply actions to routes, allowing policies to be applied to routes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 97  Enabled: Click to enable/disable the policy. (Default: enabled.) Network Areas: Areas are identified by an ID number. As of 4.1.1, CradlePoint only supports area 0. Use the IP address and netmask fields to associate a network with this policy. Also, choose whether to select Passive (active by default).
  • Page 98  Protocol Version: RIP can be configured to send either Version 1 or Version 2 packets. The default is to send RIPv2 while accepting both RIPv1 and RIPv2 (and replying with packets of the appropriate © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 99  Metric: Numerical priority of the route.  Route Map: Route maps provide a means to filter and/or apply actions to routes, allowing policies to be applied to routes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 100 Click Add to create a new route map.  Name: Choose a unique name.  Allow: Select “Permit” or “Deny”.  Order: Input a number to set the order of this policy. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 101 2. Deny: If the entry matches, then finish processing the route-map and deny the route (return `deny'). Set: A route-map entry may, optionally, specify one or more `Set Actions' to set or modify attributes of the route. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 102: Wifi / Local Networks

    For example, one network might be just an isolated WiFi hotspot for guests, while another might be the main network with administrative access, an Ethernet port, a password-protected WiFi SSID, and a VLAN interface. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 100...
  • Page 103 Otherwise guests will need to know the password to connect to the WiFi network even before viewing a Terms of Service page (or other hotspot options). Also, make sure your WiFi interface is “Enabled”. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 104 Name: This primarily helps to identify this network during other administration tasks. Hostname: [Default: cp (for CradlePoint)] The hostname is the DNS name associated with the router's local area network IP address. NOTE: You can access the router’s administration pages by typing the hostname into your browser, so if you change “cp”...
  • Page 105 WAN access will occur on both wireless and wired LAN connections. To enable a Hotspot you must also configure your Hotspot settings under System Settings → Hotspot Services.  Disabled: Disable this network. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 106 LAN is passed through from the WAN side. Change this to Static to input your own IPv6 address range here, or select None to explicitly disable IPv6 LAN connectivity. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 107 WiFi, Ethernet ports, and VLAN interfaces separately. See the Local Network Interfaces section below (on this same administration page: Network Settings → WiFi / Local Networks). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 105...
  • Page 108 Plug and Play) option if you want to enable the UPnP Gateway service for computers on this network.  Admin Access: When enabled, users may access these administration pages on this network. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 106...
  • Page 109 DHCP server needs to be 192.168.0.5 or higher. Lease Time: [Default: 720 minutes (12 hours)] The lease time specifies how long DHCP-enabled computers will wait before requesting a new DHCP lease. Smaller values are better suited to busy environments. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 110 DHCP Server Address: An optional DHCP server address if more than one DHCP server is located on the network. This field is only available when DHCP Relay is enabled. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 111  IPv6 DHCP Lease Time: This specifies how long DHCP-enabled computers will wait before requesting a new DHCP lease. Disable SLAAC and DHCP – Disable both IPv6 address configuration modes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 112 LAN. In rare cases, additional IP address ranges need access to the multicast streams. Click Add and input the IP Address and Netmask for an additional IP address range. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 113 Click on the squares to toggle between black and gray. In the example shown, the network is enabled from 8-5 on Monday through Friday, but disabled at all other times. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 111...
  • Page 114 RFC 3768. Select None or Simple. If you select Simple, input a VRRP group password. Provide Virtual IP in DHCP leases: Select this to automatically set the DHCP default gateway address and DNS server address to the virtual IP in DHCP leases provided on this network. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 115 If you want this router to be the root bridge, then set it to a value less than the default of 32768. A valid priority value is between 0 and 65535. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 116 RADIUS server is the same for both authentication and accounting.  Acct Server IP Address  Acct Server MAC Address  Port: 1813 is common for the accounting port.  Password © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 114...
  • Page 117 Wireless Radio: Enable/Disable. (Default: Enabled). Leave enabled unless you don’t want any WiFi networks broadcast from your router. Select a WiFi network and click Edit to change the settings. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 118 WiFi Name (SSID): When users browse for available wireless networks, this is the name that they will see. This name is referred to as the SSID (service set identifier). For security purposes, CradlePoint highly recommends that you change this from the pre- configured name.
  • Page 119 NOTE: If you don’t know whether you should choose Personal or Enterprise, assume Personal since you need to know RADIUS authentication for Enterprise. In order to protect your network from hackers and unauthorized users, CradlePoint highly recommends WPA2/AES for security if your attached devices can support it. WEP and WPA/TKIP are obsolete and have been replaced by WPA/AES.
  • Page 120  Auto  10Mbps - Half Duplex  10Mbps - Full Duplex  100Mbps - Half Duplex  100Mbps - Full Duplex  1000Mbps - Full Duplex © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 118...
  • Page 121 (or highlight a port and click the + button). To deselect an Ethernet port, double-click on an interface in the Selected section (or highlight the port and click the – button). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 122 VLAN ID from a dropdown list. Your Ethernet group must be created separately under Ethernet Port Configuration. Click Submit to save your configured VLAN. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 123 WiMAX modem. If no WiMAX modem is attached, then default channel and power settings will be used even if this is selected. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 124  161 (5805 MHz)  165 (5825 MHz) Client Timeout: If the access point is not able to communicate with the client it will disconnect it after this timeout (in seconds). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 125 Disabling this option forces all clients to use a longer backoff check and thus may reduce network throughput while reducing the number of transmission collisions. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 126 (in seconds) before attempting another query. This helps protect the network from floods of authentication requests if the RADIUS server is temporarily unreachable. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 127: Wipipe Qos

    NOTE: Upload speed is the speed at which data can be transferred to your ISP. Download speed is the speed at which data can be transferred to you from your ISP You can test your connection speeds with a service such as speedtest.net. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 128 Upload Bandwidth: This is the percentage of the connected WAN upload bandwidth that will be reserved for the specified traffic. The maximum value is adjusted to the remaining percentage after other rules receive their share. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 129 Download Bandwidth: This is the percentage of the connected WAN upload bandwidth that will be reserved for the specified traffic. The maximum value is adjusted to the remaining percentage after other queues receive their share. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 130 DSCP Tags as opposed to IP addresses or ports. This setting is optional. For more information see the Differentiated services Wikipedia page. Click Finish to save this queue. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 128...
  • Page 131 6.9.2 A traffic shaping rule identifies a specific message flow and assigns that flow to one of the queues created above. Click Add to create a new Traffic Shaping rule. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 132 Queue Name: Select a queue to associate this rule with. Click Next to continue to the next page. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 133 Differentiated services Wikipedia page. DSCP Negate: When checked this rule will match on any packet that does not match the DSCP field. Click Finish to save this rule. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 134: Internet

     Data Usage  GRE Tunnels  Network Mobility (NEMO)  NHRP Interfaces  VPN Tunnels  WiFi as WAN / Bridge  WAN Affinity / Load Balancing © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 132...

  • Page 135: Connection Manager

    Click on the small box at the top of the list to select/deselect all devices for either Load Balance or Enabled. Click on a device in the list to reveal additional information about that device and to enable configuration options. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 136  Uptime (in seconds) Click “Edit” to view configuration options for the selected device. For USB or ExpressCard modems, click “Control” to view options to activate or update the device. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 137  MTU: Maximum transmission unit. This is the size of the largest protocol data unit that the device can pass. (Range: 46 to 1500 Bytes.)  Hostname (This only shows for certain devices.) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 138 WAN connections can use. For best results, select an established public IP address. For example, you might ping Google Public DNS at 8.8.8.8 or Level 3 Communications at 4.2.2.2. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 139 Immediate failback returns you to the use of your preferred Internet source more quickly which may have advantages such as reducing the cost of a failover data plan, but it may cause more interruptions in your network than Usage or Time modes. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 140 Override any of the following fields:  IP Address  Subnet Mask  Gateway IP  Primary DNS Server  Secondary DNS Server © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 138...
  • Page 141 IPv4 packet and routed back over an IPv4 route. Some tunnel modes do not require upstream ISPs to route or even be aware of IPv6 traffic at all. Some modes are utilized by upstream ISPs to simplify the configuration and rollout of IPv6. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 142 IP connectivity without relying on any translation mechanism. In order to achieve this, each client device on the LAN network needs to have a publicly routable IPv6 address. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 143 Prefixes specified here only take effect if those supplied by the connection are insufficient to configure your LANs.  Delegated IPv6 Network – Additional network available for delegation to LANs. Example Configuration: © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 144 Prefixes specified here only take effect if those supplied by the connection are insufficient to configure your LANs.  Delegated IPv6 Network – Additional network available for delegation to LANs. Example Configuration: © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 145 Prefixes specified here only take effect if those supplied by the connection are insufficient to configure your LANs.  Delegated IPv6 Network – Additional network available for delegation to LANs. Example Configuration: © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 146 Prefixes specified here only take effect if those supplied by the connection are insufficient to configure your LANs.  Delegated IPv6 Network – Additional network available for delegation to LANs. Example Configuration: © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 147 Prefixes specified here only take effect if those supplied by the connection are insufficient to configure your LANs.  Delegated IPv6 Network – Additional network available for delegation to LANs. Example Configuration: © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 148  PPPoE should be configured with the username, password and other settings provided by your ISP. If you want to use a Static (Manual) or PPPoE connection, you will need to fill out additional information. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 149  Gateway IP  Primary DNS Server  Secondary DNS Server PPPoE:  Username  Password  Password Confirm  Service  Auth Type: None, PAP, CHAP © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 147...
  • Page 150 Network-Initiated Schedule: When you select “On Schedule” for Network-Initiated Alerts, you also select a time from this dropdown list. Modem updates will take place at this scheduled time. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 151  Force 3G (EVDO, UMTS, HSPA): Connect to 3G network only.  Force 2G (1xRTT, EDGE, GPRS): Connect to 2G network only. See the following tables for a breakdown of the technologies used with various CradlePoint COR models when any Modem Connection Mode is selected.
  • Page 152 Each command must be entered on a separate line. All command responses must include “OK” except the final command response, which must include “CONNECT”. Example: ATDT*99***2# © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 150...
  • Page 153 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 151...
  • Page 154  HA Shared Secret: “Home Agent” shared secret.  Primary HA.  Secondary HA.  AAA SPI: AAA Security Parameter Index.  HA SPI: HA Security Parameter Index. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 152...
  • Page 155 TTLS Username: Username for TTLS authentication. TTLS Password: Password for TTLS authentication. WiMAX Authentication Identity: User ID on the network. Leave this blank unless your provider tells you otherwise. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 156 For Verizon modems, only the third slot is editable. Changes made here are written to the modem, so a factory reset of the router will not impact these settings. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 157 However if you try to start a different operation or use a different modem, this second request will fail without interfering with the pending operation. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 158 Select any of these rules and click “Edit” to change the settings for a rule. To create a new rule, click “Add.” © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 159 Select by ID. This is generated by the router and displayed when the device is connected to the router. Condition: Select “is,” “is not,” “starts with,” “contains,” or “ends with” to create your condition’s statement. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 160 Ethernet Settings, Modem Settings, WiMAX Settings, CDMA Settings, and SIM/APN Settings have the same configuration options shown above in the WAN Configuration section (the options for Configuration Rules are the same as they are for individual devices). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 161: Client Data Usage

    The names that are shown are received during a DHCP exchange. If a client disconnects and reconnects with a new IP address there will be an additional entry in this list. Pressing Reset Statistics will restart all counters at 0. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 162: Data Usage

    CradlePoint cannot be held responsible. You must accept the agreement by clicking Yes in order to begin creating data usage rules.
  • Page 163 This causes Load Balancing to spread the data usage between interfaces according to the assigned usage rather than bandwidth. This is a best effort to © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 164 Percent of Usage (1-1000): If selected, a custom alert will be sent when your data usage reaches this percentage of your usage cap. For example, you could set this at 90 percent so that you know when your usage is nearing 100 percent of the cap. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 165 The rest of the rule settings options match those in the Data Usage Rules. See the section above for additional information about how to configure your template usage rules. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 166: Gre Tunnels

     Optionally, you might also want to enable the tunnel Keep Alive feature to monitor the status of a tunnel and more accurately determine if the tunnel is alive or not. Click Add to configure a new GRE tunnel. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 167 Remote Gateway: This is the public facing, WAN-side IP address of the network that the local gateway is going to connect to. Tunnel Enabled: Select to activate the tunnel. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 168 Netmask of 255.255.255.255. Click Save to record each new route. When you have finished adding routes, click Finish to save your GRE tunnel configuration. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 169: Network Mobility (Nemo)

    Home IP Address and Home Netmask – These may be provided by your NEMO service provider. The IP address is a placeholder, “dummy” address; any IP address can be used (1.2.3.4 is common). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 170 (maximum transmission unit) of the NEMO tunnel. The TCP (maximum segment size) is automatically derived from the MTU. Leave blank to rely on Path MTU Discovery. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 168...

  • Page 171: Nhrp C

    (multipoint GRE) tunnel. Select from configured GRE tunnels or input manually.  Peer Authentication: Embeds the secret plaintext password to outgoing NHRP packets. Incoming NHRP © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 169...
  • Page 172  Non-Caching: Disables caching of peer information from forwarded NHRP resolution reply packets.  Shortcut: Enable creation of shortcut routes.  Redirect: Enable sending of proprietary enterprise-style NHRP traffic indication packets. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 173: Vpn T

    The VPN tunnel status page allows you to view the state of the VPN tunnels. If a tunnel fails to connect to the remote site, check the System Logs for more information. You may double click on a cell to directly edit that information. Click Add to configure a new VPN tunnel. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 174 Authentication Mode: Select from Pre-Shared Key and Certificate. Pre-Shared Key is used when there is a single key common to both ends of the VPN. Certificate requires the creation of a set of certificates and a private key that can be © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 175 Condition: Select “is,” “is not,” “starts with,” “contains,” or “ends with” to create your condition’s statement. Value: If the correct values are available, select from the dropdown list. You may need to manually input the value. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 176 WAN Binding device(s) are NOT connected. This is typically useful when the VPN tunnel is being used as a hot- spare on a router with multiple active WAN connections and the VPN tunnel is only needed in the absence or unavailability of a particular WAN device (for example, an MPLS-based WAN device). © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 177 Enter the Network IP address with the Subnet Mask to define the remote network subnet that the local devices will have access to. NOTE: The remote network IP address must be different from the local network IP address. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 178 IKE will renegotiate a new set of Phase 1 keys. Encryption, Hash, and DH Groups: Each IKE exchange uses one encryption algorithm, one hash function, and one DH group to make a secure exchange. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 179 The algorithms are listed in order by priority. You can reorder this priority list by clicking and dragging algorithms up or down. Any selected algorithm may be used for IKE exchange, but the algorithms on the top of the list are more likely to be used more often. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 180 Phase 2 has the same selection of Encryption, Hash, and DH Groups as Phase 1, but you are restricted to only one DH Group. Phase 2 and Phase 1 selections do not have to match. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 181 Additionally, you can specify how many Maximum Requests to send at the selected time interval before the tunnel is considered dead. You must click Finish to save your VPN tunnel. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 182 DH Groups  DPD Click Yes at the bottom of the Tunnel Summary page to save your configuration changes. This will cause active tunnels to restart. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 180...
  • Page 183 IKE / ISAKMP NAT-T Port: Internet Key Exchange / Internet Security Association and Key Management Protocol network address translation traversal port. Default: 4500. This is a standard VPN NAT-T port that usually does not need to be changed. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 184 2. The Tunnel Name for the side of the tunnel that is not behind the NAT firewall must be “anonymous”. 3. The VPN tunnel must be initiated from the side that is behind the NAT firewall. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 185: Wifi As Wan / Bridge

    Unless a selected WiFi source is on an unprotected network, you will need to know its password or key. All CradlePoint routers and some other routers use the same default IP address for the primary network, 192.168.0.1. If you attempt to set up WiFi as WAN and there is an “IP conflict,”...
  • Page 186 When in WiFi Bridge mode with a configured profile, a WiFi Bridge device will be added to the local network interfaces, providing a way to bridge two LANs over a WiFi connection. For example, two separate CradlePoint routers linked through WiFi Bridge mode allows you to have one WiFi-connected network in two separated sections of a large office building.
  • Page 187 If you click on a network in the Site Survey, you can import it as a saved profile. You can sort the list based on any of the fields by clicking on the field name. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 188 If you import a network from Site Survey, most of the information about the network will already be completed. You need to input the password (if there is one) and then click submit to save the WiFi as WAN profile. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 189 Scan While Connected: Continue to scan for WiFi as WAN profile updates when connected. Each time a scan occurs the wireless communication of the router will be temporarily interrupted. Normally this should be disabled. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 190: Ffinity And Load Balancing

    LAN, saving you money. Click “Add” to open the WAN Affinity Policy Editor and create a new WAN Affinity rule. Name: Give a name for your rule that is meaningful to you. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 191 LAN here (leaving the last slot “0” to allow for any user attached to the guest network):  Source IP Address: 192.168.10.0  Source Netmask: 255.255.255.0 © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 189...
  • Page 192  Round-Robin: Evenly distribute each session to the available WAN connections.  Rate: Distribute load based on the current upload and download rates. A WAN device's upload and download bandwidth values can be set in Internet → Connection Manager. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 193 Data Usage rule for each interface, rather than distributing sessions based solely on bandwidth. For proper function you need to create data usage rules for each WAN device you will be load balancing. Make certain to select the "Use with Load Balancing" checkbox in the Data Usage rule editor. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 194: System Settings

     Administration  Device Alerts  Enterprise Cloud Manager  Feature Licenses  Hotspot Services  Serial Redirector  SNMP Configuration  System Control  System Software © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 192...

  • Page 195: Administration

    Admin Password: Enter a password for the administrator who will have full access to the router's management interface. You can use the default password on the back of your product, or you can create a custom Administrator Password. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 196 Local Users mode to prevent users from being locked out. Authentication Service: Choose from:  ASCII / Login  PAP © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 194...
  • Page 197 "1.2.3.4", or a DNS name in form of "host.domain.com". Only lower case letters are allowed for a DNS name. Port: Port 1812 is common for RADIUS servers. Shared Secret © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 195...
  • Page 198 Time Zone: Select from a dropdown list. Setting your Time Zone is required to properly show time in your router log. Daylight Savings Time: Select this checkbox if your location observes daylight savings time. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 199 Enable SSH Server: When the router's SSH server is enabled you may access the router's command line interface (CLI) using the standards-based SSH protocol. Use the username "admin" and the standard system password to log in. SSH Server Port: Default: 22. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 200 SSH access is enabled in the Local Management tab. Some Carriers block the remote SSH Access ports. If a ping to the router's WAN port does not work, it is unlikely that remote SSH Access will work. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 201 Remote server hostname or IP o Remote server port o Report only over specific time interval: Restricts the NMEA sentence reporting to a remote server to a specific time interval. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 202 No last update DGPS reference station id blank No station id Checksum Used by program to check for transmission errors Courtesy of Brian McClure, N8PQI. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 200...
  • Page 203 = Number of satellites in use [not those in view] = Horizontal dilution of position = Antenna altitude above/below mean sea level (geoid) 10 = Meters (Antenna height unit) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 204 12 = Meters (Units of geoidal separation) 13 = Age in seconds since last update from diff. reference station 14 = Diff. reference station ID# 15 = Checksum © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 205 If this occurs, disable this option. Log to attached USB stick: Only enable this option if instructed by a CradlePoint support agent. This will write a very verbose log file to the root level of an attached USB stick. Please disable the feature before removing the USB stick, or you may lose some logging data.
  • Page 206 DNS Server and Secondary DNS Server: The primary and secondary DNS server numbers match the static DNS values (set at Network Settings → DNS). You can leave the default values or set them manually here. (Changing these values also changes the static DNS values.) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 207: Device Alerts

     Recurring System Log: The system log is sent periodically. This alert contains all of the system events since the last recurring alert. It can be scheduled for daily, weekly and monthly reports (Frequency). You also choose the Time you want the Alert sent. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 208  To Address: Your email address Once you have filled in the information for the SMTP server, click on the “Verify SMTP Settings” button. You should receive a test email at your account. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 209 Retry Attempts: The number of attempts made to send an alert to the mail server. After the attempts are exhausted, the alert is discarded. Retry Delay: The delay between retry attempts. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 210: Enterprise Cloud Manager

    MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT 8.3 Enterprise Cloud Manager CradlePoint ECM is a cloud-based management service for configuring, monitoring, and organizing your CradlePoint routers. Key features include:  Group based configuration management  Health monitoring of router connectivity and data usage ...
  • Page 211  Ethernet Communication Only: Select this to ensure that the WiPipe Central client will not start unless the WAN is Ethernet.  Registration URL: Register your router using the code provided by CradlePoint when you purchase WiPipe Central. © 2013 CRADLEPOINT, INC.

  • Page 212: Feature Licenses

    CRADLEPOINT 8.4 Feature Licenses Some CradlePoint features may require a license. These features are disabled by default. To obtain a feature license, contact your CradlePoint sales representative. Once you have obtained the feature license file, upload the file to enable the feature. A reboot is required after uploading a feature license file.

  • Page 213: Hotspot Services

    Redirect HTTPS Requests: This allows initial requests to HTTPS websites to be redirected appropriately. Hotspot/UAM Authentication Port: Default: 8000. Type in a different port number, or use the slider to change the port. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 214 Idle Timeout: (Default: 15 minutes.) If the user is idle for this amount of time, make them re-authenticate. Bandwidth (upload): (Default: 512 Kbits/sec.) The data rate limit for users uploading data through the hotspot. Bandwidth (download): (Default: 1024 Kbits/sec.) The data rate limit for users downloading data through the hotspot. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 215  Bandwidth (upload): (Default: 512 Kbits/sec.) The data rate limit for users uploading data through the hotspot.  Bandwidth (download): (Default: 1024 Kbits/sec.) The data rate limit for users downloading data through the hotspot.  © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 216 Click Submit to save your additions. Authorized MAC Addresses 8.5.4 Add the MAC addresses of trusted machines you want to give automatic access through the Hotspot portal. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 214...

  • Page 217: Serial Redirector

    USB Serial Adapter Configuration 8.6.2 Baud Rate: Select from the dropdown list.  50  75  110  134  150  200  300  600 © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 215...
  • Page 218 Software (XON/XOFF): Use XON/XOFF to enable flow control. Linefeed: Select how you want linefeeds translated (CR = carriage return and LF = line feed).  Ignore  CR/LF  CR  LF © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 216...

  • Page 219: Snmp Configuration

    You might use this instead of WiPipe Central if you want to remotely manage a set of routers that include both CradlePoint and non- CradlePoint products. Enable SNMP: Selecting “Enable SNMP” will reveal the router’s SNMP configuration options.
  • Page 220 8 characters long. Enable SNMP traps: Enabling traps will allow you to configure a destination server, community, and port for trap notifications. Trap notifications are returned to the server with SNMPv1. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 221 System Contact: Input the email address of the system administrator. System Name: Input the router’s hostname. System Location: Input the physical location of the router. This is simply a string for your own information. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 222: System Control

    Ping Test: A simple test to check Internet connectivity. Type the Hostname or IP address of the computer you want to ping and press 'Enter' or click the 'Ping' button. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 223: System Software

    This allows the administrator to load new firmware onto the router to add new features or fix defects. If you are happy with the operation of the router, you may not want to upgrade just because a new version is available. Check the firmware release notes (www.cradlepoint.com/firmware) for information to decide if you should upgrade. Current Firmware Version: Shows the number of the current firmware and the date it was updated.
  • Page 224 Restore Settings: Click on “Upload from file” to restore your previous settings from a file on a computer. Firmware Upgrade and System Config Restore 8.9.3 Load new firmware and restore your previous settings from a file on a computer without rebooting between steps. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 225: Glossary

    The loss in strength of digital and analog signals. The Advanced Encryption Standard loss is greater when the signal is being transmitted over AES. Government encryption standard. long distances. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 223...
  • Page 226 Internet access from your A data frame by which one of the stations in a WiFi Cable provider. network periodically broadcasts network control data to other wireless stations. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 224...
  • Page 227 Default A predetermined value or setting that is used by a program when no user input has been entered for this value or setting. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 225...
  • Page 228 Domain Name System: Translates Domain Names to IP Email addresses. Electronic Mail is a computer-stored message that is Domain name transmitted over the Internet. A name that is associated with an IP address. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 226...
  • Page 229 Programming that is inserted into a hardware device that H.323 tells it how to function. A standard that provides consistency of voice and video transmissions and compatibility for video conferencing devices. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 227...
  • Page 230 A networking device that connects multiple devices Internet Protocol together. The method of transferring data from one computer to ICMP another on the Internet. Internet Control Message Protocol. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 228...
  • Page 231 LAN. A group of computers in a building that usually developed by Novell to enable their Netware clients and access files from a server. servers to communicate. Internet Service Provider. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 229...
  • Page 232 Determines what portion of an IP address designates the computer. Network and which part designates the Host. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 230...
  • Page 233 A logical channel endpoint in a network. A computer changes to the routing table are sent to all the other might have only one physical channel (its Ethernet © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 234 To restart a computer and reload its operating software A computer on a network that provides services and or firmware from nonvolatile storage. resources to other computers on the network. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 235 Simple Network Management Protocol. TCP Raw SOHO A TCP/IP protocol for transmitting streams of printer data. Small Office/Home Office. TCP/IP Transmission Control Protocol/Internet Protocol. Stateful Packet Inspection. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 233...
  • Page 236 Sending voice information over the Internet as opposed product. to the PSTN Upgrade VoIP To install a more recent version of a software or firmware Voice over IP. product. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 234...
  • Page 237 Wireless Fidelity. Used to describe any of the 802.11 A generic term for the family of digital subscriber line wireless networking specifications. (DSL) technologies, such as ADSL, HDSL, RADSL, and SDSL. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 235...
  • Page 238 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT Yagi antenna A directional antenna used to concentrate wireless signals on a specific location. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 236...

  • Page 239: Appendix

    (including death) to the user or to any other party. CradlePoint expressly disclaims liability for damages of any kind resulting from: (a) delays, errors, or losses of any data transmitted or received using the device; or (b) any failure of the device to transmit or receive such data.
  • Page 240 CradlePoint, Inc. warrants this product against defects in materials and workmanship to the original purchaser (or the first purchaser in the case of resale by an authorized distributor) for a period of one (1) year from the date of shipment. This warranty is limited to a repair or replacement of the product, at CradlePoint’s discretion. CradlePoint does not warrant that the operation of the device will meet your requirements or be error free.
  • Page 241 OTHER BINDING DOCUMENTS; TRADEMARKS; COPYRIGHT By activating or using your MBR1400 device, you agree to be bound by CradlePoint’s Terms of Use, User License and other Legal Policies, all as posted at www.cradlepoint.com/legal. Please read these documents carefully. CradlePoint, the CradlePoint logo, and MBR1400 are trademarks of CradlePoint, Inc.

  • Page 242: Specifications

     Create, manage, and terminate up to 20 IPsec WiFi On/Off Switch, WPS Button (WiFi Protected Setup), VPN sessions Modem Signal Strength, Reset, and Power Switch  Supported VPN implementations: CradlePoint to LED INDICATORS CradlePoint, CradlePoint to Cisco/Linksys Power, Ethernet LAN (1-4), Ethernet WAN, 3G/4G WAN, Routers, and CradlePoint to Linux Systems ...
  • Page 243 MBR1400 | USER MANUAL – Firmware version 4.4 CRADLEPOINT http://www.cradlepoint.com/ Copyright © 2013 by CradlePoint, Inc. All rights reserved. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 241...

This manual is also suitable for:

Mbr1400lp2-euMbr1400wMbr1400lp-atMbr1400lp

Table of Contents
