Summary of Contents for Hoover DDY 075
- Page 1 User instructions ® DDY 075 DISHWASHER...
-
Page 3: Table Of Contents
CONTENTS Safety advice pag. Setting up, installation pag. Water softener unit pag. Loading the salt pag. Adjusting the upper basket pag. Loading the dishes pag. Loading the detergent pag. Types of detergent pag. Loading the rinse aid pag. Cleaning the filters pag. -
Page 4: Safety Instructions
The door should not be left in the open SAFETY INSTRUCTIONS position since this could present a potential hazard ( es. tripping ). There are certain basic safety rules which are valid for any domestic Leaning or sitting on the open door of appliance. -
Page 5: Electrical Connection
Cutlery is washed best if it is placed in Disposal the basket with the handles downwards. If the appliance breaks down or stops The dishwasher has been made from working properly, switch it off, turn off the materials which can be recycled so that it water supply and do not tamper with it. -
Page 6: Water Connection
Water connection IMPORTANT The appliance must be connected to the water mains using new hose-sets. The old hose-sets should not be reused. The inlet and drain hoses can be directed to left or right. IMPORTANT The dishwasher can be connected to either cold or hot water, as long as it is no hotter than 60 °C. - Page 7 The hose can be hooked over the side of Connecting the outlet hose the sink, but it must not be immersed in water, in order to prevent water from being syphoned back to the machine The outlet hose should disharge into a when this is in operation (fig.
-
Page 8: Opening The Door
INSTALLATION IN FITTED Underneath existing work top KITCHENS (when fitting beneath a work top) Fitting between existing cabinets In most modern fitted kitchens there is only one single work top under which cabinets and electrical appliances are The height of the dishwasher, 85 cm, has fitted. -
Page 9: Water Softener Unit
WATER SOFTENER UNIT * The softener unit is set in the factory at level 4 (d4) as this satisfies the requirements of the majority of users. Depending on the source of the supply, water contains varying amounts of limestone and minerals which are deposited on the Regulate the setting of your water softener dishes leaving whitish stains and marks. -
Page 10: Loading The Salt
LOADING THE SALT IMPORTANT (Only for first start up) When the appliance is used for the On the bottom of the machine there is a first time, after completely filling the container for the salt for regenerating salt container, it is necessary to add the softener. - Page 11 ADJUSTMENT OF THE UPPER BASKET If 27 cm to 31 cm plates are normally used, load them onto the lower basket after the upper basket has been placed in its upper position and proceed as detailed below: 1. Turn the front stops “A” outwards; 2.
-
Page 12: Loading The Dishes
LOADING DISHES A standard daily load is represented in figs. 1, 2 and 3. Using the upper basket Upper basket (fig. 1) A = soup plates B = dinner plates The upper basket is provided with C = dessert plates mobile racks hooked to the sides of the D = saucers basket, which can be regulated into two... -
Page 13: Using The Lower Basket
- POSITION “B”: for dishes which, Upper basket (fig. 3) although standard size, have a particular A = glasses shape (very deep bowls, square dishes B = saucers or ones without borders etc.). C = cups D = small bowl - POSITION “C”: for larger than average E = medium bowl flat plates and/or ones with non-... - Page 14 A standard daily load is represented in Please load the dishwasher sensibly to figs. 7 and 8. ensure the best wash results. Lower basket (fig. 7) IMPORTANT A = medium-sized saucepan The lower basket has a safety-stop B = large saucepan device, for its safe extraction, also C = frying pan especially useful with a full load.
-
Page 15: Loading The Detergent
LOADING THE DETERGENT The detergent IMPORTANT It is essential to use a detergent that is specifically designed for dishwashers either in powder, liquid or tablet form. After pouring the detergent into the container, close the lid, firstly pushing (1) and then pressing on it (2) until you hear the click. -
Page 16: Types Of Detergent
TYPES OF DETERGENT If when using this type of product, you don't get satisfactory washing results, please contact detergent Detergent tablets manufacturer. Detergent tablets of different manufacturers In certain circumstances use of combined dissolve at different speeds, for this detergents can cause: reason, during short programmes, some detergent tablets may be not fully effective, because they are not completely dissolved. -
Page 17: Loading The Rinse Aid
LOADING THE RINSE AID The rinse aid The rinse aid, which is automatically released during the last rinsing cycle, helps the dishes to dry quickly and prevents spots and stains forming. Filling the rinse aid container The rinse aid container can be found to the left of the detergent container (fig. -
Page 18: Cleaning The Filters
CLEANING THE FILTERS The filter system (fig.A “4”) consists of: a central container that traps the larger particles; a flat gauze that continuously filters the wash water; a micro filter, located beneath the gauze, that traps the tiniest particles ensuring a perfect rinse. - Page 19 PRATICAL HINTS How to make savings How to get really good wash If you want the dishwasher to give a complete wash, place the dishes in the results dishwasher at the end of each meal and if necessary turn on the COLD RINSE Before placing the dishes in the cycle to soften the food remains and dishwasher, remove any remaining...
-
Page 20: Cleaning And Maintenance
CLEANING AND MAINTENANCE To clean the dishwasher outside, do not use solvents (degreasing action) neither abrasives, but only a cloth soaked with water. The dishwasher does not require special maintenance, because the tank is self-cleaning. Regularly wipe the door gasket with a damp cloth to remove any food remains or rinse aid. -
Page 21: Description Of The Control Panel
DESCRIPTION OF THE CONTROL PANEL "ON/OFF" button DIGITAL DISPLAY "PROGRAMME SELECTION" button "SALT EMPTY" light "DELAY START" button "RINSE AID EMPTY" light "START"/"RESET" button "OPTION SELECTION" lights (start/cancelling programme) "ACTION PRO" lights "SUPER ECO" option button Programme guide "ALL IN 1" option button "ACTION PRO"... -
Page 22: Programme Selection And Special Functions
PROGRAMME SELECTION If you wish, press the "ACTION PRO" button. AND SPECIAL FUNCTIONS (Use in conjunction with programme guide) If you wish to select an option, press the corresponding button (the indicator light will turn on). IMPORTANT The dishwasher has a very practical The option buttons can be selected or function: deselected WHITIN one minute of the... - Page 23 Programme end WARNING! If you open the door during the A 5 second alarm will sound (if not muted) drying cycle, an audible audio signal 3 times at 30 second intervals to signal that the programme has ended. advises you that the drying cycle has The display and all the indicator lights will not yet finished.
- Page 24 "DELAY START" button Alarm mute for the PROGRAMME Dishwasher start time can be set with this button, delaying start from 1 to 23 hours. The alarm for the programme end may be muted as follows: Proceed as follows to set a delayed start: IMPORTANT The dishwasher must be ALWAYS off Press the "DELAY START"...
- Page 25 The dishwasher is able to signal a series of faults in the display. AUTOMATIC FAULT SIGNALS FAULTS CAUSE SOLUTION No water (inlet hose closed). Turn off the dishwasher, open the appears on the display and inlet hose and reset the cycle. the alarm sounds.
-
Page 26: Programme Guide
PROGRAMME GUIDE Wash with prewash For wash programmes with prewash, it is advisable to add a second dose of detergent (max. 5.75 g) directly in the machine. Programme Description An antibacterial cycle, intended for washing and Hygiene+ sterilising dishes (even heavily stained ones) 75°C babies’... - Page 27 Avarage Special function Programme contents Check list duration buttons in minutes available • • • • • 75°C (5.75 g) (28 g) • • • • • 75°C (5.75 g) (28 g) • • • • • 65°C (5.75 g) (28 g) •...
-
Page 28: Aquaprotect
AQUAPROTECT – PROTECTED INCOMING WATER PIPE The main inlet pipe is contained within a protective transparent hose. In the event of damage occurring to the main inlet pipe any water leakage is retained within the transparent hose. If water has leaked from the main inlet pipe there will be a visible sign within the transparent hose. -
Page 29: Identifying Minor Faults
IDENTIFYING MINOR FAULTS Should the dishwasher fail to operate, before contacting the Service Centre, make the following checks: FAULT CAUSE REMEDY Plug is not connected to wall Connect electric plug socket O/I button has not been pressed Press button 1 - Machine completely dead Door is open Close door No electricity... - Page 30 FAULT CAUSE REMEDY See causes for no. 5 Check Bottom of saucepans have not Burnt on food remains must been washed well be soaked before putting pans in dishwasher Edge of saucepans have not Reposition saucepans been washed well Spray arms are partially blocked Remove spray arms by unscrewing ring nuts clockwise and wash under running water...
- Page 31 The manufacturer declines all responsibility in the event of any printing mistakes in this booklet. The manufacturer also reserves the right to make appropriate modifications to its products without changing the essential characteristics.
- Page 32 This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
