INSTALLATION AND OPERATING INSTRUCTIONS

WARNING: If the information in these
instructions are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or death.
⎯ Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
⎯ WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building;
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
⎯ Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home or mobile home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
For Residential Use-Meets All HUD Requirements For
Manufactured Housing Installations
• READ BEFORE INSTALLING OR OPERATING AND SAVE THESE INSTRUCTIONS •
7000 SERIES
SUPER B-VENT GAS FIREPLACE
MODELS: 724BV(4536,5142)(N,P)(V,E)B
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED OUT OF
TRAFFIC AND AWAY FROM FURNITURE
AND DRAPERIES.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURE AND SHOULD
STAY AWAY TO AVOID BURNS OR
CLOTHING IGNITION.
YOUNG CHILDERN SHOULD BE
SUPERVISED WHEN THEY ARE IN THE
SAME ROOM AS THE APPLIANCE.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED ON
OR NEAR THE APPLIANCE.
KEEP THE ROOM AREA CLEAR AND FREE
FROM COMBUSTIBLE MATERIALS,
GASOLINE, AND OTHER FLAMMABLE
VAPORS AND LIQUIDS.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Monessen Hearth 7000 Series

  • Page 1: Installation And Operating Instructions

    7000 SERIES SUPER B-VENT GAS FIREPLACE INSTALLATION AND OPERATING INSTRUCTIONS MODELS: 724BV(4536,5142)(N,P)(V,E)B WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or death. ⎯ Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2: Table Of Contents

    IMPORTANT SAFETY INFORMATION:......................2 PRODUCT SPECIFICATIONS: ..........................3 ..........................3 LTITUDE NSTALLATIONS LISTING & CODE APPROVAL: ..........................3 PRE-INSTALLATION INFORMATION: .......................4 :..............................4 EFORE TART : ...............................4 IREPLACE OCATION : ....................7 ALL AND EILING LEARANCE EQUIREMENTS :.............................7 OMBUSTIBLE LEARANCES :..............................8 ANTEL LEARANCES :..............................8 LOOR LEARANCES :..............................9 INISHING ATERIAL...
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION: INSTALLER: Please leave these instructions with the appliance. OWNER: Please read and retains these instructions for future reference. IMPORTANT: Read these instructions carefully before installing or trying to operate this appliance. • DO NOT use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control, which has been under water.
  • Page 4: Product Specifications

    & & PRODUCT SPECIFICATIONS: Gas Pressure (Inches W.C.) Models Number Gas Type Control Type Max Btu Manifold 724BV4536NV Natural Gas Milli-volt 50000 10.5 724BV4536PV Propane/LPG Milli-volt 50000 13.0 11.0 10.0 724BV5142NV Natural Gas Milli-volt 50000 10.5 724BV5142PV Propane/LPG Milli-volt 50000 13.0 11.0 10.0...
  • Page 5: Pre-Installation Information

    PRE-INSTALLATION INFORMATION: Before You Start: Read this homeowner manual thoroughly and follow all instructions carefully. Inspect all contents for shipping damage and immediately inform your dealer if any damage is found. Do not install any unit with damaged, incomplete, or substitute parts. Contents: •...
  • Page 6 Figure 1: Fireplace Dimensions...
  • Page 7 Figure 2: Fireplace Locations and Minimum Clearances Requirements CAUTION: Measure fireplace dimensions and verify framing methods & wall covering details before framing construction begins.
  • Page 8: Wall And Ceiling Clearance Requirements

    Figure 3: Wall & Ceiling Minimum Clearances Wall and Ceiling Clearance Requirements: Ensure that minimum clearances shown in Figure 3 are maintained. Left and right clearances are determined when facing the front of the appliance. Follow these instructions carefully to ensure safe installation. Failure to follow these requirements may create a fire hazard.
  • Page 9: Mantel Clearances

    Mantel Clearances: If a combustible mantel is installed, it must meet the clearance requirements detailed in Figure 4. Figure 4: Mantel Clearance Floor Clearances: The fireplace may be installed on a flat, hard combustible surface (i.e. flat wood, plywood, or particleboard). Be sure that the fireplace rests on a solid continuous floor or platform with appropriate framing support.
  • Page 10: Finishing Material

    CAUTION Measure fireplace dimensions and verify framing methods & wall covering details before framing construction begins. Finishing Material: NOTE Any remote wiring (i.e. remote control, wall switch or 120 volt wiring) must be done prior to final finishing to avoid costly reconstruction. Only noncombustible materials (i.e.
  • Page 11: Vent Installation

    VENT INSTALLATION: WARNING The following venting instructions are provided as a general guideline. Always check with pipe manufacturer for venting requirements. Positioning The Fireplace: NOTE The fireplace must be installed giving full consideration to the clearance and height requirements identified in this manual.
  • Page 12: Installing Vent Components

    WARNING Never use more than two (2) 45 degree elbows. When using adjustable elbows, never exceed 45 degrees. Vertical Venting with Two (2) 45 Degree Elbow: NOTE V1 and V2 must satisfy this condition: V1 + V2 < 40 feet Max. V1 + V2 >...
  • Page 13 Figure 8: Installing Pipe Supports WARNING Always maintain minimum clearances around vent systems. The minimum clearances to combustibles is 1” around vent pipe. For ceiling firestops and vertical sections of vent pipe a 1-inch minimum clearance all around the pipe must be maintained. Do not pack the open air spaces with insulation or other materials. This could cause high temperatures and may present a fire hazard.
  • Page 14: Vent Termination

    Figure 9: Ceiling Firestop Location Vent Termination: For Vertical Termination Figure 10: Minimum Vent Height for Various Roof Pitches WARNING Major building codes specify a minimum vent height above the rooftop depending on the pitch of the roof. Refer to the above figure for minimum heights, provided the termination cap is at least eight (8) feet from a vertical wall, and two (2) feet below a horizontal overhang.
  • Page 15: Outside Air Kit Installation

    NOTE When working on the roof, cover the opening of the installed vent pipes below to prevent debris falling in. To Locate and install Vertical Termination • Locate and mark the vent center point on the underside of the roof, and drive a nail through the center point. •...
  • Page 16: Gas Line And Electrical

    GAS LINE AND ELECTRICAL Gas Line Installation: NOTE Plumbing connections should only be performed by a qualified, licensed plumber. Main gas supply must be off when plumbing gas line to fireplace or performing service. • Consult all codes. All gas piping must be installed to comply with local codes, or in the absence of local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1.
  • Page 17: Electrical Wiring

    Figure 12: Gas Pressure Check at Gas Valve Electrical Wiring: Standing Pilot Ignition Wiring-Millivolt Control: WARNING Do not connect 110-120 VAC to the Remote Wall Switch, DC Remote Control or the Millivolt Control Valve. The appliance will malfunction or the valve will be damaged. CAUTION Electrical connections should only be performed by a qualified, licensed electrician.
  • Page 18 Figure 13: Wiring Diagram for Standing Pilot - Millivolt System Optional DC Remote Systems These instructions supersede the section entitled “Hearth Mount” in the Millivolt hand held remote instructions supplied with the remote. NOTE Remote receiver must be mounted outside the appliance, due to high temperatures inside the chamber. This will prevent failures and longer battery life.
  • Page 19 • Turn RS-ON-OFF switch to the “ON” position. If meter is reading more than 175 millivolt and the main burner does not come on, then replace control valve. If meter is reading less than 175 millivolt, then refer to TROUBLESHOOTING section of this manual to determine the cause of the low reading.
  • Page 20 NOTE Remote receiver must be mounted outside the appliance, due to high temperatures inside the chamber. This will prevent failures and longer battery life. 1. Plug in the remote connector wire to the remote receiver. 2. Connect the wire terminal from the remote receiver to replace the 15’ wall switch connection to the switch as shown in the Figure 14.
  • Page 21: Final Installation

    FINAL INSTALLATION Wall Finishing: Definitions: Combustible Materials - Materials made of or surfaced with wood, compressed paper, plant fibers, or other materials that are capable of being ignited and burned. Such materials are considered combustible even though flameproof, fire retardant, treated, or plastered. Non-Combustible Materials - Materials which will not ignite and burn.
  • Page 22: Log Placement

    Log Placement for fiber VDY24/18D3R: Step 1: Line up pins on bottom of Rear Log #1 with pins on grate bar and place on grate. Step 2: Place Front Left Log #2 on left front of grate bar lining up cutout in bottom of log with grate bar. Step 3: Place Front Right Log #3 on right front of grate bar lining up cutout in bottom of log with grate bar.
  • Page 23: Glass Bi-Fold Door Installation

    Glass Bi-Fold Door Installation: WARNING Glass doors must be installed on all Propane/LPG units and operated in the closed position to eliminate any potential for soot spillage into the room. When installing a natural gas unit with glass door option, the unit must be operated with glass doors completely opened or completely closed.
  • Page 24 Damper operation: NOTE For Massachusetts residents only: Installation of this vented gas fireplace in the Commonwealth of Massachusetts requires the damper to be permanently removed or welded into the fully open position. In addition, a naturally vented gas fireplace may not be installed in a bedroom or bathroom in the Commonwealth of Massachusetts.
  • Page 25: Operating Instructions

    Before Lighting the Fireplace: • Read the IMPORTANT SAFETY INFORMATION section at the beginning of this homeowner manual. • Before lighting, check the fireplace for possible gas leaks. • Before lighting, check for possible obstructions that could be blocking the vent termination or the front louver. •...
  • Page 26: Before Lighting The Fireplace

    LIGHTING INSTRUCTIONS MILLIVOLT CONTROL STOP! Read the safety information below With the control knob pushed in, push in and on this label. release the piezo ignitor button to light the pilot. Open access door on left side of floor to Continue pushing the control knob in for a further reveal gas valve, then locate RS-OFF-ON 60 seconds to prevent the flame detector from...
  • Page 27 LIGHTING INSTRUCTIONS ELECTRONIC IGN STOP! Read the safety information Wait five (5) minutes to clear out any gas. Than below on this label. smell for gas, including near the floor. If you smell Set the switch to “OFF” gas, STOP! Follow “B” in the safety information Turn off all electric power to the below on this label.
  • Page 28: Maintenance

    MAINTENANCE WARNING Turn off gas before servicing fireplace. It is recommended that a qualified service technician perform these check-ups at the beginning of each heating season. The appliance area must be kept clear and free from combustible materials, gasoline and other flammable vapors and liquids.
  • Page 29: Vent System

    Vent System: The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow.
  • Page 30: Parts List / Illustration

    PARTS LIST / ILLUSTRATION VDY24/18D3R Item Description 4536 5142 Rear Log 32D2118 32D2118 Front Left Log 32D2117 32D2117 Front Right Log 32D2116 32D2116 Top Middle Log 32D2114 32D2114 Top Right Log 32D2113 32D2113 Top Left Log 32D2115 32D2115 Firebox Components: Standard and Accessories Item Description 4536...
  • Page 31 Engine Components: Standing Pilot – Millivolt Control Item Description 4536NV 4536PV 5142NV 5142PV Gas Valve Assembly 26D0506 26D0507 26D0506 26D0507 Pilot Assembly 41D0327 41D0328 41D0327 41D0328 Burner Tube 41D0031K 41D0031K 41D0031K 41D0031K Flexhose with Shutoff Valve 23D6046 23D6046 23D6046 23D6046 Rocker Switch 41D0048 41D0048...
  • Page 32 Electronic Ignition Control Item Description 4536NE 4536PE 5142NE 5142PE Gas Valve Assembly 37D0016 37D0017 37D0016 37D0017 Pilot Assembly 54D2004 54D2005 54D2004 54D2005 Burner Tube 41D0031K 41D0031K 41D0031K 41D0031K Flexhose with Shutoff Valve 23D6046 23D6046 23D6046 23D6046 Rocker Switch 41D0048 41D0048 41D0048 41D0048 Injector...
  • Page 33: Troubleshooting

    TROUBLESHOOTING STANDING PILOT - MILLIVOLT SYMPTOM POSSIBLE CAUSE REMEDY Spark ignitor will A. Wire disconnected. Open door and check to make sure wire is connected to not light pilot after ignitor. repeated triggering of piezo. B. Defective ignitor. Check for spark at electrode and pilot. If no spark and electrode wire is properly connected, replace pilot assembly.
  • Page 34 ELECTRONIC IGNITION...
  • Page 35 GENERAL TROUBLESHOOTING: 1. Glass Soots A. Flame impingement Install log set per the instructions on logs Inspect the injector and air intake area. Make sure this area does not have any blockage from debris and clean. Check gas supply 2. Poor draft due to A.
  • Page 36: Massachusetts Residents Only

    MASSACHUSETTS RESIDENTS ONLY: PLEASE READ AND FOLLOW THESE SPECIAL REQUIREMENTS NOTE REGARDING VENTED PRODUCTS This product must be installed by a licensed plumber or gas fi tter when installed within the Commonwealth of Massachusetts. Any residence with a direct vent product must have a CO detector installed in the residence. Installation of the fi...
  • Page 37 SPECIAL REQUIREMENTS CONTINUED 2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accor- dance with the above provisions shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certi- fi ed. 3. SIGNAGE. A metal or plastic identifi cation plate shall be permanently mounted to the exterior of the build- ing at a minimum height of eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment.
  • Page 38: Lifetime Warranty

    Logs. Basic Warranty Monessen Hearth Systems (MHS) warrants the components and materials in your gas appliance to be free from manufacturing and material defects for a period of two years from date of installation. After installation, if any of the components manufactured by MHS in the appliance are found to be defective in materials or workmanship, MHS will, at its option, replace or repair the defective components at no charge to the original owner.
