Emerson EM510 Owner's Manual

WIRE LESS HEA DS ET
Owner's Manual
Model: EM510
In the box In the box
W IRE LES S HE ADSE T
Owner's Manual
Model: EM510
Bluetooth User Guide USB Charging
Headphones Cable
S M L
Silicone cushions AC Charger

Locations of controls

Locations of controls

Backward

Play/Stop

Forward

Volume Down
Power ON/OFF
Indicator light
Volume Up

Charging the Bluetooth Headphones

Charging the Bluetooth Headphones
1. Connect the charging pin of the USB cable to the charging
socket of the headphones.
2. Connect the other end of the USB cable to either the:
• AC Charger, and plug into a wall (A/C) outlet.
• Computer's USB port.
3. The RED LED indicator light turns on.
4. The RED LED indicator light shuts o when the headphones
are fully charged (approximately 3 hours).
NOTE: The Bluetooth Headphones will emit an intermittent
beep tone and the RED LED will ash when the battery
is running low and requires recharging.
AC Charger
Charging
Socket
Indicator
light
USB port
USB Cable
NOTE: Make sure you charge your headphones for 8 hours
before using it for the rst time.

Pairing the headphones with a Bluetooth enabled device

Pairing the headphones with a Bluetooth enabled device
1. Make sure the Bluetooth Headphones are turned o .
2. Keep your Bluetooth Headphones and mobile phone within
3 feet of each other during the pairing process.
3. Press down and HOLD the [ ] button until the RED and
BLUE lights ash alternately.
4. The headphones are now in Pairing Mode and ready to
connect to your mobile phone.
Power button
(Press down & HOLD)
within 3 feet
Indicator
light
NOTE: To enter the Pairing Mode, you must press down and
HOLD the [ ] button for approximately 10 seconds.
5. Set your mobile phone or other Bluetooth enabled device
to search for Bluetooth devices.
Bluetooth: Enabled
Paired Devices:
*Empty *
Searching for devices
1 found
Stop
6. When the phone nds the headphones, con rm by selecting
EM510 from the list.
Bluetooth: Enabled
Paired Devices:
EM510
Select Device:
EM510
Cancel
7. Enter passcode "0000" when prompted by the phone.
Bluetooth: Enabled
Paired Devices:
EM510
Enter numeric passkey
for EM510:
0000
OK
OR depending on which model mobile phone you are trying
to connect the headphones to, it may not be necessary to enter
a passcode and the following message (or similar) may appear
PC
on your phone's display.
Bluetooth: Enabled
Paired Devices:
EM510
"EM510" would like to pair
with your phone. Would you
like to allow it to pair?
Cancel
Select "Pair" to connect the headphones to your phone.
8. Your mobile phone will con rm that the pairing was completed,
and prompt you to accept the connection. Please respond
YES to connect the headphones to your mobile phone. If the
pairing was successful, the headphones' s indicator light ashes a
steady blue.
Bluetooth: Enabled
Paired Devices:
EM510
Confirm connection to
EM510?
/
YES NO
9. When attempting to reconnect the headphones to your mobile
phone, you may see the message below, and your mobile
phone will prompt you to accept the connection request to
the EM510 headphones, and an option not to ask this again.
Please accept the connection, and if you select "Don't ask this
again", your phone will automatically accept future connection
requests from your Bluetooth Headphones.
Bluetooth: Enabled
Paired Devices:
EM510
Accept connection request
from EM510?
/
YES NO
Don't ask this again
NOTE: The screenshots above are typical of many Bluetooth
enabled phones in the market today, and are used to assist
in the explanation of the pairing process. Your mobile phone' s
interface and interaction with the Bluetooth Headphones
may slightly di er from the illustrations above.
Pairing with the SONY PlayStation®3 (PS3™)
Pairing the Bluetooth Headphones with a Sony PlayStation 3
SET ACCESSORY to BLUETOOTH on PS3
1. Go to the PS3 main menu, scroll to and select "Settings".
2. Scroll to and select "Accessory Settings".
3. Scroll to and select "Manage Bluetooth Devices".
4. The menu will ask: "The Bluetooth device has not been
registered. Do you want to register it?", then select "YES".
REGISTER EM510 to PS3
Put your Bluetooth Headphones into pairing mode.
(See "Pairing the Headphones with a Bluetooth enabled device")
1. Select "Start Scanning" from the PS3 menu.
2. Once the PS3 has discovered the Headphones, the screen will read
"Select the Bluetooth device to register", then select "EM510"
3. The PS3 will ask for a passkey. Enter [0000] then select "OK". Now
press [O] (the PS3 circle button) to get back to the previous menu.
4. Scroll to and select "Audio Device Settings" to change the
"Input Device" to "EM510".
NOTE: "Input Device" is the microphone, and determines the
method of how how others will hear you speak. By default,
the "Output Device" will now switch to "EM510".
"Output Device" is the audio, and determines how you
will hear the PS3 audio and others speaking.
To test the connection, speak into the Headphones and you
will see the bars above the "Microphone Level" moving, if not,
repeat the pairing process.
Press "OK" to con rm the new settings. You are now ready to use
the Bluetooth Headphones with your PS3 Entertainment System.
If you would like to hear the PS3 audio through your TV or Audio
System, scroll to "Output Device" and switch to "System Default Device" .
Pair
For further assistance with Bluetooth settings on your PS3
please refer to your PS3 instruction manual.

Using your Bluetooth Headphones

Using your Bluetooth Headphones

Powering ON/OFF

• To turn ON, press down on and HOLD the [
the BLUE LED indicator light turns on.
• To turn OFF, press down on and HOLD the [
the RED LED indicator light blinks and shuts o .

Answering/Ending a call

• To answer a call, press down on the [
• To end a call, press down on the [

To make a call

Dial the number and press the send button on your mobile
phone, the call is automatically transferred to the headphones.

Adjusting the volume

Push the [ ] button toward [
volume to the desired level.
NOTE: You may also adjust the volume from your mobile phone' s
volume control.

Rejecting an incoming call

To reject an incoming call, press down on and HOLD the [
button until you hear the con rmation tone.
Redialing the last number called (Dependent
on your phone supporting this feature)
Double press the [ ] button. The last number called will be
redialed.
Voice dial (Dependent on your phone supporting
this feature)
Push the [ ] button towards [
con rmation tone, and then say a name from your phone's
contact list.
Transferring calls
To transfer calls between your Bluetooth Headphones and phone
during a conversation, press and HOLD the [
you hear the con rmation tone. To transfer the call back to the
Bluetooth Headphones press and HOLD the [
once again until you hear the con rmation tone.
] button until
] button until
] button once.
] button once.
] or [ ] to adjust the
]
] until you hear the
] button until
] button
