Emerson EM266 Owner's Manual

Emerson headphones user manual

Advertisement

Quick Links

Owner's Manual
stereo

Wireless Headset

Model: EM266
In the box
Owner's Manual
Wireless Headset
Model: EM266
Owner's
Earhook
Manual
Bluetooth
Headset
S M L
Silicone
Cushions
USB Charging
Cable
Stereo
AC Charger
Earphone
About noise cancellation technology
This headset uses a dual microphone design to lter out wind and
unwanted external noise.
Using Noise Cancellation Technology, the headset compares the
sound from the twin built-in microphones, and is able to recognize
the di erence between voice and unwanted background noise.
Noise Cancellation Technology
Enables the other end of your
conversation to hear you clearly!
Microphone 2
Microphone 1
Drive Safe
CAUTION: Although this device enables drivers to
conduct handsfree conversations, it is still safer to pull
over before using a mobile phone.
• Do not use the stereo earphone while driving.
• Always keep your full attention on your driving.
Driving while talking on your mobile phone is dangerous, and
illegal in many states.
Check local laws regarding the use of a mobile handset and wireless
headset while driving. If you use the Bluetooth Headset while
driving, ensure your attention and focus remains on your driving.
Please use your mobile phone, and our product
responsibly while driving!
Location of controls
Power button
Power ON/OFF
Silicone
Answer/end a call
cushion
VOLUME UP
Indicator light
VOLUME DOWN
Charging
socket
Microphone 2
Microphone 1
Charging the Bluetooth Headset
1. Connect the USB cable to the charging socket of the headset.
2. Connect the other end of the USB cable to either the:
• AC Charger, and plug into a wall (A/C) outlet
• Computer's USB port
3. The BLUE LED indicator light turns on.
4. The BLUE LED indicator light shuts o when the headset
is fully charged (approximately 2-3 hours).
NOTE: When the battery is running low, the BLUE LED indicator
light starts to ash.
USB cable
Indicator
light
AC Charger
Charging
Socket
Headset
PC
NOTE: Charge your headset for at least 8 hours before using
it for the rst time.
Pairing the headset with a Bluetooth enabled device
1. Make sure the Bluetooth Headset is turned o .
2. Keep your Bluetooth Headset and mobile phone within 3
feet of each other during the pairing process.
3. Press and HOLD the [POWER] button until the BLUE indicator
light turns on, ashes several times, and becomes a steady
blue. The headset is now in Pairing Mode, and is ready to
connect to your mobile phone.
4. The headset is now in Pairing Mode and is ready to connect
to your mobile phone.
Power button
(Press & HOLD)
Indicator light
within 3 feet
NOTE: To enter the Pairing Mode, you must press and HOLD the
[POWER] button for approximately 10 seconds.
5. Set your mobile phone to search for Bluetooth devices.
Bluetooth: Enabled
Paired Devices:
*Empty *
Searching for devices
1
found
Stop
6. When the phone nds the headset, con rm by selecting EM266
from the list.
Bluetooth: Enabled
Paired Devices:
EM266
Select Device:
EM266
Cancel
7. Enter passcode "0000" when prompted by the phone.
Bluetooth: Enabled
Paired Devices:
EM266
Enter numeric passkey
for EM266:
0000
OK
OR depending on which model mobile phone you are trying
to connect the headset to, it may not be necessary to enter a
passcode and the following message (or similar) may appear on
your phone's display.
Bluetooth: Enabled
Paired Devices:
EM266
"EM266" would like to pair
with your phone. Would you
like to allow it to pair?
Cancel
Pair
Select "Pair" to complete the pairing process.
8. Your mobile phone will con rm that the pairing was completed,
and prompt you to accept the connection. Please select
"YES" to connect the headset to your mobile phone. If the pairing
was successful, the headset' s indicator light ashes a steady blue.
Bluetooth: Enabled
Paired Devices:
EM266
Confirm connection to
EM266?
/
YES
NO
9. When attempting to reconnect the headset to your mobile
phone, you may see the message below, and your mobile
phone will prompt you to accept the connection request to
the EM266 headset, and an option not to ask this again.
Please accept the connection, and if you select "Don't ask this
again", your phone will automatically accept future connection
requests from your Bluetooth Headset.
Bluetooth: Enabled
Paired Devices:
EM266
Accept connection request
from EM266?
/
YES
NO
Don't ask this again
NOTE: The screenshots above are typical of many Bluetooth enabled
phones in the market today, and are used to assist in the
explanation of the pairing process. Your mobile phone's
interface and interaction with the Bluetooth Headset may
slightly di er from the illustrations above.
Pairing with the SONY PlayStation®3 (PS3™)
Pairing the Bluetooth Headset with a Sony PlayStation 3
<SET ACCESSORY to BLUETOOTH on PS3>
1. Go to the PS3 main menu, scroll to and select "Settings".
2. Scroll to and select "Accessory Settings".
3. Scroll to and select "Manage Bluetooth Devices".
4. The menu will ask: "The Bluetooth device has not been
registered. Do you want to register it?", then select "YES".
<REGISTER EM266 to PS3>
Put your Bluetooth Headset into pairing mode.
(See "Pairing the headset with a Bluetooth enabled device")
1. Select "Start Scanning" from the PS3 menu.
2. Once the PS3 has discovered the Headset, the screen will read
"Select the Bluetooth device to register", then select "EM266"
3. The PS3 will ask for a passkey. Enter [0000] then select "OK". Now
press [O] (the PS3 circle button) to get back to the previous menu.
4. Scroll to and select "Audio Device Settings" to change the
"Input Device" to "EM266".
NOTE: "Input Device" is the microphone, and determines the
method of how others will hear you speak. By
default, the "Output Device" will now switch to "EM266".
"Output Device" is the audio, and determines how you will
hear the PS3 audio and others speaking.
To test the connection, speak into the headset and you will see
the bars above the "Microphone Level" moving, if not, repeat the
pairing process.
Press "OK" to con rm the new settings. You are now ready to use
the Bluetooth Headset with your PS3 Entertainment System. If you
would like to hear the PS3 audio through your TV or Audio System,
scroll to "Output Device" and switch to "System Default Device".
For further assistance with Bluetooth settings on your PS3 please
refer to your PS3 instruction manual.
