4.7 PNP/PCI CONFIGURATION SETUP
Phoenix – AwardBIOS CMOS Setup Utility
PNP OS Installed
Reset Configuration Data
Resources Controlled By
*IRQ Resource
PCI/VGA Palette Snoop
Assign IRQ For VGA
Assign IRQ For USB
INT Pin 1 Assignment
INT Pin 2 Assignment
INT Pin 3 Assignment
INT Pin 4 Assignment
??? ? :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
PNP OS Installed: Select Yes if you are using a Plug and Play capable operation system;
Select No if you need the BIOS to configure non-boot devices. No, Yes
Reset Configuration Data: Default is Disabled. Select Enabled to reset ESCD when you exit
Setup if you have installed a new add-on and the system reconfiguration has caused such a
serious conflict that the OS cannot boot. Enabled/ Disabled
Resources Controlled By BIOS can automatically configure all the boot and PnP compatible
devices. If you choose Auto, you cannot select IRQ DMA and memory base address fields,
because BIOS automatically assigns them. Auto(ESCD), Manual.
PCI/VGA Palette Snoop Disabled is default setting. Enabled Non-standard VGA cards such
as graphics accelerators or MPEG video cars may not show colors properly. Enabling this item
can solve this problem.
Assign IRQ For VGA/USB: Enabled, Disabled
INT Pin 1/2/3/4 Assignment: Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15

PnP/PCI Configuration

[No]
[Disabled]
[Auto (ESCD)]
Press Enter
[Disabled]
[Enabled]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
F6: Fail - Save Defaults
Award BIOS Description
Item Help
Menu Level ?
F7: Optimized Defaults
19
