4.5 INTEGRATED PERIPHERALS
Phoenix – AwardBIOS CMOS Setup Utility
? VIA OnChip IDE Device
? VIA OnChip PCI Device
? SuperIO Device
Init Display First
USB Keyboard Support
IDE HDD Block Mode
??? ? :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
VIA OnChip IDE Device: Press <Enter> to enter submenu.
OnChip IDE Channel0/1: Enabled, Disabled
IDE Prefetch Mode: Enabled, Disabled
Primary/Secondary Master/Slave PIO: Auto, Mode 0~4
Primary/Secondary Master/Slave UDMA: Auto, Disabled
VIA OnChip PCI Device: Press <Enter> to enter submenu.
VIA -3058 AC97 Audio: Auto, Disabled
VIA –3068 MC97 Modem: Auto, Disabled
Supper IO Device: Press <Enter> to enter submenu.
Onboard FDC Controller: Enabled, Disabled
Onboard Serial Port 1/2: Defines the onboard serial port address and IRQ number. 3F8/IRQ4,
2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Auto, Disabled.
UART Mode Select: Normal, IrDA, ASKIR
RxD, TxD Active: Hi,Lo; Lo,Hi; Lo,Lo; Hi,Hi
IR Transmission Delay: Enabled, Disabled
UR2 Duplex Mode: Half, Full
Use IR Pins: IR-Rx2Tx2; RxD2,TxD2
Onboard Parallel Port: Defines onboard parallel port address and IRQ number. 378/IRQ7,
278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode: SPP, EPP, ECP, ECP+EPP, Normal
EPP Mode Select: EPP1.7, EPP1.9
ECP Mode Use DMA: 3,1
Game Port Address: 201, 209, Disabled
Midi Port Address: Disabled, 330, 300, 290
Midi Port IRQ: 5, 10
Integrated Peripherals
[Press Enter]
[Press Enter]
[Press Enter]
[PCI Slot]
[Disabled]
[Enabled]
F6: Fail - Save Defaults
Award BIOS Description
Item Help
Menu Level ?
F7: Optimized Defaults
