Summary of Contents for Chyang Fun CFI-S86
- Page 1 CFI-S86 High Performance Socket478B Motherboard User’s Guide...
- Page 2 Edition 1.01 © 2002 CHYANG FUN INDUSTRY CO., LTD. P/N: 155100-8970 WARNING To make the system work normally, please ensure JBAT1 of the mainboard is set as below. Refer to Fig. 2.1 in this manual for the location JBAT1. JBAT1 If JBAT1 is shorted to 2-3, no CMOS data can be retained.
- Page 3 PC, AT, PC-DOS, OS/2 and Presentation Manager are trademarks of IBM Corporation. UNIX is the trademark of AT&T. All other brand and product names are trademarks or registered trademarks of their respective companies. The information presented in this publication has been carefully checked for reliability; however, no responsibility is assumed for inaccuracies, whereas, specification is subjected to change without notice.
-
Page 4: Table Of Contents
CONTENTS CHAPTER 1 INTRODUCTION1 CHAPTER 2 JUMPER SETTINGS Jumper Presentation Graphical Description of Jumper Settings Clear CMOS Data CPU Frequency Setting Factory Setting CHAPTER 3 CONNECTOR CONFIGURATION U1 - Socket478 FAN Connectors J12 - Multiple Function Jumper JCDIN1 - CD-IN Connector CN4 - ATX 12V Connector ATX Power Supply Connector Rear Panel Connectors... -
Page 5: Introduction1
CHAPTER 1 INTRODUCTION Preface CFI-S86 is a 6-layers, Flex-ATX form factor, high-performance Socket478 motherboard. The system core logic is based on VIA P4M266 Chipsets. It is integrated with NEC uPD720100AGM USB 2.0 controller and Realtek RTL8100B Ethernet controller. Features CPU:... - Page 6 Chapter 1 Ethernet: Realtek RTL8100B 10/100Base-T Ethernet controller Full-Duplex supported WFM 2.0 compliant I/O Interface: Winbond W83627HF LPC controller Two enhanced PCI IDE channels which support up to 4 IDE devices with ATA-133 transfers up to 133MB/sec Build in FDC supports 1.2M/1.44M/2.88M FDD Back Panel I/O Output: PS/2 mouse and keyboard connectors 2 Type A USB connectors, 1 RJ-45 LAN port...
- Page 7 Connector Configuration ATX POWER KBMS1 FDD1 KBMS1 MPGA478B W83627HF USB1 V-Video VT1621 S-Video USB 2.0 USB/LAN RTL8100B VIA8233 SPK LINE MIC P4M266 AC97 CODEC 39SF020A BATTERY 40-pin Conn Fig. 1.1 Key Components of the Motherboard...
-
Page 9: Jumper Settings
CHAPTER 2 JUMPER SETTINGS JUMPER PRESENTATION Pins 1 and 2 are shorted with a jumper cap. Pins 2 and 3 are shorted with a jumper cap. The jumper is shorted when the jumper cap is placed over the pins of the jumper. The jumper is opened when the cap is removed from jumper. -
Page 10: Clear Cmos Data
Chapter 2 CLEAR CMOS DATA JBAT1 is used to clear the CMOS Data in the RTC (build in ICH chip). JBAT1 Description Normal Clear CMOS CPU FREQUENCY SETTING Description 133MHz 100MHz Note: P4M266 only support 100MHz * 4 Front Side Bus, SW2 must set at [3,6]. FACTORY SETTING Description SB Default... -
Page 11: Connector Configuration
CHAPTER 3 CONNECTOR CONFIGURATION Once the mainboard has been fastened into system case, the next step is to connect the internal cables. The internal cables are wire leads with plastic female connectors that attach to the connectors. The mainboard connectors have the various numbers of pins and are the contact points between the mainboard and other parts of the computer. -
Page 12: Cn4 - Atx 12V Connector
Chapter 3 CN4 – ATX 12V Connector ATX POWER SUPPLY CONNECTOR Rear Panel Connector CN1 and CN2 is the V-port and S-port of Video connector. MIC IN MOUSE LINE IN SPK OUT KEYBOARD V-Port S-Port Front Panel Connector VOL is the volume knob. IrDA is an infrared transceiver module. -
Page 13: Award Bios Description
CHAPTER 4 AWARD BIOS DESCRIPTION ENTERING SETUP Power on the computer, when the following message briefly appears at the bottom of the screen during the POST (Power On Self Test), press <Del> key or simultaneously press the <Ctrl> + <Alt> + <Esc> keys, to enter the AWARD BIOS CMOS Setup Utility. Press <Del>... -
Page 14: Standard Cmos Features Setup
Chapter 4 STANDARD CMOS FEATURES SETUP Use the arrow keys to highlight the item, and then use the <PgUp> or <PgDn> to select the value desired in each item. Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy) Tue. -
Page 15: Advanced Bios Features Setup
Award BIOS Description CGA 40: Color Graphic Adapter, powering up in 40-column mode. CGA 80: Color Graphic Adapter, powering up in 80-column mode. MONO: Monochrome adapter, including high-resolution monochrome adapters. Halt On [All, But Keyboard] This field determines whether the system will stop if an error is detected during powering up. All errors: Stop and prompt whenever the BIOS detect a non-fatal error. -
Page 16: Advanced Chipset Features Setup
Chapter 4 Virus warning: Allows you to choose the VIRUS warning feature for IDE hard disk boot sector protection. If it is enabled and someone attempt to write data into the sector, BIOS will show a warning message on screen and alarm beep. Enabled, Disabled CPU L1 &... - Page 17 Award BIOS Description ? DRAM Clock/Drive Control [Press Enter] Item Help ? AGP & P2P Bridge Control [Press Enter] ? CPU & PCI Bus Control [Press Enter] Menu Level Memory Hole [Disabled] System BIOS Cacheable [Disabled] Video RAM Cacheable [Disabled] Delay Prior to Thermal [16 Min] VGA Share Memory Size...
- Page 18 Chapter 4 System BIOS Cacheable: Besides conventional memory, the system BIOS area is also cacheable. Enabled, Disabled: Video RAM Cacheable: Besides conventional memory, video RAM area is also cacheable. Enabled, Disabled Delay Prior to Thermal: 16 Min, 32 Min, 4 Min, 8 Min VGA Share Memory Size: 32M, Disabled, 8M, 16M FB Address Conversion: Enabled, Disabled FB Page Close Prediction: Enabled, Disabled...
-
Page 19: Integrated Peripherals Setup
Award BIOS Description INTEGRATED PERIPHERALS Phoenix – AwardBIOS CMOS Setup Utility Integrated Peripherals ? VIA OnChip IDE Device [Press Enter] Item Help ? VIA OnChip PCI Device [Press Enter] ? SuperIO Device [Press Enter] Menu Level Init Display First [PCI Slot] USB Keyboard Support [Disabled] IDE HDD Block Mode... -
Page 20: Power Management Setup
Chapter 4 Init Display First PCI Slot, AGP. USB Keyboard Support: Support USB Keyboard under DOS status. Disabled, Enabled IDE HDD Block Mode: . If your IDE hard drive supports block mode, select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support. - Page 21 Award BIOS Description Video Off Option Suspend -> Off, MODEM Use IRQ, Always On Video Off Method V/H SYNC+Blank: In addition to Blank Screen, BIOS will also turn off the V-SYNC & H – SYNC signals from VGA card to monitor. DPMS Support: This function is enabled only for VGA cards supporting DPMS.
- Page 22 Chapter 4...
-
Page 23: Pnp/Pci Configuration
Award BIOS Description PNP/PCI CONFIGURATION SETUP Phoenix – AwardBIOS CMOS Setup Utility PnP/PCI Configuration PNP OS Installed [No] Item Help Reset Configuration Data [Disabled] Resources Controlled By [Auto (ESCD)] Menu Level *IRQ Resource Press Enter PCI/VGA Palette Snoop [Disabled] Assign IRQ For VGA [Enabled] Assign IRQ For USB [Enabled]... -
Page 24: Pc Health Status
Chapter 4 PC HEALTH STATUS Phoenix – AwardBIOS CMOS Setup Utility PC Health Status CPU Warning Temperature [Disabled] Item Help Current System Temp. Current CPU1 Temperature Menu Level Current CPUFAN1 Speed Current CPUFAN2 Speed Current CPUFAN3 Speed IN0 (V) IN1 (V) IN2 (V) +5 V +12 V... -
Page 25: Password Setting
Award BIOS Description Menu Level ??? ? :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5: Previous Values F6: Fail - Save Defaults F7: Optimized Defaults CPU CLOCK Ratio: Selects the multiplication of processor core frequency. If a Ratio locked processor installed, this item will be hidden. This item is only for users who understand all the CPU parameters, i.e. - Page 26 Chapter 4 will be prompted for the password only when you enter BIOS Setup. Supervisor Password has higher priority than User Password. You can use Supervisor Password when booting the system or entering BIOS Setup to modify all settings. Also you can use User Password when booting the system or entering BIOS Setup but can not modify any setting if Supervisor Password is enabled.
-
Page 27: Exit Setup
Award BIOS Description 4.11 EXIT SETUP Save & Exit Setup After finish modifying the values, choose this item to save the changes to the CMOS RAM. A confirmation message will appear, type “Y” and press Enter to save and exit Setup. Exit Without Saving If you do not want to save the changes, choose this item to exit Setup without saving changes. -
Page 29: Quick Guide
APPENDIX A QUICK GUIDE The table below summaries the functions and settings of each jumper of the motherboard. Function Jumper Settings Normal JBAT1 Clear CMOS Data Clear JBAT1 133 MHz SW1.2, SW2.3 Open CPU Frequency 100 MHz SW1.2, SW2.3 Short...
