Chapter 4
4.2

STANDARD CMOS FEATURES SETUP

Use the arrow keys to highlight the item, and then use the <PgUp> or <PgDn> to select the
value desired in each item.
Phoenix – AwardBIOS CMOS Setup Utility
Date (mm:dd:yy)
Time (hh:mm:ss)
? IDE Primary Master
? IDE Primary Slave
? IDE Secondary Master
? IDE Secondary Slave
Drive A
Drive B
Video
Hal On
Select Display Device
Select TV mode
Base Memory
Extended Memory
Total Memory
??? ? :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
Data: Set the day, month, year and century.
Time: Set the internal clock.
IDE Primary/Secondary Master/Slave: Press Enter to enter the detail settings of hard drive.
IDE HDD Auto-Detection: Press Enter to detect the HDD's status automaticly.
IDE Primary Slave: Auto, Manual, None
Access Mode: Auto, CHS, LBA, Large
Drive A/B: Set the floppy drive type. None; 350K, 5.25in; 1.2M,5.25in.; 720K, 3.5in.;1.44M,
3.5in.;2.88M, 3.5in
Video [EGA/VGA]
Select the type of video display card installed in your system.
EGA/ VGA: For EGA, VGA, SEGA, SVGA, or PGA monitors adapters.
10
Standard CMOS Features
Tue. Jan 01 2002
11:23:33
[1.44M, 3.5 in.]
[None]
[EGA/VGA]
[All, But Keyboard]
[CRT]
[NTSC]
640K
63488K
64512K
F6: Fail - Save Defaults
Item Help
Menu Level ?
Change the day,
month, year and
century
F7: Optimized Defaults
