STEP 6.
Swing out the four hangers at the corners
of the spring frame (C). Be careful to avoid
scratching the crib finish. Attach the spring
frame FLAT SIDE UP. Choose the proper level
for the mattress, starting at the highest level
and adjust it down as the child grows. Secure
the spring frame to the posts using the Allen
head bolts (V) and tighten them with the Allen
wrench (ZZ).
Make sure the Spring frame is
installed FLAT SIDE UP.
STEP 7.
Attach side panel (B) to the left and right end panels
using 2 1/4" Allen head bolts (W).
Do not overtighten the bolts.
STEP 8.
Screw cam lock bolts (Y) into the drawer front (L)
and cam locks (Z) into the holes in the left (K) and
right (J) drawer sides and drawer center (I). Slide
the drawers sides and center onto the drawer front
and tighten the cam locks. Slide the drawer bottoms
(N) into the grooves in the sides, center and front.
Y
Z
W
L
K
W
J
N
I
