Hardware; Phillips Screwdriver - Babyletto Mercer Crib Assembly And Operation Manual

S. 5/8" Pan head
wood screw (12)
W. 2 1/4 " Allen
head bolt (16)
Y. Cam bolt (3)
STEP 1.
Attach 4 post brackets (E) to each pair of
left and right posts (G+H) using 3 Phillips
head screws (S).
STEP 2.
Insert wood dowls (X) to the bottom side of each end
panel (A) as shown in the illustration below.
Use 2-1/4" Allen head bolts (W) to attach posts (G+H)
to each end panel (A).
STEP 2A
A

HARDWARE

T. 1 1/4" Phillips
head screw (12)
X. Wood dowl (4)
Z. Cam lock (3)
X
U. 3/8" Phillips
V. 3/4" Allen
head screw (10)
head bolt (4)
ZZ. Allen wrench
XX. 1 3/4" Allen
head bolt (4)
E
STEP 2B
G
Tools Needed
(not included)
S
G & H
W
Phillips
screwdriver
H
page 3
