- Page 1 SERVICE PARTS MANUAL ICE R SERIES CUBERS MODEL-ICE1606 Ice-O-Matic 11100 East 45th Ave Denver, Colorado 80239 Part Number 9081296-01 Date 1/09...
-
Page 2: Table Of Contents
ICE1606 Service Parts This parts list contains the service parts available for the ICE1606 icemakers. Check the model number on the data plate and refer to the correct listing for the specific component. Check carefully that the correct part is identified and ordered. -
Page 3: Cabinet Exterior
ICE1606 Series Service Parts Item Part Number Description Front Panel S.S. Front Panel Plastic 3021828-01 Top Cover Exterior Panels Item Part Number 2101314-01 R.H Side Panel 2101314-02 L.H Side Panel Page 2 Description Back Panel... -
Page 4: Cabinet Breakdown
ICE1606 Series Service Parts Item Page Number Description Page No. 4 Cabinet Base Page No. 5 Evaporator Assembly Page No. 6 Control Box and Bin Switch Assembly Page No. 7 Pump Assembly Page No. 8 Harvest Assist Cabinet Breakdown Page 3... -
Page 5: Refrigeration
ICE1606 Series Service Parts Item Part Number Description Front Frame panel 9031161-01 Plastic Wing Nut 3012958-01 Water Pan Cover 3012942-01 Water Pan Cover 9021010-04 Hose Clamp 9051476-01 Water Pan 3012924-01 Ice Deflector Rear Frame RH Rear Brace Rear Frame LH... -
Page 6: Evaporator And Components
ICE1606 Series Service Parts Item Part Number Description 2101355-04 Splash Curtain LH 2051147-82 Evaporator Left Side 2041338-02 Water Distribution Tube 2021567-02 9131381-02 9031122-01 Thumb Screw 9031004-19 Rubber Washer Item Page 5 Evaporator Part Number Description 9051001-09 Snap Bushing 2101355-03 Splash Curtain RH... -
Page 7: Control Box And Bin Switch Assembly
ICE1606 Series Service Parts Item Part Number Description 9041051-04 High Pressure Control 9041086-05 Purge Valve 9101218-10 Pump Cord 9181009-20 Run Capacitor 9181003-21 Start Capacitor 9101010-10 Potential Relay 9041094-01 Timer Initiate Control 9041040-01 Pump Down Control Item Part Number Description 9101124-02... -
Page 8: Water Pump/Float Assembly
ICE1606 Series Service Parts Item Part Number Description 3012957-01 Water Pump Bracket 9131111-01 Float Assembly 9161079-06 Water Pump 9091024-01 Barbed Tee 3032898-40 1/4 " ID Plastic Tubing- 3051210-40 1/4 " x 40" Long Insulation 9021010-04 Hose Clamp 9131026-02 Cap Plug... -
Page 9: Harvest Probe Assembly
ICE1606 Series Service Parts Item Part Number Description Probe Motor Bracket 9051001-13 Snap Bushing 9161031-01 Gear Motor 9131190-04 Clutch Assembly 9131189-01 Probe Shaft 9051057-01 Connecting Rod 9101160-01 Cam Switch Harvest Probe Assembly Item Part Number 9031120-01 3051145-01 9031005-03 9031119-01 9031008-16... -
Page 10: Remote Condenser
ICE1606 Series Service Parts Item Part Number Description 3012795-01 Mounting Leg 9131356-01 Fan Guard 9161110-02 Fan Motor 9161110-92 Capacitor 9131356-01 Fan Blade 9091001-12 Coupling-Bulkhead-1/2" Remote Condenser ERC2661 Lineset Couplings Item Part Number 9091001-11 3012806-01 9091001-10 9091001-08 9091001-04 9091001-02 Page 9 Description Coupling-Bulkhead-3/8"...
