  • Page 1 UPER ® SC119X Chassis Series SC119XTQ-BR700WB USER’S MANUAL...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
  • Page 3 Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SC119X 1U chassis. Instal- lation and maintenance should be performed by experienced technicians only. This manual lists compatible parts available when this document was published.

  • Page 4: Manual Organization

    These appendices list compatible cables, power supply specifications, and com- patible backplanes. Not all compatible backplanes are listed. Refer to our Web site for the latest compatible backplane information at http://www.supermicro.com. Appendix A Chassis Cables Appendix B Power Supply Specifications...

  • Page 5: Table Of Contents

    CPU ......................... 1-2 Hard Drives ..................... 1-2 I/O Expansion Slots ..................1-2 Other Features ....................1-2 Contacting Supermicro ..................1-3 Returning Merchandise for Service..............1-4 Chapter 2 Standardized Warning Statements for DC Systems About Standardized Warning Statements ............2-1 Warning Definition ................... 2-1 Installation Instructions ..................
  • Page 6 SC119X Chassis Manual Chapter 3 Chassis Components Overview ......................3-1 Components ....................3-1 Chassis ......................3-1 Backplane ......................3-1 Fans ........................ 3-1 Power Supply ....................3-2 Air Shroud (Optional) ..................3-2 Where to get Replacement Components ............3-2 Chapter 4 System Interface Overview ......................
  • Page 7 Preface General Server Precautions ................6-2 Rack Mounting Considerations ............... 6-3 Ambient Operating Temperature ..............6-3 Reduced Airflow ..................6-3 Mechanical Loading ................... 6-3 Circuit Overloading ..................6-3 Reliable Ground ..................6-3 Rack Mounting Instructions ................6-4 Identifying the Sections of the Rack Rails ............6-4 Inner Rail Extension (Optional) ...............
  • Page 8 SC119X Chassis Manual Notes viii...

  • Page 9: Chapter 1 Introduction

    Only enterprise level SAS or SATA hard drives are recommended for use in the SC119X chassis. Shipping List Visit the Supermicro web site for the latest shipping lists and part numbers for your particular chassis model at www.supermicro.com. SC119X Chassis...

  • Page 10: Chassis Features

    SC119X Chassis Manual Chassis Features The SC119X 1U high-performance chassis includes the following features: Hard Drives The SC119X chassis features eight hard drive bays for 2.5" hot-swappable SAS/ SATA drives. Once setup correctly, these drives can be removed without powering- down the server.

  • Page 11: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 12: Returning Merchandise For Service

    For faster service, RMA authorizations may be requested online (http://www. supermicro.com/support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.

  • Page 13: Chapter 2 Standardized Warning Statements For Dc Systems

    Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger.
  • Page 14 SC119X Chassis Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 15 Chapter 2: Warning Statements for DC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬...

  • Page 16: Installation Instructions

    SC119X Chassis Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 17: Circuit Breaker

    Chapter 2: Warning Statements for DC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が60V、...

  • Page 18: Power Disconnection Warning

    SC119X Chassis Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 60V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 60V, 20A.
  • Page 19 Chapter 2: Warning Statements for DC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 20: Equipment Installation

    SC119X Chassis Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 21: Restricted Area

    Chapter 2: Warning Statements for DC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 22: Battery Handling

    SC119X Chassis Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬ ‫محظورة‬...
  • Page 23 Chapter 2: Warning Statements for DC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 24: Redundant Power Supplies

    SC119X Chassis Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 25: Backplane Voltage

    Chapter 2: Warning Statements for DC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 26: Comply With Local And National Electrical Codes

    SC119X Chassis Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 27: Product Disposal

    Chapter 2: Warning Statements for DC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 28: Hot Swap Fan Warning

    SC119X Chassis Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 29 Chapter 2: Warning Statements for DC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 30: Dc Power Supply

    SC119X Chassis Manual DC Power Supply Warning! When stranded wiring is required, use approved wiring terminations, such as closedloop or spade-type with upturned lugs. These terminations should be the appropriate size for the wires and should clamp both the insulation and conductor. 警告...
  • Page 31 Chapter 2: Warning Statements for DC Systems Attention Quand des fils torsadés sont nécessaires, utiliser des douilles terminales homologuées telles que celles à circuit fermé ou du type à plage ouverte avec cosses rebroussées. Ces douilles terminales doivent être de la taille qui convient aux fils et doivent être refermées sur la gaine isolante et sur le conducteur.

  • Page 32: Dc Power Disconnection

    SC119X Chassis Manual DC Power Disconnection Warning! Before performing any of the following procedures, ensure that power is removed from the DC circuit. 警告 次の手順を開始する前に、 DC回路から電源が切断されているこ とを確認してく ださい。 警告 進行以下任一操作程序前，請確保直流電路已斷電。 警告 请在进行以下任一操作程序前，确保直流电路的电源已经断开。 Warnung Vor Ausführung der folgenden Vorgänge ist sicherzustellen, daß die Gleichstromschaltung keinen Strom erhält.

  • Page 33: Hazardous Voltage Or Energy Present On Dc Power Terminals

    Chapter 2: Warning Statements for DC Systems 주의! 다음 절차들을 수행하기 전에, 전원이 DC회로로부터 제거되었는지를 확인해 주십시오. Waarshuwing Wanneer geslagen bedrading vereist is, dient u bedrading te gebruiken die voorzien is van goedgekeurde aansluitingspunten, zoals het gesloten-lus type of het grijperschop type waarbij de aansluitpunten omhoog wijzen.
  • Page 34 SC119X Chassis Manual ¡Advertencia! Puede haber energía o voltaje peligrosos en los terminales eléctricos de CC. Reemplace siempre la cubierta cuando no estén utilizándose los terminales. Asegúrese de que no haya acceso a conductores descubiertos cuando la cubierta esté colocada. Attention Le voltage ou l'énergie électrique des terminaux à...

  • Page 35: Chapter 3 Chassis Components

    Components Chassis The chassis includes eight 2.5" hard drive bays. For the latest shipping lists, visit our web site at: http://www.supermicro.com. This chassis accepts a 1U backplane, six fans and two power supplies. SC119X models come in black. Backplane Each SC119X chassis comes with a 1U SAS/SATA backplane.

  • Page 36: Power Supply

    Supermicro Authorized Distributors/ System Integrators/Resellers. A list of Supermicro Authorized Distributors/System Integrators/Reseller can be found at: http://www.supermicro.com. Click the Where to Buy link.

  • Page 37: Chapter 4 System Interface

    Chapter 4 System Interface Chapter 4 System Interface Overview There are several LEDs on the control panel and on the drive carriers that provide system and component status. This chapter explains the meanings of all LED indi- cators and the appropriate responses that need to be taken. Figure 4-1: Control Panel Buttons and LEDs...

  • Page 38: Control Panel Buttons

    SC119X Chassis Manual Control Panel Buttons The SC119X chassis includes two or three push-buttons located on the front panel: a reset button, a power on/off button, and a UID button Power: The main power switch is used to apply or remove power from the power supply to the server system.

  • Page 39: Control Panel Leds

    Chapter 4 System Interface Control Panel LEDs The control panel located on the front of the SC119X chassis has five LEDs. These LEDs provide critical information related to different parts of the system. This sec- tion explains what each LED indicates when illuminated and any action that may be required.

  • Page 40: Drive Carrier Leds

    SC119X Chassis Manual NIC2: Indicates network activity on GLAN2 when flashing. NIC1: Indicates network activity on GLAN1 when flashing. HDD: Indicates IDE channel activity. SAS2/SATA drive and/or DVD-ROM drive activity when flashing. Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.

  • Page 41: Power Supply Leds

    Chapter 4 System Interface to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed. Red: The red LED to indicate an SAS/SATA drive failure. If one of the SAS/SATA drives fail, you should be notified by your system management software. Power Supply LEDs This chassis provides several options which may include hot-swappable, cold- swappable, and redundant power supplies.
  • Page 42 SC119X Chassis Manual Notes...

  • Page 43: Chapter 5 Chassis Setup And Maintenance

    Chapter 5 Chassis Setup and Maintenance Chapter 5 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform main- tenance on the chassis. The only tool needed to install components and perform maintenance is a Phillips screwdriver. Review the warnings and precautions listed in the manual before setting up or servicing this chassis.

  • Page 44: Removing The Chassis Cover And Front Bezel

    SC119X Chassis Manual Removing the Chassis Cover and Front Bezel Figure 5-1: Removing the Chassis Cover Removing the Chassis Cover: 1. Remove the power cord from the rear of both power supples. 2. Remove the screws securing the top cover to the chassis. 3.

  • Page 45: Installing Hard Drives

    The SC119X chassis supports eight hot-swappable hard drives, so it is not neces- sary to power down the server when replacing hard drives. Only enterprise level SAS or SATA hard drives are recommended for use in Supermicro chassis. Removing Hard Drive Carriers from the Chassis 1.
  • Page 46 6. Push the handle in until it clicks into the locked position. Warning: Only enterprise level hard drives are recommended for use in Supermicro chassis. Warning: Except for short periods of time (swapping hard drives), do not operate...

  • Page 47: Removing The Backplane

    Chapter 5 Chassis Setup and Maintenance Removing the Backplane The SC119X chassis backplane is located behind the hard drives and in front of the front system fans. In order to change jumper settings on the backplane, it may be necessary to remove the backplane from the chassis. Removing the Backplane from the Chassis 1.

  • Page 48: Backplane Installation

    SC119X Chassis Manual Backplane Installation Installing the Backplane 1. Slide the backplane into the chassis as shown, inserting the lower edge of the backplane into the clips on the floor of the chassis. 2. Align the mounting holes in the backplane with the mounting holes in the chassis.

  • Page 49: Installing The Motherboard

    Chapter 5 Chassis Setup and Maintenance Installing the Motherboard Optional Standoff Figure 5-7: Chassis Standoffs Permanent and Optional Standoffs Standoffs prevent short circuits by creating space between the motherboard and the chassis surface. The SC119X chassis includes permanent standoffs in locations used by most motherboards.

  • Page 50: Motherboard Installation

    SC119X Chassis Manual Motherboard Installation Installing the Motherboard 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, and precautions. 1. Remove the power cord from the rear of both power supples and remove the chassis cover as described in Section 5-2.

  • Page 51: Expansion Card Setup

    PCI slots for expansion cards. Note: A riser card must be used to install expansion cards into any SC119X chassis. Riser cards are sold separately. For the latest compatibility and performance information, visit our website at: http://www.supermicro.com. Full-Height Full-Length PCI Slots Low-Profile PCI Slot...
  • Page 52 SC119X Chassis Manual Riser Card Bracket Screws Riser Card Riser Card Bracket Figure 5-10: Chassis with a Riser Card Installing Expansion and Riser Cards 1. Confirm that you have the correct riser card for your chassis model and the expansion card includes a standard bracket. 2.
  • Page 53 Chapter 5 Chassis Setup and Maintenance Figure 5-11: Add-On Card Bracket Installation 5. In that slot, open the PCI slot cover lever and slide out the PCI slot coverfrom inside the chassis. 6. Slide the expansion card into the riser card. Figure 5-12: Add-On Card Installation 7.

  • Page 54: Installing The Air Shroud (Optional)

    SC119X Chassis Manual Installing the Air Shroud (Optional) Air shrouds concentrate airflow to maximize fan efficiency. The SC119X chassis air shroud does not require screws to set up. Notch Screw Figure 5-13: Air Shroud Installation Air Shroud Installation 1. Disconnect the chassis from any power source. 2.

  • Page 55: Checking The Air Flow

    Chapter 5 Chassis Setup and Maintenance Checking the Air Flow Check the Airflow 1. Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.

  • Page 56: System Fans

    SC119X Chassis Manual System Fans Figure 5-14: System Fans in the Fan Tray Six heavy-duty fans provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the chassis' internal temperature. The SC119X chassis contains counter-rotating fans. Each fan unit is actually made up of two fans joined back-to-back, which rotate in opposite directions.
  • Page 57 Chapter 5 Chassis Setup and Maintenance Figure 5-15: System Fans Replacing a System Fan 1. If necessary, open the chassis (described in Section 5-2) while the power is running to determine which fan has failed. Never run the server for an extended period of time with the chassis open.

  • Page 58: Power Supply

    SC119X Chassis Manual Power Supply The SC819 chassis includes a 700 Watt redundant power supply. This power sup- ply is auto-switching capable. The power supply automatically senses and operates at a 100V to 240V input voltage. An amber light will be illuminated on the power supply when the power is off.

  • Page 59: Chapter 6 Rack Installation

    Chapter 6 Rack Installation Chapter 6 Rack Installation Overview This chapter provides a quick setup to install the chassis into a rack. Following these steps in the order given should enable you to have the system installed within a minimal amount of time. Unpacking the System You should inspect the box the chassis was shipped in and note if it was damaged in any way.

  • Page 60: Rack Precautions

    SC119X Chassis Manual Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installation, stabilizers should be attached to the rack. •...

  • Page 61: Rack Mounting Considerations

    Chapter 6 Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 62: Rack Mounting Instructions

    SC119X Chassis Manual Rack Mounting Instructions This section provides information on installing the SC119X chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will vary slightly. Refer to the installation instructions that came with the rack unit.

  • Page 63: Inner Rail Extension (Optional)

    Chapter 6 Rack Installation Figure 6-2: Identifying the Sections of the Rack Rails (right side rail shown) Inner Rail Extension (Optional) The SC119X chassis includes a set of inner rails in two sections: Inner rails and optional inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack.

  • Page 64: Outer Rails

    SC119X Chassis Manual Attach Outer RailsTogether Secure to the Rear Secure to the of the Rack Front of the Rack Figure 6-3: Assembling the Outer Rails Warning: do not pick up the server by the front handles. They are designed to pull the system from a rack only.
  • Page 65 Chapter 6 Rack Installation Figure 6-5: Installing the Rack Rails Note: figures are for illustrative purposes only. Servers should always be installed in racks from the bottom up. Installing the Chassis into a Rack 1. Confirm that chassis includes the inner rails and rail extensions, and confirm that the outer rails are installed on the rack.

  • Page 66: Installing The Chassis Into A Telco Rack

    SC119X Chassis Manual Installing the Chassis into a Telco rack To install the chassis into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far follow the server will extend out the front of the rack.

  • Page 67: Appendix A Sc119 Chassis Cables

    This appendix lists supported cables for your system. It only includes the most commonly used components and configurations. For more compatible cables, refer to the manufacturer of the motherboard you are using and our Web site at: www. supermicro.com. A-2 Cables Included with SC119X Chassis (SAS/SATA) SC119XTQ-BR700WB Part # Type Length Description...
  • Page 68 SC119X Chassis Manual A-3 Compatible Cables These cables are compatible with the SC119 chassis. This section lists cables included with the SC119 chassis packages. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables.

  • Page 69: Extending Power Cables

    Appendix A Chassis Cables Extending Power Cables Although Supermicro chassis are designed with to be efficient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the moth- erboards.
  • Page 70 SC119X Chassis Manual Notes...

  • Page 71: Appendix B Sc119 Power Supply Specifications

    Appendix B Power Supply Specifications Appendix B SC119 Power Supply Specifications This appendix lists power supply specifications for your chassis system. SC119XTQ-BR700WB 700W (80 PLUS Gold Certified) MFR Part # PWS-703P-1R 700W: 100-140 V, 50-60 Hz, 8.5-6 Amp AC Input 750W: 180-240 V, 60-50 Hz, 5-3.8 Amp...
  • Page 72 SC119X Chassis Manual Notes...

  • Page 73: Appendix C Bpn-Sas-119Xtq Backplane Specifications

    Appendix C BPN-SAS-119XTQ Backplane Specifications Appendix C BPN-SAS-119XTQ Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
  • Page 74 This manual reflects BPN-SAS-119XTQ Revision 1.00, the most current release available at the time of publication. Always refer to the Supermicro web site at www.supermicro.com for the latest updates, compatible parts and supported con-...
  • Page 75 Appendix C BPN-SAS-119XTQ Backplane Specifications C-5 Front Connectors SB#1 SB#2 JP51 JP53 JP35 REV 1.00 BPN-SAS-119XTQ +12V +12V JP13 R111 JP10 JP35 MG9072 RST 1-2:RST 2-3:NO RST UPGRADE JP69 DESIGNED IN USA Figure C-1: Front Connectors 1. Main Power Connector (4-pin): JP10 9.
  • Page 76 SC119X Chassis Manual C-6 Front Connector Pin Definitions 1. - 2. Backplane Main Power Connectors Backplane Main Power 4-Pin Connector The 4-pin connectors, designated JP10 and Pin# Definition JP13 provide power to the backplane. See +12V the table on the right for pin definitions. 2 and 3 Ground 3.

  • Page 77: Explanation Of Jumpers

    Appendix C BPN-SAS-119XTQ Backplane Specifications C-7 Front Jumper Locations and Pin Settings JP35 SB#1 SB#2 JP51 JP53 JP35 REV 1.00 BPN-SAS-119XTQ +12V +12V JP13 R111 JP10 JP35 MG9072 RST 1-2:RST 2-3:NO RST UPGRADE JP69 DESIGNED IN USA Figure C-2: Front Jumpers Explanation of Jumpers Connector Pins...
  • Page 78 SC119X Chassis Manual C-8 Rear Connectors and LED Indicators D107 D102 SAS #3 SAS #5 SAS #7 SAS #5 SAS #1 SAS #7 SAS #3 SAS #1 FAIL3 ACT3 FAIL1 ACT1 FAIL5 ACT5 FAIL4 ACT7 D107 BAR CODE SAS #4 SAS #6 SAS #0 SAS #2...
  • Page 79 Appendix C BPN-SAS-119XTQ Backplane Specifications Notes...
  • Page 80 SC119X Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
