Digital Cellular Alarm Communicator
Installation and Operating Instructions
Important: Read Before Installing Model TG-9
The following tools are required for installation:
Screwdriver and appropriate mounting screws
Confirm the presence of all required parts:
Before going to the site:
•
•
56037002
®
Telguard
Digital Model TG-9
•
1x TG-9 Cellular Alarm Communicator
•
1x Dipole Antenna
•
6x End-Of-Line resistors
Fill out and submit the Telular TG-9 Digital Cellular Service Activation
Form.
Fax the activation form to 678-945-1651 or submit the activation form
on the internet at Telular.com
Note:
Ensure that you have the correct wiring diagram for the selected TG-9
Operation Profile.
Technical Support: 800-229-2326
M-F 8:00AM – 8:00PM EST
Saturday 9:00 AM – 5:00 PM EST
- 1 -
April 27, 2007
© 2007 Telular Corporation
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Telular Telguard Digital TG-9
Summary of Contents for Telular Telguard Digital TG-9
-
Page 1: Installation And Operating Instructions
1x Dipole Antenna • 6x End-Of-Line resistors Before going to the site: • Fill out and submit the Telular TG-9 Digital Cellular Service Activation Form. • Fax the activation form to 678-945-1651 or submit the activation form on the internet at Telular.com... - Page 2 Device Profile Options The Telguard TG-9 Profile is stored in the Telular Communications Center and defines how each unit operates. One profile may be used for multiple units. The profile is uploaded to the Telguard TG-9 when it is activated, there is no field programming needed.
-
Page 3: Installation Instructions
Make sure there are no Bell alarms in progress before activating. If a FLASHING RED appears on LED 2, the unit has failed registration. This usually indicates that the Activation Form has not been completed. If this occurs, call Telular Technical Support at 800-229-2326. - Page 4 56037002 - 4 - © 2007 Telular Corporation...
- Page 5 TABLE 1 – Zone 1 Bell Polarity Note: the Telguard model TG-9 requires a minimum of 250ma during normal operating mode. Please ensure you do not exceed the auxiliary current supply of the alarm panel. 56037002 - 5 - © 2007 Telular Corporation...
-
Page 6: System Specifications
150mA Transmit Warranty Telular will repair or replace (our option) inoperative units for up to two years from date of manufacture. This excludes damage due to lightning or installer error. Unauthorized modifications void this warranty. Not responsible for incidental or consequential damages. Liability limited to price of unit. This is the exclusive warranty and no other warranties will be honored, whether expressed or implied.
