SETUP INSTRUCTIONS

PRINTER PANEL 1

CF2002/CF3102 Printer
WARNING
• Do not plug in the power cord or turn on this unit until you are instructed to according to this manual.
CAUTION
• Install this machine so that it can quickly be unplugged from the electrical outlet in case of an
emergency. The socket-outlet shall be installed near the machine and shall be easily accessible.
• Keep all packing materials out of the reach of children.
NOTE
• Keep all packing materials in a safe place for later use in case they are needed for transportation.
4581-7777-01
© MINOLTA CO., LTD.
Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF2002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konica Minolta CF2002

Summary of Contents for Konica Minolta CF2002

  • Page 1: Setup Instructions

    SETUP INSTRUCTIONS PRINTER PANEL 1 CF2002/CF3102 Printer WARNING • Do not plug in the power cord or turn on this unit until you are instructed to according to this manual. CAUTION • Install this machine so that it can quickly be unplugged from the electrical outlet in case of an emergency.
  • Page 2 Printer Panel 1 1. Outline of the CF2002/CF3102 System Setup NOTE These Setup Instructions describe the setup for the parts marked in grey in the flowchart • Install and setup each option according to the instructions included with the option.
  • Page 3 • Installation Guide for a copier (printer controller and interface kit P)* I I I I Controller • Controller User Manual *:Cannot be used with the CF2002/CF3102 printer. Precautions Concerning the Installation of the Controller When installing the printer controller onto a printer that has the duplex unit attached, the printer memory must have 512 MB.

  • Page 4: Unpacking The Accessories

    Printer Panel 1 2. Unpacking Unpacking the Printer 1. Open the printer box, and then remove the box containing the imaging unit. Unpacking the Accessories 2. Open the two handle covers, and then pull out the handles. Remove the accessories from the box, and then check that the following are enclosed. (1) Imaging units.....................
  • Page 5 Printer Panel 1 Removing the Protective Tape and Packing Materials 4. Slide out the 2nd drawer and remove protec- tive tape and packing materials from the 1. Remove the tape affixed to the outside sur- Paper take-up inside of the drawer. face of the printer.

  • Page 6: Installing The Imaging Unit

    Printer Panel 1 3. Installing the Unit Protective tape 4. Take out the Yellow Imaging Unit from the Installing the Imaging Unit Imaging Unit carton. 1. Open the front door. 5. Remove the Imaging Unit from its aluminum package. 2. Pinch the Imaging Unit release lever for Yel- 6.
  • Page 7 Printer Panel 1 9. Keeping the Imaging Unit in the level posi- 12. Pull out the empty Imaging Unit cover. tion, insert the Imaging Unit into the mount- ing position on the printer until its leading edge is stopped. Make sure that the interference preventive sheet is left attached to the Imaging Unit when the Imaging Unit is inserted into the printer.
  • Page 8 Printer Panel 1 Installing the Toner Cartridge and the Filter 6. Swing the fixing lever upward to fix the toner cartridges in position. NOTE Make sure that the fixing lever is positively Toner does not come with the printer. Purchase toner cartridges (of different colors) sep- swung into position.

  • Page 9: Affixing The Label

    Printer Panel 1 4. Affixing the Label 5. Installing the Manual Holder 1. Affix the label on the right side of the top of 1. Insert the tab on the bottom of the manual Label the front door. holder into the slot in the printer as shown in the illustration.

  • Page 10: Connecting The Cables

    Printer Panel 1 6. Connecting the Cables 1. Make sure that the printer power cord is not plugged into the electrical outlet, and then insert the plug on the end of the power cord into the power cord connector on the printer. C4581U021AA 2.

  • Page 11: User Manual

    Printer Panel 1 7. Calibrating the Printer Setting Up the Servicing Equipment Set up the equipment in order to print a test pattern and make the necessary adjustments. Loading Test Paper Load test pattern paper that can be used with X-Rite calibration. NOTE Do not turn on any equipment until you are instructed to do so.
  • Page 12 Printer Panel 1 Setting Up the Selector Connecting the Equipment Cables 1. Using a DTP32 cross-cable, connect the I/O NOTE port of the X-Rite to port B of the selector. Prepare aluminum tape before beginning the setup. 1. Remove the selector from its box. C4004U559AA C4004U601AA 2.
  • Page 13 Printer Panel 1 X-Rite Calibration 4. Check that the External Panel Controller appears in the computer screen, and then display the Tech. Rep. Mode screen. (For details about displaying the Tech. Rep. Mode screen, refer to the Service Manual.) NOTE •...
  • Page 14 Printer Panel 1 6. Check the message that appears, and then 9. Check that the dialog box appears, and then click the Start key in the External Panel Con- click [Yes] in the dialog box. troller. Test patterns are printed for the four colors. (Cyan, Magenta, Yellow, Black) NOTE C4004P572CA...
  • Page 15 Printer Panel 1 12. If the reading was completed correctly, the 14. Check that the dialog box appears. dialog box shown at the left appears. If the reading was completed correctly, “OK” Prepare the cyan test pattern. is indicated. C4004P575CA C4004P578CA 13.
  • Page 16 Printer Panel 1 17. Turn the cyan test pattern to its original ori- 19. Turn the test pattern around, and then feed it entation, set the X-Rite guide to “30”, and to read the row indicated by “D” in direction then feed the pattern in direction “3”...
  • Page 17 Printer Panel 1 23. Prepare the yellow test pattern, and then 25. Check that the dialog box appears, set the repeat steps 13 through 20 of the above pro- selector knob on the selector from “B” to “A”, cedure to read the yellow test pattern with and then click [OK] in the dialog box.
  • Page 18 Printer Panel 1 8. Making System Setting 5. Check that the current date and time Checking the Date Setting settings are correct. If the settings are not correct, use the keypad in the 1. Check that the External Panel Controller appears in the computer screen. External Panel Controller to enter the correct date and time in the upper row of the screen.
  • Page 19 Printer Panel 1 Specifying the Serial Number 3. Click [Serial # Input]. NOTE Be sure to specify the serial number. When the serial number is specified, the settings for each unit can be read by the printer. If the serial number is not specified, a correctly adjusted image cannot be printed.
  • Page 20 Printer Panel 1 Specifying Who Performs Replacements 3. Click [Unit Change]. NOTE The message that appears a unit must be replaced can be changed to indicate that either the user or the service representative must perform the replacement. Select the appropriate settings depending on the type of servicing being performed.
  • Page 21 Printer Panel 1 Printing the List 6. Check that the External Panel Controller appears in the computer screen, and then display the Tech. Rep. Mode screen. (For details about displaying the Tech. Rep. Mode screen, refer to the Service Manual.) 1.

  • Page 22: To Set The Energy Save Mode Parameter

    Printer Panel 1 To set the Energy Save Mode parameter 8. Click [Image Processing]. NOTE When making settings according to the customer’s requests, refer to the procedure described below. 1. Check that the External Panel Controller appears in the computer screen. C4581P019CA 9.

  • Page 23: To Set The Sleep Mode Parameter

    Printer Panel 1 To set the Sleep Mode parameter 4. Select [2/2]. NOTE 5. Click [Energy Saver] When making settings according to the customer’s requests, refer to the procedure described below. 1. Check that the External Panel Controller appears in the computer screen. C4581P011CA 6.
  • Page 24 Printer Panel 1 4. Select [2/2]. 5. Click [Sleep] C4581P011CA 6. Using the keypad in the External Panel Controller, enter the desired number of minutes, and then click [Enter]. NOTE Select the [C] (Clear) key to erase the entered number. C4581P013CA 7.

  • Page 25: Loading Paper

    Printer Panel 1 9. Loading Paper 5. Load the paper into the drawer so that the front side of the paper (the side facing up NOTE when the package was unwrapped) faces For more details about loading paper, refer to the User Manual. NOTE Tray 1 •...
  • Page 26 Printer Panel 1 Tray 2 5. Load the paper into the drawer so that the front side of the paper (the side facing up 1. Prepare paper that meets this product’s when the package was unwrapped) faces specifications. 2. Pull out the paper drawer for Tray 2. NOTE •...
  • Page 27 Printer Panel 1 9. Affix the enclosed paper size label to Tray 2 as shown. 10. Affix the enclosed drawer number label as shown. Paper size label Drawer number label C4004U141AA 4581-7777-01 – 26 –...

  • Page 28: Adjusting The Options

    Printer Panel 1 10. Adjusting the Options 3. Click “Machine Adjust”. NOTE • With the printer, the adjustments of each option are performed with the servicing equipment. Therefore, start up the External Panel Controller, and make the adjust- ments with the appropriate setting. •...
  • Page 29 Printer Panel 1 7. Measure margin a from the edge of the 10. Open the paper drawer for the cassette that paper to the pattern printed in the test page, needs to be adjusted, and then remove all of and then check that the width of the mea- the paper.
  • Page 30 Printer Panel 1 10.2 Checking and Adjusting the Paper Reference Position for 4. Click “PRT Area”. PF-121 NOTE • For details on the installing PF-121, refer to its Setup Instructions. • To adjust PF-121, follow the instructions below. 1. Load Letter-size (or A4-size) paper into the paper drawer of the large-capacity cabi- net.
  • Page 31 Printer Panel 1 10.3 Checking and Adjusting the Paper Reference Position for 4. Click “PRT Area”. AD-14 NOTE • Perform the procedure below after adjusting the paper reference positions for the paper feed unit and the large-capacity cabinet. • For details on the installing AD-14, refer to its Setup Instructions. •...
  • Page 32 Printer Panel 1 8. Measure the width of loss for the test pattern printed on the back of the test page. NOTE Paper Exit Do not measure from the back of the test pat- Direction tern. Standard width (a): 3.0 mm ± 1.0 mm If the measured width of loss does not meet its standard width, click in the...
  • Page 33 Printer Panel 1 11. Preparing for Installation of the Controller Before installing the controller, make the following settings. I I I I Selecting the “Printer” Setting Use the External Panel Controller to change the “Priority Device” setting to “Printer”. [Default setting: Copier] 1.
  • Page 34 Printer Panel 1 12. Installing the Printer Panel 12.2 Install the Printer Panel for the Internal Controller 12.1 Checking the Contents of the Printer Panel 1. Open the front door. Before starting to set up, check that the following accessories are included with this unit. (1) Printer panel......................
  • Page 35 Printer Panel 1 4. Pull out the controller connector. 7. Install the cover as shown in the illustration. C4004U239AA C4581U006AA 5. Remove the connector cover shown in the illustration. 8. Insert the connector mentioned in step 6 into the connector on the back of the printer panel for the internal controller.
  • Page 36 Printer Panel 1 10. Secure the printer panel for the internal con- troller with the screw used to secure the cover. C4581U009AA 11. Close the front door. C4581U010AA 4581-7777-01 – 35 –...

  • Page 37: Outline Of Setup

    Printer Panel 1 13. Installing the Printer Controller 13.2 Outline of Setup Set up the printer controller according to the procedures shown below. 13.1 Operating Environment Check the contents of the enclosed p. 37 The printer controller operates under the following environment. interface kit.
  • Page 38 9. CKN clamp ......................2 10. Installation Guide* ....................1 ➀ ➂ 11. CD-ROM* ........................ 1 *:Cannot be used with the CF2002/CF3102 printer. C4025u912AA 2. Secure the controller circuit board with the C4025U904AA C4025U909AA six screws (6) for installing the circuit board.
  • Page 39 Printer Panel 1 3. Secure the IEEE1284 connector to the con- 6. Connect the fan connector to the controller troller mounting plate using the two screws circuit board. enclosed with the controller circuit board. C4342u001BA 4. Connect the three connectors. C4025u914AA ➁...
  • Page 40 Printer Panel 1 8. Hook the two tabs at the back of the interface kit into the notches on the back of the printer. 11. Install the power cord cover, and then secure it using the 2 screws (8) for installing the power cord cover.
  • Page 41 Printer Panel 1 13. Attach a CKN clamp at the lower-left corner of the back of the printer, and then pass the printer cable though the clamp. Attach a CKN clamp to the right side of the inter- face kit, and then pass the power cord through the clamp. Printer cable guide Power cord guide C4581U026AA...
  • Page 42 Printer Panel 1 14. Specifying the Printer Controller Settings 5. Display the Setup Mode screen in the printer From the printer, specify the necessary settings for using the controller. panel, press L or M until “Server Setup” appears, and then press the [Set] key. 1.
  • Page 43 Printer Panel 1 15. Checking With a Test Print 16. Connecting the Cables After setting up the controller, print the Configuration page to check that the controller is Use the IEEE1284 (Centronics), or network cable (Category 5 or 5E). operating correctly. I I I I LED descriptions 1.
  • Page 44 Printer Panel 1 17. Installing the Patch Files The PageScope Light page appears as shown below before the patch file is installed. Before installing the patch file I I I I Objective The controller is recognized as Minolta printer in a network management tool (EX.

  • Page 45: To Turn Off The Printer Controller

    Printer Panel 1 18. To turn off the printer controller 3. Press M on L to display “Shut Down Sys- tem”, and then press the [Set] key to begin NOTE shutting down the system. If the printer controller is turned off in a manner other than described in “To turn off the printer controller”, the controller may be damaged.

  • Page 46: Setting The User Environment

    Printer Panel 1 19. Setting the User Environment (Administrator Opera- 19.2 Entering Setup Mode on the Controller In order to select functions, the “Functions” menu must be selected. tions volume) The following procedures are basically for administrators. Refer to the following only if a 1.
  • Page 47 Printer Panel 1 19.3 Common Settings for Controllers 3. When “Continue to Setup?” appears, select (The recommended settings are underlined and the settings within [ ] are the default set- “Yes”, and then press the [Set] key. tings.) Server Setup Server Name Enter the server name.
  • Page 48 Printer Panel 1 I I I I SMB printing 19.5 Specifying the Settings Necessary for Printing on a Net- work Controller settings (The recommended settings are underlined and the settings within [ ] are the default set- The following procedure describes how to specify the settings necessary for printing on a tings.) network.
  • Page 49 Printer Panel 1 I I I I LPD (LPR) printing 4. Type the IP address of the controller into the field. 5. Select [Custom], and then click [Setting]. Controller settings (The recommended settings are underlined and the settings within [ ] are the default set- 6.

  • Page 50: Appletalk Printing

    Printer Panel 1 I I I I Network Printing on a Macintosh Computer Controller settings (Select the necessary settings according to the user’s environment.) AppleTalk printing Network Protocol Setup > IPX/SPX Setup IPX Auto Frame Controller settings Setup Type (The recommended settings are underlined and the settings within [ ] are the default set- tings.) Frame Setup Ethernet 802.2...

  • Page 51: Installation Troubleshooting

    Printer Panel 1 20. Checking Operation After Specifying Settings 21. Installation Troubleshooting After the setup procedures for the controller and user environment are finished, check the When printing cannot be carried out over a network: operation to ensure that the setup has been performed correctly. Check Possible Cause Action...
