Robe Spot 575 XT Service Manual
Hide thumbs
Also See for Spot 575 XT:
- Service manual (31 pages) ,
- User manual (33 pages) ,
- Service manual (21 pages)
Related Manuals for Robe Spot 575 XT
Summary of Contents for Robe Spot 575 XT
- Page 1 Service manual Spot 575 XT Exploded Diagrams Circuit Diagrams Wiring Diagrams Order Numbers Version: B...
-
Page 2: Wiring Diagram
PFL10 PFL10 PCB8 MAG-4A 110'C D L N 208 MZN 1200 SN F610AZEX AL575FV PCB6 MAG 6A F610AZEX PRODUCT: Spot 575 XT 70M/250V AC H05V-K 1GNYE TITLE: WIRING DIAGRAM H05V-K 1BK WIRING DIAGRAM 230V DOCUMENT: H05V-K 1BN VERSION: B DATE: 30.4.2003... - Page 3 PFL10 110`C PCB8 MAG-4A D L N 208 MZN 1200 SN AL575FV F610AZEX F610AZEX PCB6 MAG 6A 70M/250V AC PRODUCT: Spot 575 XT H05V-K 1GNYE TITLE: WIRING DIAGRAM H05V-K 1BK H05V-K 1BN WIRING DIAGRAM 120V DOCUMENT: VERSION: B DATE: 30.4.2003...
-
Page 4: Circuit Diagram
R66 R68 ARK500/2 R47 R49 R67 R69 100n KBL06 BC817 BZV55/12V IRFIZ44N 1N4007 T6.3A 7805 IN 22V ARK500/2 PRODUCT: Spot 575 XT KBU8J BZV55/11V 100n 100n ARK500/2 ARK500/2 IN 11V TITLE: EZ862 T3,15A CIRCUIT DIAGRAM DOCUMENT: VERSION: B DATE: 30.4.2003... - Page 5 100n VCC1 VCC2 74HC04 IN1A OUT1Y IN2A OUT2Y 74HC04 IN3A OUT3Y IC14 7805 IN1A OUT4Y EI1,2 L293D EI3,4 VCC1 VCC2 PRODUCT: Spot 575 XT ARK500/2 TITLE: EZ872 IN DC DOCUMENT: CIRCUIT DIAGRAM VERSION: B DATE: 30.4.2003 SHEET: 4 OF 5...
- Page 6 RB2/PWM1 RE2/WR 220R 270R RB3/PWM2 100R RB4/TCLK12 RA0/INT RB5/TCLK3 RA1/RT BC807-40 RA4/RX/TX 16MHz OSC1 RA5/TX/CK OSC2/CLKO MCLR PSL10 TEST 100M/16V 100n PIC17C43 PRODUCT: Spot 575 XT TITLE: EZND 41 CIRCUIT DIAGRAM DOCUMENT: VERSION: B DATE: 30.4.2003 SHEET: 5 OF 5...
- Page 7 3 13 6 12 PRODUCT: Spot 575 XT TITLE: Covers DOCUMENT: 99010509 VERSION: B DATE: 1.4.2003 SHEET: 1 OF 15...
- Page 8 11 12 PRODUCT: Spot 575 XT TITLE: Assembly of head DOCUMENT: 99010506 VERSION: B DATE: 1.4.2003 SHEET: 2 OF 15...
- Page 9 29 23 39 39 20 18 2 26 30 21 16 45 46 12 25 42 32 38 48 51 50 47 PRODUCT: Spot 575 XT TITLE: Blackoutprism modu le DOCUMENT: 99010506,99010009 VERSION: B DATE: 1.4.2003 SHEET: 3 OF 15...
- Page 10 28 32 40 33 33 12 10 23 38 31 35 36 25 9 31 35 1 PRODUCT: Spot 575 XT TITLE: Gobo module DOCUMENT: 99010058,99010006 VERSION: B DATE: 1.4.2003 SHEET: 4 OF 15...
- Page 11 PRODUCT: Spot 575 XT TITLE: Gobo wheel R 6+1 "B" DOCUMENT: 99010056 VERSION: B DATE: 1.4.2003 SHEET: 5 OF 15...
- Page 12 PRODUCT: Spot 575 XT TITLE: Gobo wheel FG 9+1 DOCUMENT: 99010057 VERSION: B DATE: 1.4.2003 SHEET: 6 OF 15...
- Page 13 6 13 19 PRODUCT: Spot 575 XT TITLE: Colour module DOCUMENT: 99010005 VERSION: B DATE: 1.4.2003 SHEET: 7 OF 15...
- Page 14 PRODUCT: Spot 575 XT TITLE: Colour wheel No.1 DOCUMENT: 99010011 VERSION: B DATE: 1.4.2003 SHEET: 8 OF 15...
- Page 15 PRODUCT: Spot 575 XT TITLE: Colour wheel No.2 DOCUMENT: 99010269 VERSION: B DATE: 1.4.2003 SHEET: 9 OF 15...
- Page 16 40 18 39 27 PRODUCT: Spot 575 XT TITLE: Source of light DOCUMENT: 99010623 VERSION: B DATE: 1.4.2003 SHEET: 10 OF 15...
- Page 17 PRODUCT: Spot 575 XT TITLE: Reflector modu le DOCUMENT: 99010623 VERSION: B DATE: 1.4.2003 SHEET: 11 OF 15...
- Page 18 10 24 1 50 35 46 42 9 44 48 11 39 20 49 35 4 39 20 35 49 PRODUCT: Spot 575 XT TITLE: Arm of head DOCUMENT: 99010507 VERSION: B DATE: 1.4.2003 SHEET: 12 OF 15...
- Page 19 9 26 8 31 34 27 38 16 PRODUCT: Spot 575 XT TITLE: Axe "X" DOCUMENT: 99010253 VERSION: B DATE: 1.4.2003 SHEET: 13 OF 15 22 37 41...
- Page 20 47 52 1 22 5 37 48 46 37 37 21 49 50 45 10 14 48 34 27 PRODUCT: Spot 575 XT TITLE: Base - 230V version DOCUMENT: 99010508 VERSION: B DATE: 1.4.2003 SHEET: 14 OF 15...
- Page 21 21 5 35 35 23 19 33 26 PRODUCT: Spot 575 XT TITLE: Base - 120V version DOCUMENT: 99010525 VERSION: B DATE: 1.4.2003 SHEET: 15 OF 15...
