Summary of Contents for Audison voce av quattro
- Page 1 AV quattro OWNER’S MANUAL CAR AUDIO MULTICHANNEL AMPLIFIER Release 1.2 www.audison.eu...
-
Page 2: Table Of Contents
9.5 How to configure AV bit IN ........................28 9.6 Full DA Example: Front + Rear + Sub with Audison bit Ten D processor ..........29 9.7 Full DA Example: Woofer + Tweeter + Sub with Audison bit Ten D processor ..........30 9.8 Full DA Example: Front + Rear + Sub with Audison bit One processor ............. -
Page 3: Introduction
OWNER’S MANUAL AV quattro / 1. INTRODUCTION Coming directly from the know-how of the exceptional Thesis line, Voce components takes the experience of listening in the car to a new level of excellence. Project innovation, advanced design, benchmark performance; the synthesis of consolidated know-how applied to car audio systems. -
Page 4: Packaging Contents
OWNER’S MANUAL AV quattro / 2. PACKAGING CONTENT - Amplifier AV quattro - Quick start guide - Warranty - nr.4 3,9 x 25mm / 0,15” x 0,99 self-tapping cross-headed fixing screws - N. 1 Allen wrench 0,118” - nr.1 60A AFS spare fuse. - CD ROM with: This Owner’s manual (.pdf format) TEST SIGNAL... -
Page 5: Safe Sound
OWNER’S MANUAL AV quattro / 3. SAFE SOUND AUDISON AMPLIFIERS CAN BE PART OF A HIGH POWER AUDIO SYSTEM THAT CAN GENERATE VERY HIGH UNDISTORTED SOUND PRESSURE LEVELS. PLEASE REMEMBER THAT LONG EXPOSURE TO AN EXCESSIVELY HIGH SOUND PRESSURE LEVEL MAY DAMAGE YOUR HEARING; THEREFORE, PLEASE USE COMMON SENSE AND PRACTICE SAFE SOUND. -
Page 6: Precautions
OWNER’S MANUAL AV quattro / 4. GENERAL PRECAUTIONS • This symbol indicates that you have to pay attention to these instructions. Disregarding them might cause accidental harms or damage your amplifier. • Before installing the amplifier, make sure you carefully read and understand all instructions. •... -
Page 7: Installation
OWNER’S MANUAL AV quattro / 5. INSTALLATION External size 470 mm / 18,50” Mounting size How to mount self-tapping screw 3,9 x 25 mm / 0,15” x 0,99 399 mm / 15,72” How to remove the panel Allen wrench 0,118”... -
Page 8: Rear Panel
OWNER’S MANUAL AV quattro / 6. REAR PANEL Protection fuse: 60 A; Power (Ground): Terminal block for the amplifier power supply negative pole connection. Insert here the battery negative cable or wire connected to the vehicle chassis. The plug accepts cables up to 2 A.W.G. For better current transfer it is recommended to use cables with the maximum cross-section possible and in any case of the same cross-section of the cable connected to the positive pole;... -
Page 9: How To Replace The Fuse
OWNER’S MANUAL AV quattro / HOW TO REPLACE THE FUSE 60A ASF Fuse (provided) HOW TO CONNECT THE REMOTE SWITCH REMOTE OUT to other amplifier REMOTE OUT... -
Page 10: Remote Switching Via Spk In
OWNER’S MANUAL AV quattro / REMOTE SWITCHING VIA SPK IN REMOTE OUT IN REMOTE OUT to other amplifier LEFT RIGHT HOW TO CONNECT THE SUB REMOTE VOLUME CONTROL VCRA Sub remote control (optional) -
Page 11: Front Panel
OWNER’S MANUAL AV quattro / 7. FRONT PANEL AV quattro IN A IN B PREOUT SPK IN (1.2 - 20V) CH A CH B IN B (IN A) MONO INPUT IN A: Channel A left and right analog inputs. Set the IN B switch to OFF, through this input you can drive channel B left and right inputs. -
Page 12: Input Controls
OWNER’S MANUAL AV quattro / INPUT CONTROLS... -
Page 13: How To Connect A Source Via Pre Inputs
OWNER’S MANUAL AV quattro / HOW TO CONNECT A SOURCE VIA PRE INPUTS FRONT REAR HOW TO CONNECT A SOURCE VIA THE SPEAKER IN HIGH-LEVEL INPUT FRONT REAR SWITCH ON enables turning the product on from the SPEAKER IN CH A inputs... -
Page 14: Input Controls
OWNER’S MANUAL AV quattro / 8. INPUT CONTROLS CONTROL PANEL: SWITCHES AND ADJUSTMENTS LEVELS AV quattro (0.3 - 5V) CH A CH B OVL SPK CH A CH B FILTER FILTER (IN R) (IN R) STEREO MONO STEREO MONO MODE LO FULL LO FULL MODE... -
Page 15: Setting Up Filters
OWNER’S MANUAL AV quattro / MULTIPLIER X1 - X10: Select X1 for a filter frequency range of 50 Hz-500 Hz for the channel B crossover. Select X10 for a filter frequency range of 500 Hz - 5 kHz for the crossover. STEREO - MONO MODE: Select STEREO to set channel B stereo outputs. -
Page 16: A Channels
OWNER’S MANUAL AV quattro / A Channels CH A CH B CH A CH B CH A CH B FILTER FILTER FILTER FILTER FILTER FILTER CH A CH B CH A CH B Full Range FILTER FILTER FILTER FILTER Full Range Full Range (IN R) (IN R) - Page 17 CH A CH B FILTER CH A CH B CH A CH B FILTER FILTER Full Range CH A CH B CH A CH B FILTER FILTER CH A CH B FILTER Full Range OWNER’S MANUAL AV quattro / (IN R) (IN R) MONO STEREO...
-
Page 18: Example 4 Ch: Front + Rear With In A - In B + Preout Inputs
OWNER’S MANUAL AV quattro / EXAMPLE 4 CH: FRONT + REAR WITH IN A - IN B + PREOUT INPUTS AV quattro IN A IN B PREOUT SPK IN (1.2 - 20V) CH A CH B IN B (IN A) MONO INPUT PREOUT to other amplifier... -
Page 19: Example 4 Ch: Woofer + Mid Hi With In A + Preout Inputs
OWNER’S MANUAL AV quattro / EXAMPLE 4 CH: WOOFER + MID HI WITH IN A + PREOUT INPUTS AV quattro IN A IN B PREOUT SPK IN (1.2 - 20V) CH A CH B IN B (IN A) MONO INPUT PREOUT to other amplifier Front PREOUT... -
Page 20: Example 3 Ch: Front + Sub With In A + Preout Inputs
OWNER’S MANUAL AV quattro / EXAMPLE 3 CH: FRONT + SUB WITH IN A + PREOUT INPUTS AV quattro IN A IN B PREOUT SPK IN (1.2 - 20V) CH A CH B IN B (IN A) MONO INPUT PREOUT to other ampli er Front PREOUT SOURCE... -
Page 21: Example 2 Ch: Left + Right With In A Right + In B Right Inputs
OWNER’S MANUAL AV quattro / EXAMPLE 2 CH: LEFT + RIGHT WITH IN A RIGHT + IN B RIGHT INPUTS AV quattro IN A IN B PREOUT SPK IN (1.2 - 20V) CH A CH B IN B (IN A) MONO INPUT Front PREOUT SOURCE... -
Page 22: Example 4 Ch: Front + Rear With Spk In A - Spk In B + Preout Inputs
OWNER’S MANUAL AV quattro / EXAMPLE 4 CH: FRONT + REAR WITH SPK IN A - SPK IN B + PREOUT INPUTS AV quattro IN A IN B PREOUT SPK IN (1.2 - 20V) CH A CH B IN B (IN A) MONO INPUT PREOUT... -
Page 23: Accessories: Av Bit In
OWNER’S MANUAL AV quattro / 9. ACCESSORIES: AV BIT IN Digital interface for all AV amplifiers. It allows a seamless digital connection with bit One and bit Ten D processors via the AD Link/AC Link connection. By inserting the AV bit IN “Digital Interface” into AV amplifiers, the digital signal in S/PDIF format, through the AD Link connection, leads directly to the high-quality internal D/A converters. -
Page 24: How To Insert Av Bit In
OWNER’S MANUAL AV quattro / HOW TO INSERT AV BIT IN WARNING: In particularly severe conditions the amplifier can reach temperatures between 80 and 90°C (176 ÷ 194°F). Make sure the temperature is not dangerous before touching it. -
Page 25: Front Panel
OWNER’S MANUAL AV quattro / FRONT PANEL AV bit IN AD Link AC Link 1. AD Link: Digital audio bus that can transmit the signal of 8 channels. It exploits a Class 5 or 6 shielded cable for Ethernet networks normally used in computer networks. AD Link IN: RJ-45 input terminal to connect a digital signal coming from other AV amplifiers or other external devices equipped with AD Link (bit One / bit Ten D). -
Page 26: Control Panel Display
OWNER’S MANUAL AV quattro / CONTROL PANEL DISPLAY AV bit IN MENU DOWN ENTER See 9.5: How to configure AV bit IN 1. AV bit IN STATUS DISPLAY: This is the visual element of the AV bit IN system with a 3-character backlit LCD. While operating it can display all configuration parameters stored in the amplifier during the installation. -
Page 27: How To Connect The Amplifier Equipped With Av Bit In To The System
OWNER’S MANUAL AV quattro / HOW TO CONNECT THE AMPLIFIER EQUIPPED WITH AV BIT IN TO THE SYSTEM... -
Page 28: How To Configure Av Bit In
=A Channel UP or DOWN “CHANNEL MAP” of the = Adress A Ch mono mode address 1 Audison processor ENTER (bit Ten D / bit One) a 8: A Ch mono mode address 8 MENU PC software. -
Page 29: Full Da Example: Front + Rear + Sub With Audison Bit Ten D Processor
OWNER’S MANUAL AV quattro / FULL DA EXAMPLE: FRONT + REAR + SUB with Audison bit Ten D processor AV bit IN AD Link AC Link DIGITAL OPTICAL IN to other amplifier REMOTE OUT IN BATT MONO: +AL / -AR SUB VOL. -
Page 30: Full Da Example: Woofer + Tweeter + Sub With Audison Bit Ten D Processor
OWNER’S MANUAL AV quattro / FULL DA EXAMPLE: WOOFER + TWEETER + SUB with Audison bit Ten D processor AV bit IN AD Link AC Link DIGITAL OPTICAL IN to other amplifier REMOTE OUT IN BATT MONO: +AL / -AR SUB VOL. -
Page 31: Full Da Example: Front + Rear + Sub With Audison Bit One Processor
OWNER’S MANUAL AV quattro / FULL DA EXAMPLE: FRONT + REAR + SUB with Audison bit One processor AV bit IN AD Link AC Link DIGITAL to other amplifier OPTICAL IN REMOTE OUT IN BATT MONO: +AL / -AR SUB VOL. -
Page 32: Full Da Example: Woofer + Tweeter + Sub With Audison Bit One Processor
OWNER’S MANUAL AV quattro / FULL DA EXAMPLE: WOOFER + TWEETER + SUB with Audison bit One processor AV bit IN AD Link AC Link DIGITAL to other amplifier OPTICAL IN REMOTE OUT IN BATT MONO: +AL / -AR SUB VOL. -
Page 33: Technical Specifications
OWNER’S MANUAL AV quattro / 10. TECHNICAL SPECIFICATIONS POWER SUPPLY Power supply voltage: 11 ÷ 15 VDC Idling current: 1.8 A Idling current when off: 0.02 mA Consumption @ 14.4 VDC (Max Musical Power): 55 A AMPLIFIER STAGE Distortion - THD (1kHz @ 4Ω): 0.04 % Bandwidth (-3 dB): 4 ÷... - Page 34 OWNER’S MANUAL AV quattro / www.audison.eu PART OF ELETTROMEDIA - 62018 Potenza Picena (MC) Italy - T +39 0733 870870 - F +39 0733 870880 - www.elettromedia.it...
