Product Information

The AXB-DTMF+ DTMF Interface (FIG. 1) links an Axcess central controller to a telephone
network, enabling dual tone multi-frequency (DTMF) and audio pass-through control. The AXB-
DTMF+, with a programmed central controller, processes incoming calls and initiates outgoing
calls to any pager or cellular phone.
The multi-function AXB-DTMF+ can be integrated for many imaginative and creative purposes
within a home or work environment using touch-tone control. For example, the AXB-DTMF+ can
announce callers by caller ID data, or can set up an audible menu selection to process incoming
calls for routing.
The audio pass-through can be used with an AXC-SPE Enhanced Speech Synthesizer card, or PC
sound card to produce audible menus, monitor phone audio, or provide audio input such as music
on hold. The AXB-DTMF+ allows a user to issue instructions to the AMX Central controller from
a remote location using any touch-tone telephone.
The AXB-DTMF+ receives and decodes DTMF audio signaling and sends the decoded data to the
central controller for the switching/controlling of any devices connected to the central controller.
An Axcess program written on a personal computer, and downloaded to the central controller,
enables the central controller to interpret the data received from the AXB-DTMF+. The program
may also issue menu selections over the telephone through an optional AXC-SPE card. For more
information about programming a central controller, refer to the Axcess Programming Guide.

Specifications

The following table lists the product specifications for the AXB-DTMF+.
AXB-DTMF+ Specifications
Power requirement
Power consumption
DTMF+ Monitoring
Incoming signal detection
Outgoing signal detection
Hardware state detection
Control
AXB-DTMF+ DTMF+ Interface
12 VDC
80 mA
The AXB-DTMF+ can monitor DTMF signals only when in an off-hook state or
when a phone attached to the extension connection is taken off-hook.
• DTMF tones
• Ring
• Distinctive ring
• Caller ID
• DTMF tones
• Ring
• Busy
• Call termination
• Dial tone
Detects if the AXB-DTMF+ is off-hook, or if the extension phone is off-hook.
Provides control for:
• AXB-DTMF+ off-hook/hangup
• Auto answer
• Extension phone on/disable
• Audio to telephone, and telephone to audio pass-through coupling
