- Page 1 RK Series In-Wall Speaker Owner’s Manual RK-650-IW-B/RK-830-IW-B/RK-555-LCR-IW-B Rave Technology G6434 South Dort Highway, Suite 2 Grand Blanc, Michigan 48439 Tel: 1-810-953-3918 www.ravetechnology.com...
- Page 2 Rave Technology Thank you for your purchase and welcome to the growing community of satisfied Rave Technology listeners. Please read the following installation and operation guidelines carefully to ensure enjoyment of your custom installed home audio system, for years to come. All...
-
Page 3: Features And Benefits
Features and Benefits Your Rave Technology custom installation speakers are designed to blend seamlessly into your home interior while providing superior sound quality. Installation Rave Technology custom installed products feature a self-engaging mounting system that does not require brackets. Simply cut a hole in the mounting surface, remove the grille from the speaker, connect the wires and place the speaker in the hole. -
Page 4: Installation
flame sources such as candles should be placed close to the product. Caution: Changes or modifications not expressly approved by the manufacturer could void the user's warranty to operate this device. Rave Technology G6434 South Dort Highway, Suite 2 Grand Blanc, Michigan 48439 Tel: 1-810-953-3918... - Page 5 RK Series Speaker Installation Guide Rave Technology , we continuously strive to improve our products. Fig.1 Stereo Sound Layout For this reason, we reserve the right to change product specifications Left Channel Right Channel without notice. The information concerning product specifications and instructions in this manual do not necessarily set forth all technical or other specifications of...
- Page 6 1.30 1.94 2.59 3.24 3.89 16 g uge 1.28 1.71 2.14 2.56 14 g uge 1.08 1.35 1.62 12 g uge 1.02 10 g uge Rave Technology G6434 South Dort Highway, Suite 2 Grand Blanc, Michigan 48439 Tel: 1-810-953-3918 www.ravetechnology.com...
-
Page 7: New Construction
#2 Phillips Screwdriver Hole Saw Pre-Construction Brackets Pre-construction brackets are available with all Rave Technology custom installed speakers. These brackets are measured to fit standard 16''/24'' wood stud intervals. Nail or Staple the pre-construction brackets to the stud in the planned speaker position. - Page 8 Once the grilles and baffle are painted and dry, remove the paint mask from the baffle and install the grilles. Rave Technology in-wall frames and grilles are designed to accept most types of paint. Care should be taken to avoid excessive paint build-up in the grille perforations.
-
Page 9: Existing Construction
Rave Technology suggests always painting the grilles separate from the speaker. The grilles may be lightly sprayed with thin paint (5 parts thinning agent to 1 part paint), but be careful not to plug the holes. Too much paint will adversely affect the sound of the speaker. - Page 10 Rave Technology in-wall frames and grilles are designed to accept most types of paint. Care should be taken to avoid excessive paint build-up in the grille perforations. If you want to paint the decorative frame and the wall together, insert the frame and attach with the dogs.
- Page 11 RK Line Specifications RK Series In-Wall Speaker Specifications RK-650-IW-B 6.5” 2-Way In-Wall Speaker Woofer: 6.5” Woven Kevlar cone, rubber surround, 22 oz Magnet, 1" voice coil, Bumped back plate, vented pole piece Tweeter: 1" Titanium Dome tweeter, Ferro-fluid cooled, Neodymium magnet, Swivel 30 degrees...
- Page 12 13" X 9" Weight (single pack): 12 LBS. Dimensions (single pack): 10.5” (H)X 7”(W) X8” (L) SHIPPED WITH GRILLES, PAINTMASK, CUTOUT TEMPLATES AND PRE-CONSTRUCTION BRACKETS Rave Technology G6434 South Dort Highway, Suite 2 Grand Blanc, Michigan 48439 Tel: 1-810-953-3918 www.ravetechnology.com...
-
Page 13: Warranty
2. Any cost or expense related to removal or reinstallation of the defective product. 3. Service performed by anyone other than an Authorized Rave Technology service depot. 4. Any product purchased from an unauthorized dealer, proof of purchase from an Authorized... - Page 14 Rave Technology G6434 South Dort Highway, Suite 2 Grand Blanc, Michigan 48439 Tel: 1-810-953-3918 www.ravetechnology.com Rave Technology...
