Directed Electronics 871XP Installation Manual page 49

L L E E D D F F L L A A S S H H E E S S
One
Two
Three
Four
Six
Seven
Eight
l l o o n n g g t t e e r r m m e e v v e e n n t t h h i i s s t t o o r r y y
The system stores the last two full triggers in memory. These are not erasable. Each time the unit sees a full trigger,
the older of the two triggers in memory will be replaced by the new trigger. To access long term event history:
1. With the ignition off, press and H H O O L L D D the Valet®/Program switch.
2. Turn on the ignition.
3. Release the Valet®/Program switch.
4. Press and release the Valet®/Program switch within 5 seconds. The LED will flash in groups
indicating the last two zones that triggered the unit for one minute or until the ignition
is turned off.
N N O O T T E E : : The Warn Away triggers are not stored to memory and will not be reported.
© 2004 Directed Electronics, Inc. Vista, CA
S S H H U U T T D D O O W W N N M M O O D D E E
Timed out
Over-rev shutdown
Low or no RPM
Transmitter shutdown (or optional push-button)
(-) Shutdown (H3/3 GRAY) or (+) Shutdown (H3/4 BROWN)
(-) Neutral safety shutdown (H3/6 BLACK/WHITE)
Wait-to-start timed out
4 4 9 9
