disarm button is pressed within 15 seconds after disarming the system. This setting could be used to unlock
the passenger doors when installing progressive door locks, for instance.
I I M M P P O O R R T T A A N N T T ! ! Never use this wire to drive anything but a relay or a low-current input! This tran-
sistorized output can only supply 200 mA, and connecting directly to a solenoid, motor, or other
high-current device will cause the module to fail.
H H 2 2 / / 5 5 W W H H I I T T E E / / B B L L A A C C K K ( ( - - ) ) 2 2 n n d d u u n n l l o o c c k k o o u u t t p p u u t t
■ S S e e c c o o n n d d u u n n l l o o c c k k o o u u t t p p u u t t : : This output can also be programmed to provide a second unlock pulse whenever the
disarm button is pressed within 15 seconds after disarming the system. This setting could be used to unlock
the passenger doors when installing progressive door locks, for instance.
r r e e l l a a y y s s a a t t e e l l l l i i t t e e i i g g n n i i t t i i o o n n s s w w i i t t c c h h i i n n t t e e r r f f a a c c e e
w w i i r r e e c c o o n n n n e e c c t t i i o o n n g g u u i i d d e e
h h e e a a v v y y g g a a u u g g e e w w i i r r e e s s
The eight heavy gauge wires coming from the large connector are used to energize high current circuits in the
vehicle. It is crucial that these connections are well-made and capable of handling the current demands. For this
reason, Scotch-Locks, T-taps and other such connectors are strongly discouraged.
P P U U R R P P L L E E ( ( + + ) ) s s t t a a r r t t e e r r o o u u t t p p u u t t
Connect this wire to the starter wire in the vehicle. (See Finding the Wires You Need section.)
G G R R E E E E N N s s t t a a r r t t e e r r i i n n p p u u t t
For anti grind or starter kill attach this wire to the key side of the starter wire for anti grind and for the starter
kill to be active.
N N O O T T E E : : If starter kill/anti-grind is not required this wire is not used.
© 2004 Directed Electronics, Inc. Vista, CA
