FITNESS SYSTEMS CL-2408 Note: Both Serial Number and Model Number are Required when Ordering Parts Customer Service (800) 548-5438 (619) 578-7676 RECORD SERIAL NUMBER HERE (619) 578-9558...
A S S E M B LY I N S T R U C T I O N S CONTENTS INSTRUCTIONS (Step 1) ............. FRAME ASSEMBLY (Step 2) ............PARTS LISTING ................HARDWARE LISTING ..............BOLT SIZING CHART ..............WASHER SIZING CHART ............WEIGHT RATIOS .................
A S S E M B LY I N S T R U C T I O N S Step 1 I N S T R U C T I O N S Before beginning assembly please take the time to read the instructions thoroughly.
Page 4
A S S E M B LY I N S T R U C T I O N S Page - 3 2408 Assembly FITNESS SYSTEMS...
A S S E M B LY I N S T R U C T I O N S Step 2 F R A M E A S S E M B L Y FACTORY INSTALLATION INSTRUCTION ONLY 1. ALL THREADED HOLES SHOULD BE TAPPED, EXCEPT INSERTS.
Page 6
A S S E M B LY I N S T R U C T I O N S Step 2a F R A M E A S S E M B L Y In this step attach two Flange Bearings to the Weight Cage. Make sure to put zerk fitting facing down on Flange Bearings.
Page 7
A S S E M B LY I N S T R U C T I O N S SEE PRE-ASSEMBLED PARTS ON PAGE 20 BEFORE ASSEMBLED MACHINE. 2408 Assembly Page - 6 FITNESS SYSTEMS...
Page 8
A S S E M B LY I N S T R U C T I O N S Step 2b F R A M E A S S E M B L Y In this step, start by attaching the Cross Tube Assembly to the Weight Cage, then attach the Seated frame to the Cross Tube Assembly and the Weight Cage.
Page 9
A S S E M B LY I N S T R U C T I O N S 1/2” INSERTS ARE BEHIND 2408 Assembly Page - 8 FITNESS SYSTEMS...
Page 10
A S S E M B LY I N S T R U C T I O N S Step 2c F R A M E A S S E M B L Y In this step start by pressing two Guide Rod Bushings into the Weight Cage.
Page 11
A S S E M B LY I N S T R U C T I O N S FOR ASSEMBLY INSTRUCTION FOR ASSEMBLY INSTRUCTION SEE PAGE 18 SEE PAGE 18 FOR CLARITY SEE A-1 FOR CLARITY SEE A-1 AW AW 2408 Assembly Page - 10 FITNESS SYSTEMS...
Page 12
A S S E M B LY I N S T R U C T I O N S Step 2d F R A M E A S S E M B L Y In this step start by attaching the Belt Assembly to the Weight Assembly(prior to attaching the Cam Belt).
Page 13
A S S E M B LY I N S T R U C T I O N S FIGURE 1 FIGURE 1 FIGURE 2 FIGURE 2 FIGURE 3 FIGURE 3 FOR BELT ASSEMBLY SEE SX145 B-1 FOR BELT ASSEMBLY SEE SX145 B-1 NOTE: 1.
Page 14
A S S E M B LY I N S T R U C T I O N S Step 2e F R A M E A S S E M B L Y In this step start by attaching the 5” Dia. x 17.25 lg Roller to the Shin Bar Assembly.
Page 15
A S S E M B LY I N S T R U C T I O N S 2408 Assembly Page - 14 FITNESS SYSTEMS...
Page 16
A S S E M B LY I N S T R U C T I O N S Step 2f F R A M E A S S E M B L Y Attach the Shield to the Weight Cage. bolts Wrench tighten Part Descriptions...
Page 17
A S S E M B LY I N S T R U C T I O N S 2408 Assembly Page - 16 FITNESS SYSTEMS...
Page 18
A S S E M B LY I N S T R U C T I O N S Step 2g F R A M E A S S E M B L Y Slide the Plate Selector Stem up into the 15 LBS Aluminum Top Plate and secure with a 7/16”...
Page 19
A S S E M B LY I N S T R U C T I O N S 2408 Assembly Page - 18 FITNESS SYSTEMS...
Page 20
A S S E M B LY I N S T R U C T I O N S Step 2h F R A M E A S S E M B L Y In this step start by pressing in two(2) Bushings, two(2) Radial Bearings, two(2) Bumper Stoppers, one(1) End Cap, and secure the 1/2”...
Page 21
A S S E M B LY I N S T R U C T I O N S P R E - A S S E M B L E D P A R T S 2408 Assembly Page - 20 FITNESS SYSTEMS...
A S S E M B LY C A T A L O G P A R T L I S T I N G Key # Qty. Part Number Description 26-STD-SX145 Belt Assembly 26-STD-SX146 Range of Motion 26-STD-SX155 Center RH BRK(Add-On) 26-STD-SX164 Extension Tube Assy.
A S S E M B LY C A T A L O G H A R D W A R E L I S T I N G Key # Qty. Part Number Description 11-BTN-12112WZ 1/2-13" x 1 1/2" Button Head Screw 11-FLA-121WZ 1/2-13"...
Page 24
O W N E R S Page - 23 2408 Assembly FITNESS SYSTEMS...
O W N E R S W E I G H T R A T I O S The above chart shows the actual weight you are lifting when the ratios are applied. To find the actual weight you are lifting you would come down from the ratio being used and across from the number of the weight plate you have pinned.
Page 28
O W N E R S Page - 27 2408 Assembly FITNESS SYSTEMS...
O W N E R S W E I G H T T R A I N I N G T I P S Always consult your physician before starting any exercise program. Hoist equipment is designed to maximize your time spent working out.
Page 30
O W N E R S Page - 29 2408 Assembly FITNESS SYSTEMS...
O W N E R S D E C A L P L AC E M E N T S Decal Descriptions 1 - 021-0004026 2 - 021-0003008 3 - 021-0004029 4 - 021-0004020 5 - 021-0003011 6 - 021-0003006 7 - 021-0012004 8 - 021-0013071 9 - 021-0003090...
Page 34
O W N E R S D E C A L R E F E R E N C E This decal has been attached to this piece of equipment to provide information regarding operation, safety and maintenance. Before use, take the time to read these decals. ROUTINE MAINTENANCE Inspect;...
Page 35
O W N E R S D E C A L R E F E R E N C E This decal have been attached to this piece of equipment to provide information regarding operation, safety and maintenance. Before use, take the time to read these decals. 021-0013071 2408 Assembly Page - 34...
Page 36
O W N E R S D E C A L R E F E R E N C E This decal has been attached to this piece of equipment to provide information regarding operation, safety and maintenance. Before use, take the time to read these decals. 021-0012004 021-0004029 SERIAL # DECAL: Always refer to the...
Page 37
O W N E R S D E C A L R E F E R E N C E This decal has been attached to this piece of equipment to provide information regarding operation, safety and maintenance. Before use, take the time to read these decals. 021-0004026 021-0004020 PATENT...
O W N E R S HOIST FITNESS SYSTEMS GENERAL MAINTENANCE INFORMATION Links, Pull-Pins, Snap Locks, Swivels, Weight Stack Pins: Check all pieces for signs of visible wear or damage. Check springs in snap hooks and pull-pins for proper tension and alignment.
Page 39
O W N E R S Continued: GENERAL MAINTENANCE INFORMATION Belt and Cable Tension: F Referring to the Assembly/Owners Manual, when belts or cables are used check all bolts and attachments to be sure they are properly attached. Check slack in belts or cables and readjust tension if needed. Seat Sleeves &...
Page 40
O W N E R S 2408 Assembly Page - 39 FITNESS SYSTEMS...
