  • Page 1 IBM PCI AUDIO ADAPTER USER’S GUIDE June 1999 OPTIONS By IBM B-1__BBBBB_...
  • Page 3: Product Registration

    Thank you for purchasing OPTIONS by IBM . Please take a few moments to register your product and provide us with information that will help IBM to better serve you in the future. Your feedback is valuable to us in developing products and services that are important to you, as well as in developing better ways to communicate with you.
  • Page 4 Contents...
  • Page 5: Inputs And Outputs

    I.Description The IBM PCI Audio Adapter provides the next generation of PCI audio performance to the PC market. The adapter not only meets the new demands of advanced PC audio applications but also enables the integration of a complete multimedia subsystem on a single adapter. The adapter functionality and interfaces are compliant with all major industry standards, including SoundBlaster®...
  • Page 6: External Connectors

    External Connectors: J1: ......Ø 3.5mm Phone Jack for MIC IN J2: ......Ø 3.5mm Phone Jack for LINE IN J3: .
  • Page 7 Keep other people from touching the card. They might have a static-electricity build-up. Limit your movement. Movement causes a build-up of static electricity. 0 Installing the IBM PCI Audio Adapter Step 1. Turn off the system and all peripheral devices.
  • Page 8 There is one CD title that comes with this package. This CD-title includes the necessary device drivers for Windows® 95,Windows® 98, Windows® NT4.0 and IBM OS/2®operating system. The driver described in this chapter supports 14 languages, that is, English, Simplified Chinese, Traditional Chinese, Danish, French, German, Italian, Japanese, Dutch, Norwegian, Portuguese, Spanish, Finish and Swedish.
  • Page 9 6) After the computer is restarted, for Win95, no user actions ard needed, for Win98 the system will detect the PCI Multimedia Audio device, and begin to process the PnP procedure. Please press “Enter” key in all the PnP procedures to accept the default settings that the setup program has set up for you. 7) Note that the setup program may ask you to insert the Win95 or Win98 system CD into the CD ROM drive, please just do as the dialog indicates to finish the driver installation.
  • Page 10 The “Select Other Location” dialog box will appear. Assuming your CD-ROM drive is D, type the command D:\Win95&98 and click “OK”. The “Update Device Driver Wizard” dialog box will appear, informing you that the “ESS Solo-1 PCI AudioDrive ” has been found by the system. Please continue by clicking “Finish”. The “Insert Disk”...
  • Page 11 The system will copy all the necessary files from the Win95 CD-ROM. Verifying the Device Driver under Win95 OSR2 To verify that the correct device driver for the audio adapter has been installed, please follow the steps below: Go to the ”Control Panel" and double-click “System”. Choose the “Device Manager”...
  • Page 12 Next, the “Add New Hardware Wizard” dialog box will inform you that the wizard has found the “ESS Solo-1 PCI AudioDrive” device. Click “Next>” to accept the location of the new device driver. An”Insert Disk” dialog box will appear to ask you to insert the driver disk. Please click “OK” to continue installing the driver.
  • Page 13 Installing and Uninstalling the Device Driver under Windows® NT4.0 4 Installing the Device Driver under Windows® NT4.0 To install the device driver for your IBM PCI Audio Adapter, please follow the steps described below: After you have installed your new audio adapter, start up your Windows® NT4.0 operating system.
  • Page 14 10) At the end of the installation, “MMPM/2-Multimedia Installation Successful” dialog box will inform you that the device driver has been successfully installed, please click “OK” to finish the installation. You have to go to the desktop, shut down and restart the system before using the IBM PCI Audio Adapter.
  • Page 15 “Finish” to restart your computer. 1 Verifying the Software Wavetable Installation under Win95/98 To verify the correct installation of the software wavetable application program for your IBM PCI Audio Adapter, please follow the steps below: Go to your ”Control Panel"...
  • Page 16 The “Setup Complete” dialog box appears. If you want the program to be removed immediately, select “Yes, I want to restart my computer now” and click “Finish” to restart your computer. Playing games under DOS mode To play games under DOS mode, please add the following line to your CONFIG.SYS file, assuming the startup driver is C: DEVICE=C:\ESSolo.SYS After rebooting your system, please type the file name “ESSolo.COM”...
  • Page 17: Appendix A. Help And Service Information

    For the support telephone number and support hours by country, refer to the following table or to the enclosed technical support insert. If the number is not provided, contact your IBM reseller or IBM marketing representative. Response time may vary depending on the number and nature of the calls received.
  • Page 18: Appendix B. Product Warranty And Notice

    Machine. If a Machine does not function as warranted during the warranty period, and IBM and your reseller are unable to either 1) make it do so or 2) replace it with one that is at least functionally equivalent, you may return it to your place of purchase and money will be refunded. The replacement may not be new but in good working order.
  • Page 19 IBM or your reseller of changes in a Machine’s location. IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM’s possession or 2) in transit in those cases where IBM is responsible for the transportation charges.
  • Page 20: Extent Of Warranty

    Machine. If a Machine does not function as warranted during the warranty period, and IBM or your reseller are unable to either 1) make it do so or 2) replace it with one that is at least functionally equivalent, you may return it to your place of purchase and your money will be refunded. The replacement may not be new, but will be in good working order.
  • Page 21: Production Status

    Machine and 2) at an engineering-change level compatible with the feature, conversion, or upgrade. Many features, conversions, or upgrades involve the removal of parts and their return to IBM. A part that replaces a removed part will assume the warranty service status of the removed part.
  • Page 22 FRANCE: Limitation of Liability: The following replaces the second sentence of the first paragraph of this Section: In such instances, regardless of the basis on which you are entitled to claim damages from IBM, IBM is liable for no more than: (items 1 and 2 unchanged).
  • Page 23 The minimum warranty period for Machines is six months. In case IBM or your reseller are unable to repair an IBM Machine, you can alternatively ask for a partial refund as far as justified by the reduced value of the unrepaired Machine or ask for a cancellation of the respective agreement for such Machine and get your money refunded.
  • Page 24 CANADA: Warranty Service: The following is added to this Section: To obtain warranty service from IBM, call 1-800-465-6666. UNITED STATES OF AMERICA: Warranty Service: The following is added to this Section: To obtain warranty service from IBM, call 1-800-IBM-SERV.
  • Page 25 IBM, are the responsibility of the user. IBM may have patents or pending patent applications covering subject matter in this document. Their furnishing of this document does not give you any license to these patents. You can send license inquiries, in writing, to:...
  • Page 26 A15-0166-310...
