  • Page 1 Hetis H61 Ultra Personal Computer MS-B050 System G52-B0501X1...

  • Page 2: Table Of Contents

    Preface Contents Copyright Notice ���������������������������������������������������������������������������������������������iii Trademarks ����������������������������������������������������������������������������������������������������iii Revision ���������������������������������������������������������������������������������������������������������iii Upgrade and Warranty ���������������������������������������������������������������������������������� iv Acquisition of Replaceable Parts ������������������������������������������������������������������ iv Technical Support ����������������������������������������������������������������������������������������� iv Green Product Features ��������������������������������������������������������������������������������� v Environmental Policy �������������������������������������������������������������������������������������� v Safety Instructions ����������������������������������������������������������������������������������������� vi CE Conformity ����������������������������������������������������������������������������������������������viii FCC-B Radio Frequency Interference Statement ����������������������������������������viii WEEE Statement ������������������������������������������������������������������������������������������...

  • Page 3: Copyright Notice

    Hetis H61 Ultra Copyright Notice The material in this document is the intellectual property of MICRO-STAR INTER- NATIONAL� We take every care in the preparation of this document, but no guar- antee is given as to the correctness of its contents� Our products are under con- tinual improvement and we reserve the right to make changes without notice�...

  • Page 4: Upgrade And Warranty

    Preface Upgrade and Warranty Please note that certain components preinstalled in the product may be upgrad- able or replaceable by user’s request� To learn more about upgrade limitation, please refer to the specifications in the User’s Manual� For any further information about the product users purchased, please contact the local dealer�...

  • Page 5: Green Product Features

    Hetis H61 Ultra Green Product Features ◙ Reduced energy consumption during use and stand-by ◙ Limited use of substances harmful to the environment and health ◙ Easily dismantled and recycled ◙ Reduced use of natural resources by encouraging recycling ◙...

  • Page 6: Safety Instructions

    Preface Safety Instructions Read the safety instructions carefully and thoroughly� All cautions and warnings on the equipment or user’s manual should be noted� Keep the User’s Guide that comes with the package for future reference� Keep this equipment away from humidity and high temperature� Lay this equipment on a reliable flat surface before setting it up�...
  • Page 7 Hetis H61 Ultra Never pour any liquid into the opening that could damage or cause electri- cal shock� Place the power cord in a way that people are unlikely to step on it� Do not place anything on the power cord�...

  • Page 8: Ce Conformity

    Preface CE Conformity Hereby, Micro-Star International CO�, LTD declares that this de- vice is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive� FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules�...

  • Page 9: Weee Statement

    Hetis H61 Ultra WEEE Statement (English) Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005, products of “electrical and electronic equipment” cannot be discarded as municipal waste anymore and manufacturers of covered electronic equipment will be obligated to take back such products at the end of their useful life�...
  • Page 10 Preface (Greek) (Ελληνικά) Σύμφωνα με την Οδηγία 2002/96/ΕΚ της Ευρωπαϊκής Ένωσης («ΕΕ») περί Απόρριψης Ηλεκτρικού και Ηλεκτρονικού Εξοπλισμού (WEEE), η οποία λαμβάνει ισχύ στις 13 Αυγούστου 2005, τα προϊόντα «ηλεκτρικού και ηλεκτρονικού εξοπλισμού» δεν είναι δυνατόν να απορριφθούν πλέον ως κοινά απορρίμματα και οι κατασκευαστές κεκαλυμμένου...
  • Page 11 Hetis H61 Ultra (Indonesia) (Bahasa Indonesia) Sesuai dengan Regulasi Uni Eropa (“UE”) perihal WEEE (Limbah Peralatan Listrik dan Elektronik), Directive 2002/96/EC, yang berlaku sejak 13, 2005, produk “peralatan listrik dan elektronik” tidak lagi dapat dibuang sebagai sampah umum dan pabrik peralatan elektronik diwajibkan untuk mengambil kembali produk terse- but pada saat masa pakainya habis�...
  • Page 12 Preface (Danish) (Dansk) I henhold til direktiv fra den europæiske union (EU) vedrørende elektrisk og elektronisk affald , Direktiv 2002/96/EC, som træder i kraft den 13� august 2005, må produkter som “elektrisk og elektronisk udstyr” ikke mere bortskaffes som kommunalt af- fald�...

  • Page 13: Overview

    Chapter 1 Overview Congratulations for purchasing the Hetis H61 Ultra (MS- B050) System. This system is your best slim PC choice. With the fantastic appearance and ultrasmall form factor, it can easily be set anywhere. The feature packed plat- form also gives you an exciting PC experience.

  • Page 14: Packing Contents

    Overview Packing Contents Hetis H61 Ultra Stand AC Power Cord Driver/ Utility Disk User Manual * Please contact us immediately if any of the items is damaged or missing. * The illustrations are for reference only and your packing contents may slightly vary...

  • Page 15: System Overview

    Hetis H61 Ultra System Overview  Front View Headphone Jack This connector is provided for headphones or speakers. Microphone Jack This connector is provided for microphones. USB 3.0 Port The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard, mouse, or other USB-compatible devices.
  • Page 16 Overview Hard Disk Drive LED This indicator shows the activity status of the HDD. It flashes when the system is accessing data on the HDD and remains off when no disk activity is detected. Optical Disk Drive A DVD Super-Multi drive is integrated for your home entertainment. (Blu-ray is optional.) Eject Button Press the eject button to open and close the optical disk drive.

  • Page 17: Rear View

    Hetis H61 Ultra  Rear View Power Jack Power supplied through this jack supplies power to your system. Power Switch Press the power switch to turn the power supply on and off. The “on” position is the solid line and the “off” position is the circle. Make sure the power supply switch to the “on”...
  • Page 18 Overview LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN). You can connect a network cable to it. Yellow Green/ Orange Color LED State Condition Left Yellow LAN link is not established. On (steady state) LAN link is established.
  • Page 19 Hetis H61 Ultra HDMI Port The High-Definition Multimedia Interface (HDMI) is an all-digital audio/ video interface capable of transmitting uncompressed streams. HDMI supports all TV format, including standard, enhanced or high-definition video, plus multi-channel digital audio on a single cable.

  • Page 20: System Specifications

    Overview System Specifications Processor ■ Intel Core™ i5, Core™ i3, Pentium and Celeron processor in the LGA1155 ® ® ® package (TDP Max 77 W) Chipset ■ Intel H61 chipset ® Memory ■ 2 DDR3 DIMM slots (non-ECC) ■ Supports Dual-Channel mode ■...
  • Page 21 Hetis H61 Ultra Storage ■ 3.5” Hard Disk Drive ■ 5.25” Optical Disk Drive Power Supply ■ 270 watt PSU with active PFC (Voltage Value Auto-Switch) Dimension ■ 385 mm (D) x 340 mm (W) x 94 mm (H) (with stand) ■...

  • Page 22: Component Replacement & Upgrade

    Overview Component Replacement & Upgrade Please note that certain components preinstalled in the product may be upgradable or replaceable by user’s request depending on the models users purchased. 1-10 To learn more about upgrade limitation, please refer to the specifications in the User’s Manual.

  • Page 23: Getting Started

    Chapter 2 Getting Started This chapter provides you with the information on hard- ware setup procedures. While connecting peripheral devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity.

  • Page 24: Safety & Comfort Tips

    Put your hands on the desk naturally to support your wrists. Avoid using your PC in a place where discomfort may occur (such as on the bed). The Hetis H61 Ultra is an electrical device. Please treat it with great care to avoid personal injury.

  • Page 25: Connecting Peripheral Devices

    Hetis H61 Ultra Connecting Peripheral Devices The I/O (input/output) ports on the rear panel allow you to connect peripheral devices. All devices listed here are for reference only.  Connecting Serial Devices Serial ports are commonly used in applications such as industrial automation systems, scientific analysis, shop till systems and some industrial/consumer products.
  • Page 26 Getting Started  Connecting VGA-Out & HDMI-Out Devices This Hetis H61 Ultra provides a VGA port and an HDMI port for connection to exter- nal monitors, projectors, set-top boxes, DVD players, digital video cameras, mini note- books, digital cameras, etc.
  • Page 27 To connect these devices, install the drivers for each device first if necessary, and then connect the device to the Hetis H61 Ultra. This Hetis H61 Ultra is capable of auto detecting the USB devices installed, and if there is no detection of the devices, please manually enable the USB devices by going to Start Menu / Control Panel / Add Hardware to add the new device.
  • Page 28  Connecting the Network Device The RJ-45 connector of the Hetis H61 Ultra allows you to connect the LAN (local area network) devices, such as a hub, switch and gateway, to build a network connection. For more instructions or detailed steps on connecting to the LAN, please ask your MIS...
  • Page 29 The eSATA standard interface supports “plug-and-play” technology, so that you can connect and remove the eSATA devices without turning off the Hetis H61 Ultra. To connect the eSATA hard disk device, simply connect the cable of the device to the...

  • Page 30: Hardware Setup

    Disconnecting the AC Power 3. Unplug the AC power cord from the electrical outlet first. 4. Unplug the AC power cord from the Hetis H61 Ultra. Important When unplugging the AC power cord, always hold the connector part of the cord. Never pull the cord directly! ...

  • Page 31: System Operations

    Chapter 3 System Operations This chapter provides you with essential information on system operations, such as system boot setup, recovery disc creation, network connection, and so on. Important It is highly recommended that you create a system re- • covery disc as the backup solution in the event of a catastrophic disk failure or other accidents.

  • Page 32: System Booting Setup For The First Time

    When the progress bar completes loading, click [Finish] to continue. 13. The system enters the Windows 7 OS to start its personalized settings. Get ready to explore your Hetis H61 Ultra after the personalized settings are done. Have fun with it!

  • Page 33: Creating System Recovery Disc

    Hetis H61 Ultra Creating System Recovery Disc For the first-time use, it is highly recommended that you create a system recovery disc as the backup solution in the event of a catastrophic disk failure or other accidents. Before moving forward, please make sure your system booting setup is complete and go over the following procedures to get it done.
  • Page 34 System Operations 3. Select [Create and burn a recovery disc] and click [Next] to continue. Alternatively, choose [Advanced] to bring forth advanced options. 4. The image of recovery disc is being created. It takes some time to finish the pro- cessing.
  • Page 35 Hetis H61 Ultra 5. Follow the on-screen instructions to prepare enough number of blank DVD discs. Insert the blank DVD disc into the optical disc drive and click [Next] to continue. 6. The Windows Disc Image Burner pops up. Click [Burn] to start the burning progress.
  • Page 36 System Operations 7. On completion of the disc creation, click [Close] to exit and take out the disc. Follow the on-screen instructions to create all recovery discs. 8. All recovery discs have been successfully created. Please store the discs carefully and click [Next] to continue.
  • Page 37 Hetis H61 Ultra 9. Check the following box if you want to remove the temporary files. Click [Finish] to complete recovery disc creation.

  • Page 38: Network Connection Under Windows

    System Operations Network Connection under Windows  Wired LAN 1. Go to [Start] > [Control Panel]. 2. Select [Connect to the Internet] under [Network and Internet].
  • Page 39 Hetis H61 Ultra 3. Select [Broadband (PPPoE)] to connect using DSL or cable that requires a user name and password. 4. Type the information from your Internet Service Provider (ISP) and click [Connect] to establish your LAN connection.

  • Page 40: Power Management

    System Operations Power Management Power management of personal computers (PCs) and monitors has the potential to save significant amounts of electricity as well as deliver environmental benefits. To be energy efficient, turn off your display or set your PC to sleep mode after a period of user inactivity.
  • Page 41 Hetis H61 Ultra ■ The Shut Down Computer menu presents the options of Sleep (S3/S4) & Shut Down (S5) for rapid and easy management of your system power.  Power Management through ENERGY STAR quali- fied monitors (Optional) The power management feature allows the computer to initiate a low-power or “Sleep”...

  • Page 42: System Recovery

    System Operations System Recovery Important The System Recovery Function is only available on systems bundled with Windows OS and MSI utilities by default. The purposes for using the System Recovery Function may include: ■ Restore the system back to the initial status of original manufacturer’s default settings.
  • Page 43 Hetis H61 Ultra 3. Select [MSI Recovery Manager] to start the System Recovery Function; or select [EXIT] to restart the system. 4. The System Recovery Function will get your system back to default settings. Press [OK] to confirm. 5. Press [OK] to reconfirm and start the System Recovery Function. Alternatively, press [Cancel] to stop.

  • Page 44: Recovering The System With The Recovery Discs

    System Operations  Recovering the System with the Recovery Discs If the F3 hotkey recovery cannot work, try recovering your system with the recovery discs that you created beforehand. Follow the instructions below to continue: 1. Insert the recovery disc into the optical disc drive and restart the system. 2.
  • Page 45 Hetis H61 Ultra 5. The system recovery menu pops up. [Hard Disk Recovery] will format the whole HDD. All data on the HDD will be erased while all settings will be restored to manu- facturer default. Select [Hard Disk Recovery] only when your HDD is infected with fatal viruses and no solution can be found except a clear cleanup of the HDD.
  • Page 46 System Operations 7. DO NOT turn off the system power while performing the system recovery function, or it may cause unknown damage to the system. 8. The following message indicates successful system recovery. Press [OK] to restart the system and access the Windows operating system as usual. 9.
