N N O O T T E E : : For parking light circuits that draw 10 amps or more, the internal jumper must be switched
to a (-) light flash output. (See the Internal Programming Jumper section of this guide.) P P / / N N 8 8 6 6 1 1 7 7
or a standard automotive SPDT relay must be used on the H1/2 light flash output harness wire.
H H 1 1 / / 3 3 W W H H I I T T E E / / B B L L U U E E ( ( - - ) ) r r e e m m o o t t e e s s t t a a r r t t a a c c t t i i v v a a t t i i o o n n i i n n p p u u t t
This input comes from the factory set to 2 activation pulses. This means that it is necessary to have 2 consecu-
tive ground pulses on the white/blue wire for the remote start to activate or to deactivate. The same holds true
for the remote control activation when set to a two pulse setting it is necessary to press the
for the remote start to activate or deactivate.
N N O O T T E E : : When the activation pulse count can be programmed to 1, 2, or 3 pulses when changed
it will affect both activation inputs; the White/Blue wire and the remote control activation.
© 2005 Directed Electronics—all rights reserved
( ( + + ) ) P P o o s s i i t t i i v v e e L L i i g g h h t t F F l l a a s s h h O O u u t t p p u u t t
( ( - - ) ) L L i i g g h h t t F F l l a a s s h h O O u u t t p p u u t t
button twice
1 1 3 3
