- Page 1 8-port 10/100Base-TX Switch (INS-806) User’s Guide...
- Page 2 COPYRIGHT All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photo copying, recording or otherwise, without the prior written permission of the publisher. FCC WARNING This equipment has been tested and found to comply with the limits for class A device, pursuant to part 15 of FCC rules.
-
Page 3: Table Of Contents
INTRODUCTION ..............5 ........5 NDUSTRIAL THERNET ECHNOLOGY ............. 5 WITCHING ECHNOLOGY ................6 EATURES INS-806 INDUSTRIAL SWITCH UNPACKING AND SETUP ..................8 ................8 NPACKING INS-806............9 AYOUT OF THE DIN R INS-806........ 11 OUNTING OF THE ..........12... -
Page 4: About This Guide
0°C to 70°C, and is designed to sustain higher than normal degrees of vibration and shock, making is suitable and safe for harsh industrial environments. This manual discusses how to install the INS-806 Industrial Fast Ethernet Switch. Terms/Usage In this guide, the term “Switch”... -
Page 5: Introduction
806 is engineered and designed especially for the harsh, industrial type environments commonly encountered in heavy industry. With its redundant DC power inputs and high performance components, the INS-806 is perfectly suited for an industrial Ethernet deployment. Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. -
Page 6: Features
Switching is a cost-effective way of increasing the total network capacity available to users on a local area network. A switch increases capacity and decreases network loading by dividing a local area network into different segments, which don’t compete with each other for network transmission capacity. Features The Switch was designed for easy installation and high performance in an industrial environment where vibration, shock,... - Page 7 bandwidth. Other key features are: Eight (8) 10/100Base-TX Rugged, hardened IP30 Case Vibration/Shock operational Power terminal block Wide voltage range: 9-48V DIP Switch to enable or disable alarm functions Power input polarity protection function Under power and over power detection function Wide operating temperature: 0°C - 70°C Store and forwarding Auto-negotiation at all ports...
-
Page 8: Ins-806 Industrial Switch Unpacking And Setup
NDUSTRIAL WITCH NPACKING AND ETUP This section and the following sections explain the setup and installation of the VOLKTEK INS-806 Industrial Switch. Unpacking Open the box of the Switch and carefully unpack it. The box should contain the following items:... -
Page 9: Layout Of The Ins-806
Layout of the INS-806 Front View of Switch Primary Power LED Redundant Power LED Alarm LED TX port 100Mbps LED TX port LNK/ACT LED... - Page 10 TOP View of Switch Grounding Screw Terminal block for power input (PWR/RPS), and alarm dry contact DIP Switches Back View of Switch Din Rail Bracket Screws...
-
Page 11: Din Rail Mounting Of The Ins-806
DIN Rail Mounting of the INS-806 The aluminum DIN Rail attachment plate should already be affixed to the back panel of the Switch. If you need to attach the DIN Rail plate, assure that the stiff metal spring is situated towards the top. Attaching the Switch... -
Page 12: Redundant Power Inputs
Switch. Do not place heavy objects on the Switch. Grounding INS-806 Industrial Switch will help eliminate the effects of noise due to electromagnetic interference (EMI). Always run the ground connection from the ground screw to the grounding surface prior to connecting DC power. - Page 13 DC Powered Switch: Power is supplied through an external DC power source. Check the technical specification section for information about the DC power input voltage. Since the switch does not include a power switch, plugging its power adapter into a power outlet will immediately power it on. plastic green colored...
-
Page 14: Ethernet Connections
C. If not already inserted into the terminal block receptor into the Switch, do so now. D. Assure your DC power supply is stable and clean before applying DC power to the Switch. Ethernet Connections The INS-806 Industrial Fast Ethernet Switch has eight 10/100Base-TX Ethernet ports. The 10/100Base-TX... -
Page 15: Led Indicators
ports are located on the Switch’s front panel and are used to connect to Ethernet-enabled devices. LED Indicators Switch Status LED Besides LED indicators for the 10/100BaseTX ports, the Switch has three LED status indicators. Power Indicator (PWR)/ Redundant Power Supply (RPS) This indicator lights green when the Switch is receiving power. -
Page 16: External Alarm Contact
External Alarm Contact The INS-806 Industrial Switch has one Alarm Contact located on the green Power Block Contact on the top panel. For detailed instructions on how to connect the Alarm Contact power wires to the two middle contacts of... -
Page 17: Dip Switch Settings
Recommended Procedure for configuring and setting DIP switches during initial installation: 1. Turn all DIP switches OFF. 2. Install the INS-806 into your network. 3. Decide which port(s) need to be monitored or triggered alarm(s). 4. Turn the corresponding port DIP switch ON. -
Page 18: Auto-Negotiation
Switching, Filtering, and Forwarding Packets entering the INS-806 Switch with source and destination addresses belonging to the same port segment will be filtered, constraining those packets to one port, and relieving the rest of the network from the need to process them. -
Page 19: Port Speed & Duplex Mode
Port Speed & Duplex Mode After plugging the selected cable to a specific port, the system uses auto-negotiation to determine the transmission mode for any new twisted-pair connection: If the attached device does not support auto-negotiation or has auto-negotiation disabled, an auto-sensing process is initiated to select the speed and set the duplex mode to half-duplex. - Page 20 Dimensions 120 x 50 x 162 mm (D x W x H) Compliance FCC Class A, CE approved Performance Transmission Store and forward, with IEEE802.3x full duplex, Method: non-blocking flow control. Packet 10Mbps Ethernet: 14,880/pps Filtering/Forwar 100Mbps Fast Ethernet: 148,800/pps ding Rate: MAC Address Automatically update...
-
Page 21: Appendix
PPENDIX RJ-45 Pin Specification For your reference, the following diagram and tables show the standard RJ-45 receptacle/connector and their pin assignments. RJ-45 Connector pin assignment Contact Media Direct Interface Signal TX + (transmit) TX - (transmit) Rx + (receive) Not used Not used Rx - (receive) Not used... - Page 22 VOLKTEK CORPORATION 4F, No. 192 Lian-Cheng Road Chung-Ho, Taipei 235, Taiwan ROC TEL: +886 (2) 8242-1000 FAX: +886 (2) 8242-3333 ISO 9001 Certified...
