- Page 1 5-port 10/100Base-TX Industrial Switch (INS-801 / INS-801W) User’s Guide...
-
Page 2: Fcc Warning
COPYRIGHT All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, whether electronic, mechanical, photo copying, recording or otherwise, without the prior written permission of the publisher. FCC WARNING This equipment has been tested and found to comply with the limits for a class A device, pursuant to part 15 of FCC rules. -
Page 3: Table Of Contents
ABLE OF ONTENTS ABOUT THIS GUIDE............4 ............... 4 ERMS SAGE INTRODUCTION ..............4 ........5 NDUSTRIAL THERNET ECHNOLOGY ............. 5 WITCHING ECHNOLOGY ................6 EATURES INS-801 INDUSTRIAL SWITCH - UNPACKING AND SET-UP ................... 7 ................7 NPACKING INS-801/801W..........8 AYOUT OF THE DIN- INS-801/801W ..... -
Page 4: About This Guide
In this guide, the term “Switch” (first letter uppercase) refers to the INS-801/801W Industrial Fast Ethernet Switch, and ”switch” (first letter lowercase) refers to all other Ethernet switches. In this guide, the term INS-801 will also refer to the INS-801W. NTRODUCTION This chapter describes the features of the Switch and... -
Page 5: Industrial Ethernet Technology
VOLKTEK has created an Industrial Series of Switches and interconnecting devices specifically for the purpose of extending Ethernet to the factory floor and industrial environments. All of... -
Page 6: Features
Features The Switch was designed for easy installation and high performance in an industrial environment where vibration, shock, heat, and RF interference may be commonplace. The Switch was specifically designed to be small and compact for easy DIN-rail mounting and it can be installed where space is limited. -
Page 7: Ins-801 Industrial Switch - Unpacking And Set-Up
Wide voltage range: 9-48V DIP-switch to enable or disable alarm functions Power input polarity protection function Under-power and over-power detection function Wide operating temp.: -40° C ~ 70° C for the INS-801W Store-and-forwarding Auto-negotiation at all copper ports INS-801 I... -
Page 8: Layout Of The Ins-801/801W
your local reseller for replacement. Layout of the INS-801/801W Front View of Switch 1. Alarm LED 2. Redundant Power LED 3. Primary Power LED 4. TX ports (5) 5. TX port 100Mbps LED 6. TX port LNK/ACT LED... - Page 9 TOP View of Switch Grounding Screw Terminal block for power input (PWR/RPS), and alarm dry contact DIP-switches Back View of Switch Din Rail Bracket Screws...
-
Page 10: Din-Rail Mounting Of The Ins-801/801W
DIN-rail mounting of the INS-801/801W The aluminum DIN-rail attachment plate should already be affixed to the back panel of the Switch. If you need to attach the DIN-rail plate, assure that the stiff metal spring is situated towards the top. Attaching the Switch to the DIN-rail is easy: just align and hook it over the top rail, making sure that the metal spring (thin bent rod) is in front of the rail edge as the rail edge bites into the space... -
Page 11: Redundant Power Inputs
from the Switch. Visually inspect the DC power jack and make sure • that it is fully secured to the power adapter. Make sure that there is proper heat dissipation from • and adequate ventilation around the Switch. Do not place heavy objects on the Switch. - Page 12 DC Powered Switch: Power is supplied through an external DC power source. Check the technical specification section for information about the DC power input voltage. Since the switch does not include a power switch, plugging its power adapter into a power outlet will immediately power it on. plastic green contact...
-
Page 13: Ethernet Connections
Procedure for Connecting DC Power: For shipping, the removable green Contact Block may be detached from the six-pin terminal contact point. It may be easier to attach the DC wires to the green Contact Block if it has first been unplugged from the terminal contact point on the switch. -
Page 14: Led Indicators
LED Indicators Switch Status LEDs Besides LED indicators for the 10/100BaseTX ports, the Switch has the following LED status indicators: Power Indicator (PWR) This indicator lights green when the Switch is receiving power from primary power supply. Otherwise, it is off. Redundant Power Supply (RPS) This indicator lights green when the Switch is receiving power from a redundant power supply. -
Page 15: Dip-Switch Settings
connection point located on the green Power Contact Block on the top panel. For detailed instructions on how to connect the Alarm Contact power wires to the two ALM contacts of the 6-contact terminal block connector, see the Procedure for Connecting DC Power in the section above (it is the same procedure). -
Page 16: Auto-Negotiation
figure below shows the DIP-switch control: DIP 1 (PWR) controls the primary power external alarm input. Default is OFF. DIP 2 (RPS) controls the redundant power external alarm input. Default is OFF. DIP 3-7 represents the alarm for port numbers of the INS-801 Switch respectively. -
Page 17: Switching, Filtering, And Forwarding
Packets that are used to maintain network operations (such as the occasional multi-cast packet) are forwarded to all ports. As with all VOLKTEK switches, the INS-801 Industrial Switch operates in the store-and-forward switching mode, which eliminates bad packets and enables peak performance to be achieved when there is heavy traffic on the network. -
Page 18: Technical Specifications
9-48V DC Temperature Operating: -10° ~ 70° C, Storage: -20° ~ 80° C INS-801W Operating: -40° ° ° ° ~ 70° ° ° ° C, Storage: -40° ° ° ° ~ 85° ° ° ° C Humidity Operating: 10% ~ 80%... -
Page 19: Appendix
Performance Transmission Method: Store-and-forward, with IEEE802.3x full duplex, non-blocking flow control. Packet Filtering / 10Mbps Ethernet: 14,880/pps Forwarding Rate: 100Mbps Fast Ethernet: 148,800/pps MAC Address Learning: Update automatically PPENDIX RJ-45 Pin Specifications The RJ-45 ports in the Switch support auto-negotiation and auto MDI/MDI-X. - Page 20 The standard cable, RJ-45 pin placement The standard RJ-45 receptacle/connector VOLKTEK CORPORATION 4F, No. 192 Lian-Cheng Road Chung-Ho, Taipei 235, Taiwan ROC TEL: +886 (2) 8242-1000 FAX: +886 (2) 8242-3333 ISO 9001 Certified...
