- Page 1 Panel Heater with Programmable Timer User Manual Please read this manual carefully before using the heater. 1000 Watt PEH002 1500 Watt PEH003 2200 Watt PEH004 Keep this manual in a safe place for future reference. PEH002 Instructions.indd 1 22/12/09 2:30:10 PM...
-
Page 2: Warnings And Safeguards
12. Do not operate with cord set coiled up as a heat buildup is likely, which could be sufficient to become a hazard. 13. The use of an extension cord with this appliance is not recommended. PEH002 Instructions.indd 2 22/12/09 2:30:11 PM... - Page 3 20. When the appliance has been unpacked, check it for transport damage and ensure all parts have been delivered. If parts are missing or if the appliance has been damaged, contact the Arlec Customer Service Team. (Refer to details on back page) 21.
-
Page 4: Free Standing
Plug into a standard 230/240 volt AC electrical outlet. Locking Screws When slotting the panel heater onto the wall mounting backet, locate and align Mounting Screws slot ‘A’ with point ‘a’ first and slot ‘B’ with point ’b’ PEH002 Instructions.indd 4 22/12/09 2:30:11 PM... -
Page 5: Care And Cleaning
PROGRAMMING Introduction Your programmable Arlec panel heater will provide controlled background warmth when you require it so as to minimize electricity usage. The heater is equipped with an electronic thermostat and a 24 hour/7 day timer with 2 timer periods that control the temperature within a set program. -
Page 6: Control Panel Overview
8. Timer Selection 9. Copy Button 10. Down Button 11. Up Button 12. Tamper Screw Fig. 3 Fig. 4 COMFORT SYMBOL FROST SYMBOL LOCK ECONOMY SYMBOL DIGITAL PROGRAM DISPLAY TIMER ON/OFF DEGREES COPY DISPLAY °C PEH002 Instructions.indd 6 22/12/09 2:30:11 PM... - Page 7 Depending on the time selection P button “5” and program set, one again to terminate the of the following will setting. illuminate Comfort Period = Orange & Red Economy Period = Orange Standby = Green PEH002 Instructions.indd 7 22/12/09 2:30:11 PM...
-
Page 8: Pre-Set Programmes
P8: Children’s Bedroom P9: Adult’s Bedroom CF: Constant frost protection – Only turns on if ambient temperature drops below 7°C CE: Constant Economy temperature CC: Constant Comfort Temperature UP: Program for the week defined by user PEH002 Instructions.indd 8 22/12/09 2:30:12 PM... -
Page 9: Setting The User Program
The word “COPY” will to the desired day. disappear and the “day” -Press the COPY button “9” will stop flashing. to complete. ENDING THE PROGRAMING Press the “PROG” button. Will show the current program. PEH002 Instructions.indd 9 22/12/09 2:30:12 PM... -
Page 10: Adjusting Program Settings
Repeat the above step to The lock symbol (a padlock) unlock the controls. will disappear and buttons will operate again. Mechanical locking/unlocking: Screw/unscrew the tamper screw located on the cover of the control panel. PEH002 Instructions.indd 10 22/12/09 2:30:12 PM... - Page 11 PEH002 Instructions.indd 11 22/12/09 2:30:12 PM...
-
Page 12: Technical Specifications
Arlec’s recommendations and within such voltage and current limits as are specified by Arlec in relation to the product. Arlec will at its own option make good, replace with the same or...
