Carrier 38TXA Product Data

With r-410a 60 hz sizes 024 thru 048
Hide thumbs Also See for 38TXA:

Advertisement

Table of Contents

See also: Product Data , Manual
®
Copyright 1996 Carrier Corporation
Product
Data
38TXA (60 Hz)

Air Conditioner

with R-410A
Sizes 024 thru 048
The 38TXA achieves energy-
efficient cooling performance
up to 14 SEER when used with
components as designated by
manufacturer. All models are listed
with UL, ARI, c-UL, CEC, Green Seal,
and Energy Star.
The Tech 2000 Silencer System
features the InViroFlow design,
energy-efficient fan and motor,
advanced sound hood, and
compressor vibration isolator plate.
InViroFlow Design for improved
airflow pattern requiring less energy.
Energy-Efficient Fan and Fan
Motor adds to quiet operation while
moving air more efficiently.
Sound Hood to muffle noise from
operation.
Compressor Vibration Isolator
Plate eliminates compressor
vibration transmission to the base
pan thus ensuring quiet operation.
FEATURES/BENEFITS
Electrical Range — All units are
offered in 208/230v single phase
only.
Wide Range of Sizes — Available
in 5 nominal sizes from 024 through
048 to meet the needs of residential
and light commercial applications.
Weather-Armor II Cabinet —
Steel is galvanized and coated with a
layer of zinc phosphate. A coat of
modified polyester powder coating is
then applied and baked-on, providing
each unit with a hard, smooth finish
that will last for many years.
All screws on cabinet exterior are
coated for a long-lasting, rust-resistant,
quality appearance.
Totally Enclosed Fan Motor —
Means greater reliability under
rain conditions, and dependable
performance for many years.
Form 38TXA-1PD

Advertisement

Table of Contents
loading

Related Manuals for Carrier 38TXA

Summary of Contents for Carrier 38TXA

  • Page 1: Air Conditioner

    Air Conditioner Data ® with R-410A Sizes 024 thru 048 The 38TXA achieves energy- efficient cooling performance up to 14 SEER when used with components as designated by manufacturer. All models are listed with UL, ARI, c-UL, CEC, Green Seal, and Energy Star.

  • Page 2: Model Number Nomenclature

    Refrigerant — The earth-friendly line filter drier to remove any moisture and easily. Each valve has a service refrigerant we use in the 38TXA is from the system. port for ease of checking operating R-410A. This advanced refrigerant refrigerant pressures.
  • Page 3 CERTIFICATION APPLIES ONLY WHEN THE CERTIFICATION OF COMPLETE SYSTEM IS LISTED WITH ARI. MANUFACTURING SITE. As an ENERGY STAR partner, Carrier Corporation has This product meets Green Seal criteria for determined that this product meets the ENERGY STAR manufacturing, energy efficiency, sound levels, guidelines for energy efficiency.
  • Page 4 Accessories ORDERING NO. DESCRIPTION KSASF0101AAA Support Feet — All Sizes KSAHS0401AAA Start Assist — Capacitor/Relay — Sizes 024–042 KSAHS0801AAA Start Assist — Capicitor/Relay — Size 048 KAACS0201PTC Start Assist — PTC — All Sizes KAALS0201LLS Liquid Solenoid Valve — All Sizes KSACY0101AAA Cycle Protector —...

  • Page 5: Accessory Description And Usage

    Accessory Description and Usage 1. Coastal Filter A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from salt damage without restricting airflow. SUGGESTED USE: In geographic areas where salt damage could occur. 2.
  • Page 6 Dimensions SHIPPING ELECTRICAL UNIT WEIGHT CHARACTERISTICS 38TXA024 ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ 38TXA030 ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ 38TXA036 ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄...

  • Page 7: Electrical Data

    Electrical data MAX FUSE† MIN WIRE OR HACR OPER VOLTS* COMPR UNIT SIZE- SIZE LENGTH (Ft) TYPE CKT 60°C/75°C** 60°C/75°C‡ BKR AMPS SERIES V/PH 024-0 61.0 13.5 0.73 17.6 14/14 44/42 030-0 72.5 14.7 0.73 19.2 14/14 41/39 036-0 208/230/1 83.0 15.4 20.2...

  • Page 8: Performance Data

    Performance data SEASONAL EFFICIENCY FACTORY- FIELD-SUPPLIED SUPPLIED SOUND ACCESSORY UNIT INDOOR TOT. CAP. ENHANCE- STANDARD RATING SIZE-SERIES UNIT BTUH MENT RATING TDR† (dBA)‡ CC5A/CD5A/CD5BA024 24,000 NONE — 12.50 12.50 CC5A/CD5A/CD5BA030* 24,000 NONE — 13.00 13.00 CC5A/CD5A/CD5BW024 24,000 NONE — 12.50 12.50 CC5A/CD5A/CD5BW030 24,000...
  • Page 9 Performance data SEASONAL EFFICIENCY FACTORY- FIELD-SUPPLIED SUPPLIED SOUND ACCESSORY UNIT INDOOR TOT. CAP. ENHANCE- STANDARD RATING SIZE-SERIES UNIT BTUH MENT RATING TDR† (dBA)‡ FK4CNF001** 29,000 — — 13.00 FK4CNF002** 29,000 — — 13.50 FK4CNF003** 29,600 — — 14.00 COILS + 58MVP040-14 VARIABLE-SPEED FURNACE CC5A/CD5A/CD5BA030 28,400 13.20...
  • Page 10 Performance data SEASONAL EFFICIENCY FACTORY- FIELD-SUPPLIED SUPPLIED SOUND ACCESSORY UNIT INDOOR TOT. CAP. ENHANCE- STANDARD RATING SIZE-SERIES UNIT BTUH MENT RATING TDR† (dBA)‡ CD3(A,B)A036 35,000 13.20 — 13.20 CD3(A,B)A042 35,000 13.20 — 13.20 CD3CA036 34,000 12.50 — 12.50 CD3CA042 34,000 12.50 —...
  • Page 11 Performance data SEASONAL EFFICIENCY FACTORY- FIELD-SUPPLIED SUPPLIED SOUND ACCESSORY UNIT INDOOR TOT. CAP. ENHANCE- STANDARD RATING SIZE-SERIES UNIT BTUH MENT RATING TDR† (dBA)‡ CD3CA042 34,000 13.00 — 13.00 CD5A/CD5BW036 35,000 13.50 — 13.50 CE3AA036 35,000 13.50 — 13.50 CE3AA042 35,000 14.00 —...
  • Page 12 Performance data SEASONAL EFFICIENCY FACTORY- FIELD-SUPPLIED SUPPLIED SOUND ACCESSORY UNIT INDOOR TOT. CAP. ENHANCE- STANDARD RATING SIZE-SERIES UNIT BTUH MENT RATING TDR† (dBA)‡ CC5A/CD5A/CD5BW048 40,500 13.50 — 13.50 CC5A/CD5BA048 40,500 13.50 — 13.50 CD3(A,B)A042 40,500 13.20 — 13.20 CD3(A,B)A048 40,500 13.50 —...
  • Page 13 Performance data SEASONAL EFFICIENCY FACTORY- FIELD-SUPPLIED SUPPLIED SOUND ACCESSORY UNIT INDOOR TOT. CAP. ENHANCE- STANDARD RATING SIZE-SERIES UNIT BTUH MENT RATING TDR† (dBA)‡ COILS + 58MVP080-20 VARIABLE-SPEED FURNACE CC5A/CD5A/CD5BA060 46,500 13.00 — 13.00 CC5A/CD5A/CD5BC048 45,000 12.50 — 12.50 CC5A/CD5A/CD5BW048 46,000 13.00 —...

  • Page 14: Detailed Cooling Capacities

    Detailed cooling capacities* CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 15 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 16 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 17 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...
  • Page 18 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAP Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡ KW** Total Sens‡...

  • Page 19: System Design

    System Design 1. Intended for outdoor installation with free air inlet and outlet. Outdoor fan external static pressure available is less than 0.01-in. wc. 2. Minimum outdoor operating air temperature without low-ambient operation accessory is 55°F (12.8°C). 3. Maximum outdoor operating air temperature is 125°F (51.7°C). 4.

  • Page 20: Service Training

    [ ] Packaged Service Training [ ] Classroom Service Training A94328 • Carrier Corporation Syracuse, New York 13221 2-96 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book Page 20 Catalog No.
