Controls - Driving Controls/Accelerator; Freewheel Device; Battery Cut-Out - Electric Mobility Eco 3 Owners Manual & Service Record

Charging Point: The charging point is situated on the upper rear right hand side of the battery box (see
Battery Charging section for further instructions).

Controls - Driving Controls/Accelerator

Finger control - To operate, turn on the ignition.
Push the right hand lever away from you and the machine moves forward. The more you push the lever the
faster the scooter goes. To brake, release the lever. Again the faster the lever is released the quicker you will
stop. To reverse, pull the left lever towards you. Do not pull both levers at once. Note. The controls can be
changed for customers with a left-hand bias. Please contact your local dealer for information.

Freewheel Device

When the vehicle is switched off the brakes are automatically engaged. This is called "Failsafe Braking".
Also, if the batteries are flat, the brakes are applied. There may be occasions where you may wish to
move the vehicle without power. To do this there is a Freewheel Device fitted.
The Freewheel device allows the vehicle to be pushed without power. To activate, first locate the lever. When
standing behind the scooter, it is located on the right hand side of the rear of the vehicle - See Illustration.
• Make sure the ignition is switched off.
• Move the lever up. The vehicle can now be pushed in Freewheel.
• Move the lever down to engage drive. The vehicle is now braked. This is the normal operating position.
• IF YOU ARE NOT COMPLETELY SURE OF THIS FEATURE CONTACT
YOUR DEALER BEFORE OPERATING THE SCOOTER.
Push the lever UP to enable the vehicle to be moved without
power. Braking is disabled. NEVER sit on the vehicle with the
lever in this position.
Pull the lever DOWN to the lower position. This is the normal
operating position. The brakes are enabled, and the vehicle can
only operate with the lever in this position

Battery Cut-Out

A battery cut-out switch is fitted on the rear left hand side of the battery box. It protects the battery from
overload. If your scooter should stop suddenly or will not start, the battery cut-out may have operated. Push
the button in and try driving the scooter. If the cut-out repeatedly operates or will not reset, contact your dealer.
